Echo SRM-210i Operator's Manual

Echo grass trimmer/brush cutter operator's manual
Hide thumbs Also See for SRM-210i:
Table of Contents

Advertisement

Quick Links

Grass Trimmer/Brush Cutter
Operator's Manual
MODEL
Read rules for safe operation and instructions carefully. ECHO provides an Operator's
Manual and a Safety Manual. Both must be read and understood for proper and safe
operation.
X7712274900
SRM-210
WARNING
DANGER
X771000490
02/04

Advertisement

Table of Contents
loading

Related Manuals for Echo SRM-210i

Summary of Contents for Echo SRM-210i

  • Page 1 Grass Trimmer/Brush Cutter Operator's Manual MODEL Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. X7712274900 SRM-210 WARNING DANGER X771000490 02/04...

  • Page 2: Table Of Contents

    NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will find both easy to use and full of helpful operating tips and SAFETY messages.

  • Page 3: Manual Safety Symbols And Important Information

    Locate these safety decals on your unit. Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDER- ING instructions for specific information.

  • Page 4: International Symbols

    • Beware of KICKOUT (blade thrust) when using blades. Special precautions are necessary for blade operation, see your Operator's and Safety Manuals. ONLY install ECHO approved blades on Brush Cutters (SRM) models equipped with proper blade shield, U-handles, harness, blade collar, nut and cotter pin.

  • Page 5: Safety Instructions

    PERSONAL CONDITION AND SAFETY EQUIPMENT WARNING Trimmer/Brush Cutter users risk injury to themselves and others if the trimmer/brush cutter is used improperly or safety precautions are not followed. Proper clothing and safety gear must be worn when operating a trimmer/brush cutter.

  • Page 6: Equipment

    Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual.

  • Page 7: Safe Operation

    SAFE OPERATION WARNING Do not operate this product indoors or in inadequately ventilated areas. Engine exhaust contains poisonous emissions and can cause serious injury or death. Read the Manuals • Provide all users of this equipment with the Operator’s Manual and Safety Manual for instructions on Safe Operation.

  • Page 8: Description

    After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts.
  • Page 9 Safety Video RASS RIMMER RUSH PERATOR UTTER ANUAL...
  • Page 10 7. NYLON CUTTER HEAD - Contains replaceable nylon trimming lines. 8. CUT-OFF KNIFE - Trims line to the correct length (5 in.). If trimmer is operated without a cut-off knife the line may be too long - more than (5 in.) - the operating speed will slow, the engine overheat and performance will suffer.

  • Page 11: Specifications

    PECIFICATIONS MODEL ----------------------------------------------------- SRM-210 Length ------------------------------------------------------- 1778 mm (70.0 in.) Width -------------------------------------------------------- 250 mm (9.84 in.) Height ------------------------------------------------------- 325 mm (12.8 in.) Weight (dry) w/cutter head ------------------------------- 5.4 kg (11.9 lb.) Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine Bore ---------------------------------------------------------- 32.2 mm (1.27 in.) Stroke -------------------------------------------------------- 26.0 mm (1.02 in.) Displacement ----------------------------------------------- 21.2 cc (1.29 cu.

  • Page 12: Assembly

    Read and comply with all safety instructions listed in this manual and attachment manual. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO for use with these units.

  • Page 13: Nylon Head Installation

    NYLON LINE HEAD INSTALLATION 1. Align hole in upper plate with notch in edge of gear housing and insert head locking tool (C). 2. Be sure upper plate (A) remains on PTO shaft. 3. Place line head onto PTO shaft. Followed by large metal washer. 4.

  • Page 14: Pre-Operation

    PERATION OPERATION WITH BLADES Preparing the Trimmer/Brush Cutter for Blade Use Blade use DEMANDS specific Brush Cutter configuration. Operation without specified shield, harness, and handle can result in serious personal injury. Grass/Weed Blades Require: Install Blade Conversion Kit, P/N 99944200415 - Includes metal shield (A), barrier bar (B), and shoulder harness (C).
  • Page 15 64 mm (2-1/2 in.) diameter. Use Shoulder/Waist Harness (P/N 99944200200) Use of the Shoulder/ Waist Harness is recommended for ALL Trimmer/Brush Cutter use. The Shoulder/Waist Harness suspends the trimmer from the operator's shoulder and reduces operator fatigue.

  • Page 16: Fuel

    IMPORTANT Echo premium Power Blend Universal 2-Stroke Oil may be mixed at 50:1 ratio for application in all Echo engines sold in the past regardless of ratio specified in those manuals. Mixing Instructions 1. Fill an approved fuel container with half of the required amount of gasoline.

  • Page 17: Operation

    PERATION STARTING COLD ENGINE WARNING The attachment will operate immediately when the engine starts and could result in loss of control and possible serious injury. Keep movable parts of the attachment off the ground and away from objects that could become entangled or thrown. 1.

  • Page 18: Starting Warm Engine

    The attachment should not move at idle, otherwise serious personal injury may result. NOTE If attachment moves, readjust carburetor according to “Carburetor Adjustment” instructions in this manual or see your ECHO Dealer. 1. Stop Switch Move stop switch button (A) forward away from the STOP position. 2. Primer Pump primer bulb (C) until fuel is visible and flows freely in the clear fuel tank return line.

  • Page 19: Stopping Engine

    ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see you Echo Dealer for repairs.

  • Page 20: Maintenance Intervals

    MAINTENANCE INTERVALS i l y t l i t l i i l o l f f ) s l l i o s t l t n i ® ® o i t t I - n i f i r u o i t .

  • Page 21: Air Filter

    AIR FILTER Level 1. Tools required: 25 - 50 mm (1 - 2 in.) Cleaning Brush Parts required: 90008 REPOWER 1. Close choke (Cold Start Position [ entering the carburetor throat when the air filter is removed. Brush accumulated dirt from the air cleaner area. 2.

  • Page 22: Spark Plug

    SPARK PLUG Level 2. Tools required: T-Wrench, feeler gauge, soft metal brush Parts Required: REPOWER Tune-Up Kit P/N 90074C 1. Remove spark plug and check for fouling, worn and rounded center electrode. 2. Clean the plug or replace with a new one. DO NOT sand blast to clean.
  • Page 23 1. Disconnect spark plug lead from spark plug. 2. Release stored energy in power spring by removing spark plug. 3. Remove three (3) screws (A) from starter assembly and remove starter. NOTE DO NOT disassemble the starter assembly. 4. Remove the four screws that retain the engine cover. Two at the inside top of the mounting plate (B), one on the top guard (C), and one at the muffler cover (D).
  • Page 24 8. Use a brush to remove dirt from the cylinder fins. IMPORTANT DO NOT use a metal scraper to remove dirt from the cylinder fins. 9. Remove grass and leaves from the grid between the starter and fuel tank. 10. Reassemble parts in reverse order of removal. When installing the cover, be certain: •...

  • Page 25: Exhaust System

    The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service. RASS...

  • Page 26: Carburetor Adjustment

    See "Specifications," for correct idle speed. Level 2. Tools required: Screwdriver, Tachometer (ECHO P/N 99051130017). NOTE Every unit is run at the factory and the carburetor is set in compli- ance with emission regulations. This carburetor does not have acceleration and high speed adjustment needles.

  • Page 27: Lubrication

    LUBRICATION Level 1. Tools required: 8 & 13 mm Open End Wrench, Cross Head Screwdriver, Clean rag, Grease gun P/N 91016 Parts Required: ECHO LUBE 8 oz. (P/N 91014) or Lithium Base ® Grease. Gear Housing 1. Clean all loose debris from gear box.

  • Page 28: Sharpening Metal Blades

    SHARPENING METAL BLADES Three styles of metal blades are approved for use on the ECHO Brush Cutter. The 8-tooth blade can be sharpened during normal maintenance. The clearing blade and 80 tooth blade require professional service. Before sharpening, CLOSELY inspect blade for cracks (look at the bottom of each tooth and the center mounting hole closely), missing teeth and bending.

  • Page 29: Troubleshooting

    ROUBLESHOOTING i l y s t r t ' n t l i f t l i f y l r i l o Fuel vapors are extremely flammable and may cause fire and/or explosion. Never test for ignition spark near an open spark plug opening, otherwise serious personal injury may result.

  • Page 30: Storage

    TORAGE During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious property damage or personal injury may result. Long Term Storage (over 30 days) Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage mainte- nance which includes the following: 1.
  • Page 31 RASS RIMMER RUSH UTTER PERATOR ANUAL NOTES...

  • Page 32: Servicing Information

    • Purchasing from your Echo Dealer. • Manuals are available by sending a written request stating the model number and serial number of your Echo unit, part number of the manual, your name and address, and mail to the address below.
  • Page 33 When selecting optional Blade Conversion Kits (99944200411, 99944200415) or Combination Blade/U-Handle Kits (99944200451, 99944200521), only use kits with this label attached. This kit has been modified for installation on all Echo SRM-210 and SRM-211 Trimmers. Models listed on this label must use this kit for proper blade retention.
  • Page 34 Si necesita asistencia o tiene dudas referentes a la aplicación, operación o mantenimiento de este producto puede llamar al Departamento de asistencia de productos del consumidor de ECHO, 1-800-673-1558 de 8:30 de la mañana a 4:30 de la tarde (hora central estándar) de lunes a viernes. Antes de llamar, tenga a mano el número de modelo y serie de su unidad para ayudar a su representante de asistencia de productos del consumidor.

This manual is also suitable for:

Srm-211i
