Preparing the installation Earthing Serial connection Alarm and relay connections Pan/tilt connection Network connection Connecting the power supply Adjusting the WFOV lens Configuration Assigning an IP address Testing the configuration Bosch Sicherheitssysteme GmbH Quick Installation Guide F.01U.245.673 | V4.5 | 2011.09...
For further detailed information, please see the extensive online Help for the VOT-320. This Quick Installation Guide, the Installation and Operating Manual and the current firmware package are available in other languages at www.boschsecurity.com. F.01U.245.673 | V4.5 | 2011.09 Quick Installation Guide Bosch Sicherheitssysteme GmbH...
Unpacking – Check that the delivery is complete and in perfect condition. – Arrange for the unit to be checked by Bosch Security Systems if you find any damage. F.01U.245.673 | V4.5 | 2011.09 Quick Installation Guide Bosch Sicherheitssysteme GmbH...
Use two appropriate screws, washers and spring washers to mount the camera to a mount or a pan/tilt. The spring washers must be used for the screws to thread properly. Bosch Sicherheitssysteme GmbH Quick Installation Guide F.01U.245.673 | V4.5 | 2011.09...
Failure to do this could allow water to enter the housing and damage electronic parts, camera, and lens. Use drip loops on the wiring outside of the rear end caps. F.01U.245.673 | V4.5 | 2011.09 Quick Installation Guide Bosch Sicherheitssysteme GmbH...
Bonding wire leading to the housing top Bonding wire leading to the camera module Only with pan/tilt: Bonding wire leading to the pan/tilt Earthing wire Tooth lock washer – Refasten the screw. Bosch Sicherheitssysteme GmbH Quick Installation Guide F.01U.245.673 | V4.5 | 2011.09...
If you require a serial connection to the VOT-320, connect the relevant cables to the terminal block. – Connect the terminal block to the upper orange socket on the VOT-320. F.01U.245.673 | V4.5 | 2011.09 Quick Installation Guide Bosch Sicherheitssysteme GmbH...
Connect the alarm switches to the appropriate terminals. – Connect the relay connections to the appropriate terminals. – Connect the terminal blocks to the orange sockets on the VOT-320. Bosch Sicherheitssysteme GmbH Quick Installation Guide F.01U.245.673 | V4.5 | 2011.09...
Tilt Up Tilt Down P/T Common PP Return (–) PP Supply (+) – Connect the ground wire from the pan/tilt to the GND screw on the bottom inside the housing. F.01U.245.673 | V4.5 | 2011.09 Quick Installation Guide Bosch Sicherheitssysteme GmbH...
EIA/TIA-568-A EIA/TIA-568-B white/green white/orange green orange white/orange white/green blue blue white/blue white/blue orange green white/brown white/brown brown brown – Connect the VOT-320 to the network via the RJ45 socket. Bosch Sicherheitssysteme GmbH Quick Installation Guide F.01U.245.673 | V4.5 | 2011.09...
Connect the power supply unit cables to the terminal block. – Connect the terminal block to the orange socket on the VOT-320. – Insert the power supply unit plug into a suitable socket. F.01U.245.673 | V4.5 | 2011.09 Quick Installation Guide Bosch Sicherheitssysteme GmbH...
Refasten the four screws and disconnect the monitor. – Close the cover of the housing, and secure the latches using the tamper resistant screws and the provided torx wrench. Bosch Sicherheitssysteme GmbH Quick Installation Guide F.01U.245.673 | V4.5 | 2011.09...
Before you can operate the VOT-320 within your network, it must have a valid IP address for your network and a compatible subnet mask. – If you have not already done so, install the Bosch Video Client program from the product CD. – Start Bosch Video Client.
Use the links at the top of the pages to navigate. NOTICE! Set the graphics card of the computer to 16-bit or 32-bit color depth. Otherwise the computer cannot display the video images. Bosch Sicherheitssysteme GmbH Quick Installation Guide F.01U.245.673 | V4.5 | 2011.09...
