TGA939BX(e).fm Page 1 Thursday, October 29, 2009 11:23 AM
Thank you for purchasing a Panasonic product.
This unit is an additional handset compatible with the following
Panasonic Digital Cordless Phone: KX-TG9385
You must register this handset with your base unit before it can
be used. This installation manual describes only the steps
needed to register and begin using the handset. Please read
the base unit's operating instructions for further details.
Charge the batteries for about 7 hours before initial use.
Please read this installation manual before using the unit and
save it for future reference.
Installation Manual
Additional Digital Cordless Handset
KX-TGA939BX
Model No.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TGA939BX

Summary of Contents for Panasonic KX-TGA939BX

  • Page 1 Additional Digital Cordless Handset KX-TGA939BX Model No. Thank you for purchasing a Panasonic product. This unit is an additional handset compatible with the following Panasonic Digital Cordless Phone: KX-TG9385 You must register this handset with your base unit before it can be used.

  • Page 2: Supplied Accessories

    (100-240 V AC, 50/60 Hz) Hooks Note: L Use only the supplied Panasonic AC adaptor PQLV219BX. L The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) – 2 –...
  • Page 3 L When replacing the batteries: – USE ONLY rechargeable Ni-MH batteries AAA (R03) size. – Do NOT use Alkaline/Manganese/Ni-Cd batteries. – We recommend using the Panasonic rechargeable batteries noted in the base unit’s operating instructions for replacement battery information. Press the notch on the handset cover firmly, and slide it in the direction of the arrow.

  • Page 4: Registering A Handset To The Base Unit

    TGA939BX(e).fm Page 4 Thursday, October 29, 2009 11:23 AM Registering a handset to the base unit Handset: Lift the handset and press {OFF}. Base unit: Press and hold {LOCATOR} for about 5 seconds until the registration tone sounds. L If all registered handsets start ringing, press the same button to stop.

  • Page 5: Wall Mounting

    TGA939BX(e).fm Page 5 Thursday, October 29, 2009 11:23 AM Wall mounting Drive the screws (not supplied) into the wall. Mount the charger (A), then slide it down (B) and to the right (C) until it is secure. 25 mm Screws (100-240 V AC, 50/60 Hz) Belt clip N To attach...

  • Page 6: For Your Safety

    TGA939BX(e).fm Page 6 Thursday, October 29, 2009 11:23 AM For your safety To prevent severe injury and loss of life/property, read this section carefully before using the product to ensure proper and safe operation of your product. WARNING Power connection L Completely insert the AC adaptor/power plug into the power outlet.

  • Page 7: Other Information

    TGA939BX(e).fm Page 7 Thursday, October 29, 2009 11:23 AM Battery L We recommend using the supplied batteries or additional/replacement batteries noted in the base unit’s operating instructions for replacement battery information. USE ONLY rechargeable Ni-MH batteries AAA (R03) size. L Do not mix old and new batteries. L Do not open or mutilate the batteries.
  • Page 8 This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd. © Panasonic Communications Co., Ltd. 2009...
