Lite-Puter ECP-A02T User Manual

Hvac control panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
ECP-A02T
HVAC Control Panel
ECP-A02T [EUM-A]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECP-A02T and is the answer not in the manual?

Questions and answers

Related Manuals for Lite-Puter ECP-A02T

Summary of Contents for Lite-Puter ECP-A02T

  • Page 1 USER MANUAL ECP-A02T HVAC Control Panel ECP-A02T [EUM-A]...

  • Page 2: Table Of Contents

    2. Operations ........................ 4 2-1 Zone Setting ........................ 4 2-2 DMX-512 Start Address Setting .................. 4 2-3 Set Operation Mode ....................5 2-4 Check Temperature..................... 5 2-5 Set Temperature ......................5 2-6 Set Fan Speed ......................5 Limited Warranty ......................7 ECP-A02T [EUM-A]...

  • Page 3: Introductions

    2. Dimension: 86(W) X 86(H) X 34.6(D) mm 3. Weight: 110g approximate. 4. Power input：DC 12V 5. Protocol: EDX(RS-485) 1-3 Panel Introductions Front Side: 1: LED Screen 2. Fan speed +/- buttons:【FAN+】and 【FAN-】 3. Temperature +/- buttons:【TEMP+】and 【TEMP-】 4. Fan speed indicators ECP-A02T [EUM-A]...
  • Page 4 Rear Side: About EDX cable line: The digital signal wiring is basically the same as RS-485 wiring. If you are not familiar with RS-485 wiring, please check EDX wiring guide on Lite-Puter’s website: http://www.liteputer.com.tw/tech_guide.asp ECP-A02T [EUM-A]...

  • Page 5: Wiring Diagram

    1-4 Wiring Diagram DP-E800 DP-NEX1 with EDX-A01D ECP-A02T [EUM-A]...

  • Page 6: Operations

    2 channel in DMX-512. Please set EDX-A01D (HVAC module) as the same address of ECP-A02T to make sure that EDX-A01R will be controlled by ECP-A02T. Example: If the DMX-512 start address of EDX-A01R is 9, please set the start address of ECP-A02T to 9.

  • Page 7: Set Operation Mode

    Figure: it shows that the current operating mode is heat mode. 2-4 Check Temperature In main screen, the LED display on ECP-A02T shows the current temperature. It shows that the current temperature is 27 ̊ ̊ C . 2-5 Set Temperature Press 【TEMP+】or【TEMP-】to set desired temperature from 16 ̊...
  • Page 8 MODE MODE (Actual (Actual - - - - Set) Set) Heater Heater (AUTO) (AUTO) MODE MODE (Actual (Actual Set) Set) Heater Heater (AUTO) (AUTO) <=-3 HIGH NO ACTION NO ACTION NO ACTION NO ACTION HEAT >=3 ECP-A02T [EUM-A]...

  • Page 9: Limited Warranty

    2. Lite-Puter guarantees to keep Lite-Puter’s from manufacturing defects within a year since the distributing date. 3. Lite-Puter does not offer on-site service. If the defects appears in Lite-Puter’s product, please deliver the product to local distributors or to Taipei headquarters.
