INSTALLATION
AND OPERATION
INSTRUCTIONS
BULL OUTDOOR PRODUCTS MUSTANG
36" GAS BARBECUE
CONGRATULATIONS, on the purchase of your new
BARBECUE. These units are designed and intended for
GENERAL INFORMATION
These instructions are intended as a general guide and
do not supersede national or local codes in any way.
Authorities having jurisdiction should be consulted
before installation.
Installation and provision for combustion and ventilation
air must conform to the National Fuel Gas Code, ANSI
Z223.1, or CAN/CGA-8149.1, Natural Gas Installation
Code, or CANICGA-8149.2, Propane Installation Code.
This barbecue has been tested to, and complies with,
ANSI Z21.58 and CAN/CGA 1.6 ( 1995 ), STANDARDS
FOR OUTDOOR COOKING GAS APPLIANCES.
!!! IMPORTANT !!!
Read these instructions carefully before installing or
operating this gas barbecue. These instructions should
be left with the homeowner for future reference.
!!! WARNING !!!
the information i n this manual is not followed exactly. a
If
fire or explosion may result causing property damage,
personal injury or loss of life.
Do not store combustible materials or use
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
A liquid propane tank, not connected for
use with this gas barbecue, shall not be
stored in the vicinity of this or any other
appliance.
Installation and service must be performed
by a: Qualified technician, service agency,
or the gas supplier.
Outdoor Products Inc.
TABLE OF CONTENTS
GENERAL INFORMATION
LIQUID PROPANE INFORMATION
NATURAL GAS INFORMATION
LIGHTING INSTRUCTIONS
PARTS LISTING
TROUBLE SHOOTING
WARRANTY
!!! WARNING !!!
Gas supply system must be installed i n accordance with
the
U
S National Fuel Gas Code
This appliance and its individual shut off valve must be
disconnected from the gas supply piping system during
any system pressure test i n excess of½ PSI ( 3.5
Use a system manual shut off valve to shut off the gas
supply to this gas appliance before continuing with
installation procedures.
GAS-FIRED
ANSI Z21.58 - (1995) AND CAN/CGA 1.6 - (1995)
c@us
OUTDOOR COOKING GAS APPLIANCE. 12ME
L I S T E D
WHAT TO DO IF YOU SMELL GAS:
< Shut off gas supply to the appliance.
< Extinguish any open flames.
< Open barbecue lid.
< If odor continues, Immediately call your
gas supplier. Follow the gas supplier's
instructions.
< If you can not reach your gas supplier,
call the fire department.
1
r!
\
ll
1
2
3
3
4
4
4
7
9
1 0
1 1
1 1
13
15
17
1 8
KPA
).
Advertisement
Table of Contents
Related Manuals for Bull Outdoor MUSTANG
Summary of Contents for Bull Outdoor MUSTANG
-
Page 1: Table Of Contents
36" GAS BARBECUE GENERAL INFORMATION MODELS SHIPPING AND PACKING LIST CONGRATULATIONS, on the purchase of your new SAFETY INFORMATION BULL OUTDOOR PRODUCTS MUSTANG GAS SPECIFICATIONS BARBECUE. These units are designed and intended for INSTALLATION outdoor use only. SET-UP & ASSEMBLY... -
Page 2: Bull Outdoor Products Mustang Gas
BULL OUTDOOR PRODUCTS MUSTANG GAS BARBECUE BULL OUTDOOR PRODUCTS MUSTANG GAS BARBECUE ACCESSORIES SIDE BURNER ROTISSERIE... -
Page 3: Outdoor Use Only
SHIPPING AND PACKING LIST CONSTRUCTION AND MATERIALS MUST BE MAINTAINED FROM ALL SIDES, TOP, AND BOTTOM Your BULL OUTDOOR PRODUCTS MUSTANG GAS OF THIS APPLIANCE ( 24" I N ANY DIRECTION ). BARBECUE comes assembled, ready for the gas connection,... -
Page 4: Specifications
LOCATION a range of 3/4" 5/32" male hex driver or L-wrench Your Bull Outdoor Products Mustang Gas Barbecue can #2 Phillips Screw Driver be installed on any flat, stable surface away from any combustible materials or construction. See " CLEAR-... - Page 6 CHECK FOR LEAKS! Apply soapy water to each connection and watch for bubbles. If FIGURE4 bubbles are seen, turn off the main gas supply system, retighten the connections and CHECK AGAIN! DO NOT use a lighted match or other source of ignition to check for leaks. Repeat this FIGURE 5 procedure until you are sure that there are no leaks i n the gas connections.
- Page 7 If the tank manufacturer does not resolve any FIGURE 9 issue to your satisfaction, please call the Bull Outdoor The Liquid Propane cylinder ( tank ) designed for use Products Customer Service Center.
-
Page 8: Final Set-Up
Align the TYPE 1 - LP TANK CONNECTOR with the hose and regulator furnished with this appliance or a the valve threads. Bull Outdoor Products approved replacement. Turn the fitting clock-wise until snug. DO NOT ( SEE FIGURE 10 ). - Page 9 BE CAREFUL! Make sure all gas connections regulated Natural Gas kit may be purchased by calling are snug, but do not over tighten! the Bull Outdoor Products Customer Service Center. Remove the existing cap or gas jet assembly This appliance comes assembled from the factory using from the gas stub.
-
Page 10: Maintenance
OFF on the other. MAINTENANCE GREASE DRIPPINGS Your Bull Outdoor Products Gas Barbecue was Your Bull Outdoor Products Gas Barbecue should be designed to carbonize some amount of grease thoroughly cleaned on a regular basis. Remove the... - Page 11 Visually check the burner flames on a regular basis. Remove burner plates to expose burners. Remove the burner retaining pin, located Flames should appear blue i n color, and approximately one to one and one half inches ( 1" to 1 1 /2" ) i n height. beneath the rear burner guide, beneath the rear of the burner.
