Luxaire ACCLIMATE AL6B024F3 Technical Manual

TECHNICAL GUIDE
TM
ACCLIMATE
SPLIT-SYSTEM AIR CONDITIONERS
16 SEER – R-410A
MODELS:
AL6B024 THRU 060
(2 THRU 5 NOMINAL TONS )
Due to continuous product improvement,
specifications are subject to change without notice.
Visit us on the web at
www.upgnet.com and www.luxaire.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY
Standard 5-year limited parts warranty.
10-year limited compressor warranty.
Premium System Warranty - Limited lifetime compressor
when matched with an approved Johnson Controls Unitary
Products premium furnace and coil or premium air handler.
Extended 10-year limited parts warranty when product is
registered online within 90 days of purchase for replace-
ment or closing for new home construction.
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
The 16 SEER Series unit is the outdoor part of a versatile cli-
mate system. It is designed with a matching indoor coil compo-
nent from Johnson Controls Unitary Products. Available for
typical applications, this climate system is supported with
accessories and documents to serve specific functions.
FEATURES
• Superior Coil Protection – A decorative, stamped metal coil
guard completely protects coil from debris and other large
damaging material.
• Isolated Compressor Compartment – A molded composite
bulkhead isolates the compressor from the rest of the unit,
reducing sound and vibration.
• Protected Compressors – Each compressor is protected
against abnormal pressures by an internal pressure relief
valve and factory installed high and low pressure controls.
Additional protection against moisture and debris is provided
by factory installed liquid line filter driers.
• Environmentally Friendly Refrigerant – Next generation
refrigerant R-410A delivers environmentally friendly perfor-
mance with zero ozone depletion.
• Durable Finish – Automotive quality finish provides the ulti-
mate protection from harmful U.V. rays and rust creep,
ensuring long-lasting, high quality appearance. A powder-
paint topcoat is applied over a baked-on primer, using a gal-
vanized, zinc coated steel base material. The result is a fin-
ish that has been proven in testing to provide 33% greater
durability than conventional powder-coat finishes.
• Lower Installed Cost – Designed to provide enhanced
installability by featuring a slide-down control compartment
and angled service valves to reduce overall installation time
and cost.
• Low Operating Sound Levels – A fan design boasting tech-
nology adapted from aeronautic and defense engineering
provides for whisper quiet operation by allowing airflow to
flow smoothly and efficiently across the fan tips.
• Filter-Drier – A factory installed, solid core liquid line filter-
drier filters harmful debris and moisture from the system.
• Easy Service Access – A full end, full service, access panel
with handle makes for easy entry to internal components.
• Composite Base - Strong and durable composite base pan
resists rust and corrosion while it helps reduce vibrations and
noise.
TM
• SilentDrive System - Features combination of swept-
wing fan, composite base pan, isolated compressor compart-
ment, and single-stage compressor to reduce overall sound
to a mere whisper.
• Low RPM fan motor - Helps to reduce airflow noise.
• Communications Capable – Requiring only a simple 4-wire
installation, the communicating capability enables the use of
the Touch Screen Communicating Control, allowing real time
visibility of system operation and the use of diagnostic fea-
tures, while still maintaining the ability to function with a tradi-
tional thermostat.
• Agency Listed - U.L. and C.U.L. listed - approved for out-
door application. The unit is certified in accordance with the
Unitary Small Equipment certification program, which is
based on AHRI Standard 210/240.
567177-LTG-D-1211
