TGA910E(e).fm Page 1 Thursday, July 20, 2006 2:32 PM
This unit is an additional handset for use with the
following Panasonic Digital Cordless Phones:
KX-TG9120/KX-TG9140/KX-TG9150
You must register this unit to your base unit before it can
be used.
Please refer to your base unit's operating instructions for
further details.
Charge the batteries for about 7 hours before initial use.
Please read this installation manual before using the unit and
save it for future reference.
Additional Digital Cordless Handset
Installation Manual
KX-TGA910E
Model No.
Advertisement
Table of Contents
Related Manuals for Panasonic KX-TGA910E
Summary of Contents for Panasonic KX-TGA910E
- Page 1 Installation Manual KX-TGA910E Model No. This unit is an additional handset for use with the following Panasonic Digital Cordless Phones: KX-TG9120/KX-TG9140/KX-TG9150 You must register this unit to your base unit before it can be used. Please refer to your base unit’s operating instructions for further details.
- Page 2 TGA910E(e).fm Page 2 Thursday, July 20, 2006 2:32 PM Preparation Thank you for purchasing a new Panasonic digital cordless phone. Sales and support information Customer Care Centre • For customers within the UK: 08700 100 076 • For customers within the Republic of Ireland: 01289 8333 •...
-
Page 3: Included Accessories
TGA910E(e).fm Page 3 Thursday, July 20, 2006 2:32 PM Preparation Included accessories Charger Part No. PQLV30045Z AC adaptor Part No. PQLV209EZ (PQLV209E) Rechargeable batteries Handset cover Belt clip AAA (R03) size Part No. Part No. Part No. HHR-4EPT PQYNTG9120E PQKE10456Z1 Important information General •... - Page 4 TGA910E(e).fm Page 4 Thursday, July 20, 2006 2:32 PM Preparation Environment • Do not use this product near water. • This product should be kept away from heat sources such as radiators, cookers, etc. It should also not be placed in rooms where the temperature is less than 5 °C or greater than 40 °C.
-
Page 5: Information On Disposal For Users Of Waste Electrical & Electronic Equipment (Private Households)
TGA910E(e).fm Page 5 Thursday, July 20, 2006 2:32 PM Preparation Information on Disposal for Users of Waste Electrical & Electronic Equipment (private households) This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to designated collection points, where they will be accepted on a free of charge basis. -
Page 6: Battery Installation/Replacement
Important: • Use only the included rechargeable batteries noted on page 3, 4. • When replacing batteries, we recommend using the Panasonic rechargeable batteries noted on page 2, 4. • Wipe the battery ends (S, T) with a dry cloth. -
Page 7: Battery Charge
TGA910E(e).fm Page 7 Thursday, July 20, 2006 2:32 PM Preparation Insert the batteries negative (T) end first. Close the handset cover. Battery charge Place the handset on the charger for about 7 hours before initial use. • While charging, the charge indicator on the handset lights in amber. When the batteries are fully charged, the charge indicator lights in green. -
Page 8: Wall Mounting
TGA910E(e).fm Page 8 Thursday, July 20, 2006 2:32 PM Preparation Wall-mounting 25 mm Screws Hooks Note: • Make sure the screws are securely fastened to the wall. • Use the following wall template to position the screws before drilling. 25 mm Helpline Tel. - Page 9 TGA910E(e).fm Page 9 Thursday, July 20, 2006 2:32 PM Preparation Registering the handset to the KX-TG9120/ KX-TG9140/KX-TG9150 base unit Ensure that the handset is switched on. If it is not on, press and hold {ih} for few seconds to turn the handset on. Lift the handset and press {ih} to put the handset in standby mode.
- Page 10 TGA910E(e).fm Page 10 Thursday, July 20, 2006 2:32 PM Declaration of Conformity: • Panasonic Communications Co., Ltd. declares that this equipment is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC.
- Page 11 TGA910E(e).fm Page 11 Thursday, July 20, 2006 2:32 PM...
- Page 12 3 Ping Xi 8 Lu, Nanping Keji Gongye Yuan, Zhuhai, Guangdong, China 519060 Copyright: This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd.
