User Manual
Pro Install Hands-Free Vehicle Kit for
The SONIM AT & T Phone
Available with cradle
with and without phone locking device

Advertisement

loading
Need help?

Need help?

Do you have a question about the Hands free and is the answer not in the manual?

Questions and answers

Summary of Contents for AdvanceTec Hands free

  • Page 1 User Manual Pro Install Hands-Free Vehicle Kit for The SONIM AT & T Phone Available with cradle with and without phone locking device...
  • Page 2: Call Waiting

     Vehicle Hands-free Kit Part # ATT6301A consists of the SONIM custom Hands-free cradle  Vehicle Hands-free Kit Part # ATT6302A consists of the SONIM custom Hands-free cradle WITH phone lock and: 1. Part # AT8231A Speaker 2. Part # AT8262A Junction Box 3.
  • Page 3 Hands‐free Installation    Before beginning the installation process, determine the best locations for  the  mounting  of  the  Mounting  Bracket,  Hand‐free  Cradle,  Push‐To‐Talk  (PTT) button, Visor Microphone, Speaker and Junction Box.    Consider the following guideline when planning the installation:   DO use all mounting hardware provided.   DO ensure that cables are not placed under stress.   DO follow proper + and ‐ connections.   DO crimp connectors securely.   DO NOT attach components to any part of the Car that is not rigid  or is subject to excessive vibration.   DO NOT install components in areas where rain or snow can easily  get  into  them,  such  as  next  to  a  Car  window,  which  may  be  left  open. ...
  • Page 4     2. The Speaker should be located more than four feet from the junction  box.  3. The Speaker includes a mounting bracket, permitting it to be mounted  in a variety of ways. Loosen the thumbscrews on the side of the speaker  and  using  the  mounting  bracket  as  a  template,  drill  the  necessary  mounting  holes  and  secure  the  bracket  with  the  self‐tapping  screws  provided.  Mounting Bracket Thumb Screws          Diagram 1    4.    Position  the  Speaker  on  the  mounting  bracket  and  secure  it  by  tightening ...
  • Page 5    Facing the driver        Diagram 2    3.    The  visor  microphone  has  a  noise  canceling  feature  and  must  be  mounted facing the driver as shown in the picture above.                  4.  To  avoid  visual  or  physical  obstruction,  route  the  microphone  cable  down  inside  the  door  molding.  Allow  sufficient  slack  on  the  connector  end of the cable to reach the Junction Box. ...
  • Page 6   Remove the strips and replace the small plastic part that held the strips  in place with the larger flat plastic part supplied with the PTT. Screw the  new plastic part in place.  3. Feed the cable out of sight to the location where you intend to mount  the junction box.  Caution:  Make sure there is sufficient slack in the cable to allow the free  movement of the gear lever without stretching the PTT cable.    D. Installing the Power Cable  Caution!  The  Car  kit  should  be  used  with  a  negative  ground  electrical  system  only.  Reverse  polarity  (positive  ground)  will  trigger  protection  circuits  which  cause  the  cable  fuse  to  open.  Check  the  ground  polarity  before you begin the installation to prevent wasted time and effort. 12V ...
  • Page 7   4.  If  the  connection  is  being  made  under  the  dash  or  in  the  Car  cabin,  connect the black lead directly to the chassis of the Car.  5.  If  the  connection  is  being  made  in  the  engine  compartment,  connect  the in‐line fuse holder between the black lead of the power cable and the  desired chassis connection point.    Note! Do not connect the black lead to the negative (‐) battery terminal.   The  Car  Kit  could  be  damaged  if  there  were  a  malfunction  in  the  Car’s  electrical system.  ...
  • Page 8   Connecting cables to Junction Box.  1. Locate  a  position  for  the junction box beneath  the dashboard  on  the  passenger's side of the Car or on the center side post between the front  seats.    It  must  be  protected  from  dirt  and  moisture  and  must  be  afforded  adequate  space  for  cooling.  There  must  be  sufficient  space  to  allow  for  connection of all cabling.  2.  DO  NOT  mount  the  junction  box  at  this  stage.  First  connect  the  Microphone, ...
  • Page 9   NOTE: 2.   When inserting the connector ensure that the round corners of  the connector line up with the round corners of the receptacle on the  phone (situated on the lower part of the phone)   Rounded corners to line up with    rounded corners of  connector  Squared corners to line up with    squared corners of  connector    Diagram 9    Inserting and removing the handset  from cradle    3.  Insert  the  bottom  of  the  handset  behind  the  ridge  on  the  cradle  and  press the top of the handset back into the Cradle until it snaps into place.    Press button on top  Insert side   of cradle to release  audio cable  phone ...
  • Page 10     4. Turn the Handset on.  5.  To  remove  the  handset  from  the  Cradle,  press  the  release  button  on   the top of the cradle.  The Handset will snap forward out of the cradle.     Car Ignition connection  1.  When  the  Car  ignition  is  ON,  the  Car  Kit  will  stay  on  as  long  as  the  cables are inserted into both sides on the handset.   2.  When  the  ignition  is  turned  OFF  the  Car  Kit  will  turn  OFF  after  60  minutes.  ...
  • Page 11: Optional Extras

        Charging the battery  1. With the handset turned off, the Car kit will charge the battery to 60%  in approximately 1 hour. The charge time will be longer if the handset is  operational during charge time.  2.  For  operator  convenience,  the  handset’s  backlight  will  remain  on  for  ease of viewing during low/no‐light conditions.    NOTE!  Batteries will charge within the temperature window of ‐10 C to  +40 C (50 F to 104 F). If the battery is outside the temperature window,  no charge current will be supplied to the battery.    Operating Specifications  Input voltage range:  11V dc to 32V dc  Operating ambient:  ‐30C to +60 C      Optional Extras                        ATT7107A – Handset with Cradle           Part # ATT7107A – Privacy Handset with Cradle  1.  To use the Privacy Handset, plug the connector on the end of the coil  cord into the corresponding RJ45 receptacle on the Junction Box.  See  Diagram 6 above  2. An active call can be terminated and an incoming call can be rejected  by pressing the PTT button on the back of the Privacy handset for more  than 2 seconds.   ...
  • Page 12 Palm  Mic.  into  the  corresponding  RJ45  receptacle  on  Junction  Box.  See Diagram 6 above.    2.  Once  connected,  the  pressing  of  the  switch  on  the  Palm  Mic.  will  deactivate the Visor Mic. and activate the Palm Mic.                                                                                      1150 NW 163  Drive, Miami, FL 33169  T: 305-623-3939 F: 305-623-3996 www.advancetec.com www.advanceMobileGPS.com...
