99944200540
Trimmer Attachment
FOR MODELS: SRM-2100SB, 2400SB, 210SB, 211SB, 225SB,
260SB, 261SB, PAS-2100, 2400, 2601, 210, 211, 225, 225VP,
225VPB, 230, 231, 260, 261, 265, 266, 280
Operator's Manual
Users of this equipment risk injury to themselves and others if
the unit is used improperly and/or safety precautions are not
followed. ECHO provides an operator's manual. It must be read
and understood for proper and safe operation. Failure to do so
could result in serious injury.
Specifications, descriptions and illustrative material in this literature are as
accurate as known at the time of publication, but are subject to change
without notice. Illustrations may include optional equipment and
accessories, and may not include all standard equipment.
X7532279109
© 7/2016 ECHO Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRM-2100SB and is the answer not in the manual?

Questions and answers

Related Manuals for Echo SRM-2100SB

Summary of Contents for Echo SRM-2100SB

  • Page 1 Users of this equipment risk injury to themselves and others if the unit is used improperly and/or safety precautions are not followed. ECHO provides an operator’s manual. It must be read and understood for proper and safe operation. Failure to do so could result in serious injury.

  • Page 2: Table Of Contents

    The Safety Manual..................3 Servicing Information ..................3 Parts/Serial Number .................. 3 Service....................... 3 Echo Consumer Product Support .............. 4 Product Registration .................. 4 Additional or Replacement Manuals ............4 Safety ........................ 4 Manual Safety Symbols and Important Information ........4 International Symbols ................

  • Page 3: Introduction

    Service Service of this product during the warranty period must be performed by an Authorized ECHO Service Dealer. For the name and address of the Authorized ECHO Service Dealer nearest you, ask your retailer or call: 1-800-432-ECHO (3246). Dealer information is also available on our Web Site. When presenting your unit for Warranty service/repairs, proof of purchase is required.

  • Page 4: Echo Consumer Product Support

    ECHO equipment on-line at www.echo-usa.com or by filling out the product registration sheet included in this manual. Registering your product confirms your warranty coverage and provides a direct link between you and ECHO if we find it necessary to contact you.

  • Page 5: International Symbols

    International Symbols Symbol Description Symbol Description Warning, See Safety/Alert Operator’s Manual Wear eye, ear and Finger Severing head protection Wear hand Rotating Cutting and foot protection Attachment Wear slip resistant Wear Face Shield foot wear X7532279109 © 7/2016 ECHO Inc.

  • Page 6: Personal Condition And Safety Equipment

    Proper clothing and safety gear must be worn when operating unit. Physical Condition Your judgment and physical dexterity may not be good: • If you are tired or sick. • If you are taking medication. • If you have taken alcohol or drugs. X7532279109 © 7/2016 ECHO Inc.
  • Page 7 Gloves also provide protection against cuts and scratches, cold environments, and reduce the transmission of machine vibration to your hands. Hearing/Ear Protection ECHO recommends wearing hearing protection whenever unit is used. Breathing Protection Operators who are sensitive to dust or other common airborne allergens may need to wear a dust mask to prevent inhaling these materials while operating unit.
  • Page 8 In the absence of such information, ECHO does not recommend the use of this machine by anyone who has a pacemaker. Extended Operation / Extreme Conditions Prolonged exposure to cold and/or vibration may result in injury.
  • Page 9 Engine exhaust contains poisonous emissions and can cause serious injury or death. Read the Manuals • Provide all users of this equipment with the Operator’s Manual and Safety Manual for instructions on Safe Operation. X7532279109 © 7/2016 ECHO Inc.

  • Page 10: Equipment

    Replace if either is damaged or missing. • Check that the cutting attachment is firmly attached and in safe operating condition. Note: ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO.

  • Page 11: Description

    Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow the instructions on it. If a decal cannot be read, a new one can be ordered from your ECHO dealer. Shaft Label DRIVE SHAFT ASSEMBLY - Contains a specially designed liner and the flexible drive shaft.

  • Page 12: Contents

    The ECHO product you purchased has been factory pre-assembled for your convenience. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. ____ 1 - PAS Trimmer Attachment...

  • Page 13: Assembly

    Insure locator pin is fully engaged by twisting lower drive shaft. Locator pin should snap flush in coupler. Full engagement will prevent further shaft rotation. Secure lower shaft assembly to coupler by tightening clamping knob (D). X7532279109 © 7/2016 ECHO Inc.

  • Page 14: Operation

    Wear gloves to protect hands from sharp edges and hot surfaces. Your ECHO unit is designed to provide many hours of trouble free service. Regular scheduled maintenance will help your unit achieve that goal. If you are unsure or are not equipped with the necessary tools, we recommend that you take your unit to an ECHO Servicing Dealer for maintenance.

  • Page 15: Maintenance Intervals

    99944200540 MAINTENANCE Click HERE or go to http://www.echo-usa.com/products/maintenance-kit for information on Maintenance Kits Maintenance Intervals Maintenance Skill Component/System Interval Procedure Level Drive Shaft Grease Every 25 hours of use (1) Gear Housing Grease Every 50 hours of use (1) Inspect/...

  • Page 16: Nylon Line Replacement

    Hold trimmer head while turning knob clockwise to wind line onto spool until about 13 cm (5 in.) of each line remains exposed. Trimmer head is now fully loaded and ready for operation. X7532279109 © 7/2016 ECHO Inc.

  • Page 17: Storage

    236 mm (9.29 in.) Weight (dry) w/line head 1.07 kg (2.35 lb.) Drive Shaft 1/4" Flex Shaft Direction of Rotation Counter clockwise viewed from the top Cutter Head Speed-Feed® Nylon line head Line Capacity 6 m (20 ft.) X7532279109 © 7/2016 ECHO Inc.

  • Page 18: Product Registration

    Please go to http://www.echo-usa.com/Warranty/Register-Your-ECHO to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Inc. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
  • Page 19 99944200540 PRODUCT REGISTRATION X7532279109 © 7/2016 ECHO Inc.
  • Page 20 S06400369501/S06400999999 ECHO, INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 www.echo-usa.com...
