Echo SRM-211i Operator's Manual

Grass trimmer/brush cutter
Hide thumbs Also See for SRM-211i:
Table of Contents

Advertisement

Quick Links

Download this manual
Grass Trimmer/Brush Cutter
Operator's Manual
MODEL
Read rules for safe operation and instructions carefully. ECHO provides an Operator's
Manual and a Safety Manual. Both must be read and understood for proper and safe
operation.
X7712272502
SRM-211
WARNING
DANGER
X771000242
10/05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRM-211i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Echo SRM-211i

Summary of Contents for Echo SRM-211i

  • Page 1 Grass Trimmer/Brush Cutter Operator's Manual MODEL SRM-211 WARNING DANGER Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X7712272502 X771000242 10/05...

  • Page 2: Table Of Contents

    NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will find both easy to use and full of helpful operating tips and SAFETY messages.

  • Page 3: Safety

    RASS RIMMER RUSH UTTER PERATOR ANUAL AFETY MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages preceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you.
  • Page 4 Wear no-slip, heavy-duty work gloves to improve your grip on the handle. Gloves also reduce the transmission of machine vibration to your hands. Hearing Protection ECHO recommends wearing hearing protection whenever unit is used. Proper Clothing Wear snug fitting, durable clothing;...
  • Page 5 RASS RIMMER RUSH UTTER PERATOR ANUAL Repetitive Stress Injuries It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).

  • Page 6: Equipment

    Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual.

  • Page 7: Description

    Locate these safety decals on your unit. Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDER- ING instructions for specific information.
  • Page 8 1. POWER HEAD - Includes the Engine, Clutch, Fuel System, Ignition System and Recoil Starter. 2. GRIP - Rear (right hand) handle. 3. THROTTLE TRIGGER LOCKOUT - This lever must be held during starting. Operation of the throttle trigger is prevented unless throttle trigger lockout lever is engaged.

  • Page 9: Contents

    After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts.

  • Page 10: Assembly

    Read and comply with all safety instructions listed in this manual and attachment manual. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO for use with these units.

  • Page 11: Nylon Head Installation

    RASS RIMMER RUSH UTTER PERATOR ANUAL NYLON LINE HEAD INSTALLATION 1. Align hole in upper plate with notch in edge of gear housing and insert head locking tool (C). 2. Be sure upper plate (A) remains on PTO shaft. 3. Place line head onto PTO shaft. Followed by large metal washer. 4.

  • Page 12: Operation

    PERATION OPERATION WITH BLADES Preparing the Trimmer/Brush Cutter for Blade Use WARNING DANGER Blade use DEMANDS specific Brush Cutter configuration. Operation without specified shield, harness, and handle can result in serious personal injury. Grass/Weed Blades Require: Install Blade Conversion Kit, Includes metal shield (A), barrier bar (B), and shoulder harness (C).
  • Page 13 RASS RIMMER RUSH UTTER PERATOR ANUAL Plastic/Nylon Blades may be used where ever the nylon line head is used. DO NOT use this blade for heavy weeds or brush! 8 Tooth Weed/Grass Blade P/N 69600120331 is designed for grass, garden debris and thick weeds. DO NOT use this blade for brush or heavy woody growth, 19 mm (3/4 in.) diameter or larger.

  • Page 14: Fuel

    Emission Defect Warranty Explanation.) IMPORTANT Echo premium Power Blend Universal 2-Stroke Oil may be mixed at 50:1 ratio for application in all Echo engines sold in the past regardless of ratio specified in those manuals. IMPORTANT Spilled fuel is a leading cause of Handling Fuel hydrocarbon emissions.

  • Page 15: Starting Cold Engine

    RASS RIMMER RUSH UTTER PERATOR ANUAL STARTING COLD ENGINE WARNING DANGER The attachment will operate immediately when the engine starts and could result in loss of control and possible serious injury. Keep movable parts of the attachment off the ground and away from objects that could become entangled or thrown.

  • Page 16: Starting Warm Engine

    The attachment should not move at idle, otherwise serious personal injury may result. NOTE If attachment moves, readjust carburetor according to “Carburetor Adjustment” instructions in this manual or see your ECHO Dealer. 1. Stop Switch Move stop switch button (A) forward away from the STOP position. 2. Primer Pump primer bulb (C) until fuel is visible and flows freely in the clear fuel tank return line.

  • Page 17: Stopping Engine

    ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see you Echo Dealer for repairs.

  • Page 18: Maintenance Intervals

    MAINTENANCE INTERVALS i l y t I - t l i t l i i l o l f f ) s l l i o s t l t n i ® ® o i t n i f i r u o i t .

  • Page 19: Air Filter

    RASS RIMMER RUSH UTTER PERATOR ANUAL AIR FILTER Level 1. Tools required: 25 - 50 mm (1 - 2 in.) Cleaning Brush Parts required: 90008 REPOWER AIR & FUEL FILTER KIT. 1. Close choke (Cold Start Position [ ]). This prevents dirt from entering the carburetor throat when the air filter is removed.

  • Page 20: Spark Plug

    SPARK PLUG Level 2. Tools required: T-Wrench, feeler gauge, soft metal brush Parts Required: REPOWER Tune-Up Kit P/N 90074 IMPORTANT Use only NGK BPM-8Y spark plug (BPMR-8Y in Canada) otherwise severe engine damage may occur. 1. Remove spark plug and check for fouling, worn and rounded center electrode.
  • Page 21 RASS RIMMER RUSH UTTER PERATOR ANUAL 1. Disconnect spark plug lead from spark plug. 2. Release stored energy in power spring by removing spark plug. 3. Remove three (3) screws (A) from starter assembly and remove starter. NOTE DO NOT disassemble the starter assembly. 4.
  • Page 22 8. Use a brush to remove dirt from the cylinder fins. IMPORTANT DO NOT use a metal scraper to remove dirt from the cylinder fins. 9. Remove grass and leaves from the grid between the starter and fuel tank. 10. Reassemble parts in reverse order of removal. When installing the cover, be certain: •...

  • Page 23: Exhaust System

    The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service.

  • Page 24: Carburetor Adjustment

    See "Specifications," for correct idle speed. Level 2. Tools required: Screwdriver, Tachometer (ECHO P/N 99051130017). NOTE Every unit is run at the factory and the carburetor is set in compli- ance with emission regulations. This carburetor does not have acceleration and high speed adjustment needles.

  • Page 25: Lubrication

    PERATOR ANUAL LUBRICATION Level 1. Tools required: 8 & 13 mm Open End Wrench, Cross Head Screwdriver, Clean rag, Grease gun P/N 91016 Parts Required: ECHO LUBE 8 oz. (P/N 91014) or Lithium Base ® Grease. Gear Housing 1. Clean all loose debris from gear box.

  • Page 26: Sharpening Metal Blades

    SHARPENING METAL BLADES Three styles of metal blades are approved for use on the ECHO Brush Cutter. The 8-tooth blade can be sharpened during normal maintenance. The clearing blade and 80 tooth blade require professional service. Before sharpening, CLOSELY inspect blade for cracks (look at the bottom of each tooth and the center mounting hole closely), missing teeth and bending.

  • Page 27: Troubleshooting

    RASS RIMMER RUSH UTTER PERATOR ANUAL ROUBLESHOOTING i l l r e l i l y i l y r e l f f u r e l h t i t l i f r e l s t r t ' n i r t r e l...

  • Page 28: Storage

    TORAGE WARNING DANGER During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious property damage or personal injury may result. Long Term Storage (over 30 days) Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage mainte- nance which includes the following: 1.

  • Page 29: Specifications

    RASS RIMMER RUSH UTTER PERATOR ANUAL PECIFICATIONS MODEL ----------------------------------------------------- SRM-211 Length ------------------------------------------------------- 1780 mm (70.1 in.) Width -------------------------------------------------------- 250 mm (9.84 in.) Height ------------------------------------------------------- 325 mm (12.8 in.) Weight (dry) w/cutter head ------------------------------- 5.2 kg (11.3 lb.) Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine Bore ---------------------------------------------------------- 32.2 mm (1.27 in.) Stroke -------------------------------------------------------- 26.0 mm (1.02 in.) Displacement ----------------------------------------------- 21.2 cc (1.29 cu.
  • Page 30 NOTES...
  • Page 31 RASS RIMMER RUSH UTTER PERATOR ANUAL NOTES...

  • Page 32: Servicing Information

    • Purchasing from your Echo Dealer. • Manuals are available by sending a written request stating the model number and serial number of your Echo unit, part number of the manual, your name and address, and mail to the address below.
