Arton -DL User Manual

Linear optical smoke detector
Hide thumbs Also See for ARTON-DL:

Advertisement

Private enterprise "ARTON"
6 Nezalezhnosti ave.
Chernivtsi 58029 Ukraine
EN 54-12
ISO 9001:2008
LINEAR OPTICAL SMOKE DETECTOR
Model:
USER'S
MANUAL
For further information please contact us:
+38 0372 584373
www.arton.com.ua
ARTON-DL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARTON-DL and is the answer not in the manual?

Questions and answers

Summary of Contents for Arton ARTON-DL

  • Page 1 ISO 9001:2008 LINEAR OPTICAL SMOKE DETECTOR ARTON-DL Model: USER’S MANUAL Private enterprise "ARTON" 6 Nezalezhnosti ave. Chernivtsi 58029 Ukraine EN 54-12 For further information please contact us: +38 0372 584373 www.arton.com.ua...
  • Page 2: Technical Specifications

    2.9 Start‐up time                                                                                     ≤10 s  2.10 Dimensions of the detector’s units (w/o brackets)                    67х100 mm  2.11 Weight                                                     1,5 kg  2.12 Permissible angles of mechanical adjustment in horizontal plane    ≥±90 °           Permissible angles of mechanical adjustment in vertical plane       ≥±45°   2.13 Operating temperature range                                                           from – 30 to 55 °С           Relative humidity                                                                              93%      2.14 Average  lifetime                                                                               ≥10 years      3 ITEMS SUPPLIED WITH THE DETECTOR        Name               Quantity Note   ARTON‐DL smoke detector  Receiver – 1 pc.    Transmitter – 1 pc.  Manual     1 dB attenuator    2 dB attenuator       ...
  • Page 3 4 DESIGN AND PRINCIPLES OF OPERATION  4.1 The detector is an automatic optical electronic device providing electronic and  visual alarm when smoke appears in the space between Rx and Tx.  4.2 Each unit, transmitter and receiver, is a construction consisting of the housing  and  a  mounting  bracket  where  functional  units  of  Rx and  Tx  and  external  interface  units  (EIU‐1  and  EIU‐1.1)  are  located.  There  are  also  holes  on  the  bracket  intended  to  fix  detector's units.  4.3 Indicators and optical system window are located on front panels of Rx and Tx.  The  RANGE  and  CALIBRATION  switches  are  located  on  the  rear  panel  of  Rx.  The  slot  for  access ...
  • Page 4: Installation

    6 INSTALLATION  6.1  The  installation  should  be  made  according  to  a  pre‐elaborate  plan  where  the  requirements of the manual should be considered.    ATTENTION:  Only  one  detector  should  be  connected  to  a  fire  alarm  loop.  It  is  recommended  to  make  connections  of  a    control  panel  with  the  transmitter  and  the   receiver with the transmitter by twisted‐wire cable and lay in the special earthed cable ...
  • Page 5 ‐ bright flashes of both indicators every 0.5 sec when adjustment of the receiver  and transmitter has been made incorrectly  ‐  flashes  at    different  intervals  (0.5  sec  and  2  sec),  and  a  control  panel  will    fix   open‐circuit  in  alarm  loop  when  the  electric  connection  between  the  receiver  and  transmitter is absent.   7.2.4  If  the  optical  signal  level  is  high  it  is  necessary  to  attain  the  normal  signal  level by slowly turning the calibration regulator counter‐clockwise. It is allowed to change ...
  • Page 6: Maintenance

    7.3.4 Energize the loop. The standby mode will be set in 10 sec. The left indicator  on Rx shall pulse every second with low brightness.  7.3.5  Place    the  1  dB  optical  attenuator  for  at  least  15  sec    in  the  in  immediate  proximity (not greater than 2 cm) to the optical system window of the receiver so that the  optical  axe  of  Rx  lens  mates  the  attenuator's  center.  The  detector  shall  remain  in  the  standby mode.   7.3.6 Remove the 1 dB optical attenuator and in the same way set the 2 dB optical  attenuator.   The detector will go to the pre‐alarm mode, with both indicators flashing on  the receiver once every 1 sec 5 times. The brightness of the left indicators flashes will be  lower than those of the right one. After that the detector will go to the fire mode.  ...
  • Page 7    Figure 1a  APPEARANCE, DIMENSIONS, INDICATORS AND CONTROLS OF TRANSMITTER     indicators                     Figure 1b    APPEARANCE, DIMENSIONS, INDICATORS AND CONTROLS OF  RECEIVER                                                left right   indicator indicator   RANGE switch           Calibration   indicator  ...
  • Page 8      Figure 2 WIRING DIAGRAM FOR DETECTOR’S UNITS TO CHECK THEIR OPERATION  WITHOUT ALIGNMENT    Wiring diagram for Rx  Wiring diagram for Tx   = 51 Ohm                      Figure 3   WIRING DIAGRAM TO DC FACP             ...
  • Page 9 Figure 4  WIRING DIAGRAM TO FACP through MUSH‐DL module    Resistors are specified by control panel manufacturer  Wiring is made by screened twisted pair  Figure 5       WIRING DIAGRAM TO AC FACP            through MUSH‐DL module     ...
  • Page 10                   QUALITY  AND PACKING CERTIFICATE    ARTON‐DL linear smoke detector,   serial number________________________________________    Complies with EN 54‐12:2004     Approved:  Proper quality       Manufacturing date     __ __.__ __.201_ Packing date __ __.__ __.201_   This product has been successfully tested by the quality control department and  was released for sale according to the existent specifications    Quality control mark_______________     ...
