Arton SPD-3.10 User Manual

Optical smoke point detector

Advertisement

Private enterprise "ARTON"
6 Prutska street
Chernivtsi 58008 Ukraine
EN 54-7
ISO 9001:2008
OPTICAL SMOKE POINT DETECTOR
Model: SPD-3.10
USER'S
MANUAL
For further information please contact us:
+38 0372 584373
www.arton.com.ua

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPD-3.10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Arton SPD-3.10

  • Page 1 ISO 9001:2008 OPTICAL SMOKE POINT DETECTOR Model: SPD-3.10 USER’S MANUAL Private enterprise "ARTON" 6 Prutska street Chernivtsi 58008 Ukraine EN 54-7 For further information please contact us: +38 0372 584373 www.arton.com.ua...
  • Page 2 2.1.10 Operating temperature range, °С…………………………......from - 30 to 55 2.1.11 Meantime-between-failures, h………………………….........60 000 min 2.1.12 Average lifespan, years…………………………...........10 min 2.2 Technical characteristics of the SPD-3.10 detector with the B1-B9 bases. 2.2.1 For technical characteristics of the SPD-3.10 detector with the B1-B9 bases please refer to the appropriate manuals.
  • Page 3 B01 base included Manual 1 pc. Package 1 pc. Per 25 detectors SPD-3.10 detectors can be completed with B1-B9 bases B1 base Quantity and type The quantity of bases in one Manual of bases depend on package corresponds with the...
  • Page 4 HOW TO PREPARE THE DETECTOR FOR OPERATING 5.1 Open the package after receiving detectors, check contents. ATTENTION! If detectors were in below 0 C temperature conditions before opening the package, allow them to acclimatize inside the structure for at least 4 hours. 5.2 Test detectors for proper operating.
  • Page 5 8.3 In the case faults according to a reclamation have been removed the guarantee term is prolonged for the while detectors were not in use because of faults. QUALITY AND PACKING CERTIFICATE Optical smoke detector, model SPD-3.10, serial numbers: _________________pieces With B01 base______________pieces...
  • Page 6 APPEARANCE, DIMENSIONS AND CONTACTS NUMERATION OF B01 BASE Figure 3 WIRING DIAGRAM FOR SPD-3.10 WITH B01 TO DC CONTROL PANEL For 24 V: CLR = (0,36–2) kOhm, EOL resistor - from 2,4 to 10 kOhm depending on the control panel specifications.
  • Page 7 – ceramic 0,1 – 0,22 µF; C – 22 µF 25 V Figure 5 WIRING DIAGRAM FOR SPD-3.10 WITH B01 TO AC CONTROL PANEL AL with current limited at 20 mA. Diode VD type 1N4148, EOL resistor 3.9 kOhm 0,25 W...
  • Page 8 Figure 6 WIRING DIAGRAM FOR SPD-3.10 WITH B01 TO FIRE-INTRUDER CONTROL PANEL THROUGH MUSH-1 MODULE (MUSH-2) resistor –1,5 kOhm 0,25 W. EOL resistor is specified by control panel specifications (from 1 to 10 kOhm)
