The following abbreviations apply in the manual:
AL - alarm loop
FACP- fire alarm control panel
IR – infrared
1.1 The detector is designed to detect smoky fires inside large premises.
1.2 Detector consists of 2 units: transmitter (Tx) and receiver (Rx). Tx and Rx are
connected to each other and to alarm loop through external interface units (EIU-1).
1.3 The detector transmits the Fire and the Fault messages. The detector transmits the Fire
message when infrared radiation flux between Tx and Rx is slackened by smoke in specified
number of times, and the Fault message when the infrared radiation flux is completely obscured or
electrical connection between units is broken. These messages are indicated with red LED
indicators on the receiver.
1.4 The Fire outcoming signal retains after combustion aerosol products affecting is over.
You can reset the detector to standby mode switching off the mains supply for at least 5 s.
1.5 The detector is designed for continuous-running operation with 24V DC FACP.
2.1 Detection range
2.2 D.C. voltage range
2.3 Tx current consumption in standby mode
2.4 Rx current consumption in standby mode
2.5 Rx current consumption in fire mode
2.6 Rx current consumption in fault mode
2.7 Rx voltage drop in fire or fault mode
2.8 Tx voltage drop in standby mode
2.9 Start-up time
2.10 Dimensions of the detector's units (w/o brackets)
2.11 Weight
2.12 Permissible angles of mechanical adjustment in horizontal plane
Permissible angles of mechanical adjustment in vertical plane
2.13 Operating temperature range
Relative humidity
2.14 Operating temperature range
(without moisture condensation)
2.15 Average lifetime
ARTON-DL
linear optical smoke detector

2 TECHNICAL SPECIFICATIONS

USER'S
MANUAL

1 PURPOSE

10 ÷ 100 m
10 ÷ 30 V
1 mA
1 mA
8+1,6 mA
25+5 mA
8 V
8 V
10 s
67 100 mm
0,6 kg
±90 °
±45°
from – 10 to 55 °
95%
from -30° and lower
10 years

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARTON-DL and is the answer not in the manual?

Questions and answers

Summary of Contents for Arton ARTON-DL

  • Page 1 USER’S MANUAL ARTON-DL linear optical smoke detector The following abbreviations apply in the manual: AL - alarm loop FACP- fire alarm control panel IR – infrared 1 PURPOSE 1.1 The detector is designed to detect smoky fires inside large premises.
  • Page 2 3 ITEMS SUPPLIED WITH THE DETECTOR Name Quantity Note ARTON-DL smoke detector Receiver – 1 pc. Transmitter – 1 pc. Manual 1 dB attenuator 2 dB attenuator 4 DESIGN AND PRINCIPLES OF OPERATION 4.1 The detector is an automatic optical electronic device providing electronic and visual alarm when smoke appears in the space between Rx and Tx.
  • Page 3 Shielded cable should be used to provide additional protection against electrical obstacles. It is not recommended to place fire alarm system cables in common cable channels with other electrical wires. 6.2 It is not recommended to mount the units in places where the gases, vapour and aerosols can cause corrosion.
  • Page 4 7.2.6 If the optical signal level is low it is necessary: - set the normal level of signal turning the sensitivity adjustment screw clockwise; - set the high level of signal turning the sensitivity adjustment screw clockwise; - set the normal level of signal turning the sensitivity adjustment screw counter- clockwise.
  • Page 5 8 MAINTENANCE Detector should be checked for proper operation periodically at least once every 6 months in accordance with p.7.3. When the CALIBRATION switch on Rx is in position “1”, the detector should stay in standby mode. If the mode of indicators changes calibration should be made according to p.7.2.
  • Page 6 Figure 3 DIMENSIONS OF BRACKET ATTACHING OF RECEIVER AND TRANSMITTER 3 holes * reference dimensions Figure 4 APPEARANCE OF ARTON-DL: ) Tx; b) Rx...
  • Page 7 Figure 5 WIRING DIAGRAM FOR DETECTOR’S UNITS TO CHECK THEIR OPERATION WITHOUT ALIGNMENT: ) Rx wiring b) Tx wiring Wiring diagram for Rx Wiring diagram for Tx R = 51 Ohm EIU-1 EIU-1 Power unit Power unit 12V DC 12V DC Figure 6 WIRING DIAGRAM TO DC FACP EIU-1...
