Arton DL User Manual

Waterproof linear optical smoke detector

Advertisement

Quick Links

The following abbreviations apply in the manual:
AL - alarm loop
FACP- fire alarm control panel
IR – infrared
1.1 The detector is designed to detect smoky fires inside large premises.
1.2 Detector consists of 2 units: transmitter (Tx) and receiver (Rx). Tx and Rx are
connected to each other and to alarm loop through external interface units (EIU-1).
1.3 The detector transmits the Fire and the Fault messages. The detector transmits the Fire
message when infrared radiation flux between Tx and Rx is slackened by smoke in specified
number of times, and the Fault message when the infrared radiation flux is completely obscured or
electrical connection between units is broken. These messages are indicated with red LED
indicators on the receiver.
1.4 The Fire outcoming signal retains after combustion aerosol products affecting is over.
You can reset the detector to standby mode switching off the mains supply for at least 5 s.
1.5 The detector is designed for continuous-running operation with 24V DC FACP.
2.1 Detection range
2.2 D.C. voltage range
2.3 Tx current consumption in standby mode
2.4 Rx current consumption in standby mode
2.5 Rx current consumption in fire mode
2.6 Rx current consumption in fault mode
2.7 Rx voltage drop in fire or fault mode
2.8 Tx voltage drop in standby mode
2.9 Start-up time
2.10 Dimensions of the detector's units (w/o brackets)
2.11 Weight
2.12 Permissible angles of mechanical adjustment in horizontal plane ≥±90 °
Permissible angles of mechanical adjustment in vertical plane
2.13 Operating temperature range
Relative humidity
2.14 Operating temperature range
(without moisture condensation)
2.15 Average lifetime
ARTON-DL waterproof
linear optical smoke detector

1 PURPOSE

2 TECHNICAL SPECIFICATIONS

USER'S
MANUAL
10 ÷ 100 m
10 ÷ 30 V
≤1 mA
≤1 mA
8+1,6 mA
25+5 mA
≥8 V
≥8 V
≤10 s
67х100 mm
600 g
≥±45°
from – 10 to 55 °С
95%
from -30°С and lower
≥10 years

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DL and is the answer not in the manual?

Questions and answers

Summary of Contents for Arton DL

  • Page 1 USER’S MANUAL ARTON-DL waterproof linear optical smoke detector The following abbreviations apply in the manual: AL - alarm loop FACP- fire alarm control panel IR – infrared 1 PURPOSE 1.1 The detector is designed to detect smoky fires inside large premises.
  • Page 2 Figure 2 Annex 3. The wiring diagram for the detector to 4-wire intruder fire alarm control panel with the help of MUSH-DL module is shown on Figure 3 Annex 3. The wiring diagram for the detector to 4-wire AC fire alarm control panel with the help of MUSH-DL module is shown on Figure 4 Annex 3.
  • Page 3 6 INSTALLATION 6.1 The installation should be made according to a pre-elaborate plan where the requirements of the manual should be considered. ATTENTION: Only one detector should be connected to a fire alarm loop. It is recommended to make connections of a control panel with the transmitter and the receiver with the transmitter by twisted-wire cable and lay in the special earthed cable channels.
  • Page 4 - bright flashes of the right indicator and low brightness flashes of the left indicator every 1 sec when low level of optical signal has been detected; - bright flashes of both indicators every 0.5 sec when adjustment of the receiver and transmitter has been made incorrectly - flashes at different intervals (0.5 sec and 2 sec), and a control panel will fix open- circuit in alarm loop when the electric connection between the receiver and transmitter is absent.
  • Page 5 9.3 In the case that faults according to the reclamation have been removed the guarantee term is prolonged for the while detectors were not in use because of faults. QUALITY AND PACKING CERTIFICATE ARTON-DL linear smoke detector, serial number________________________________________ Complies with EN 54-12:2004...
  • Page 6 ANNEX 1 VIEW AND DIMENSIONS OF WATERPROOF HOUSING...
  • Page 7 ANNEX 2 Figure 1 LAYOUT OF INDICATORS AND PARTS ON THE TRANSMITTER Side view Front view Indicators Bracket attaching screw Figure 2 LAYOUT OF INDICATORS AND OPERATING CONTROLS ON THE RECEIVER Front view Side view Back view Bracket Right RANGE switch attaching screw indicator CALIBRATION...
  • Page 8 U=12V EOL resistor is specified control panel manufacturer WIRING DIAGRAM TO INTRUDER FIRE ALARM CP THROUGH MUSH-DL MODULE Rn=3,6 Kohm EOL resistor is specified by control panel manufacturer (2,4 kOhm). Wiring is made by screened twisted pair WIRING DIAGRAM...
