User Manual
Pro Install Hands-Free Car Kit for
Verizon® V860 - BARRAGE
Car Kit Part # AT6810A consists of:
1. Part # AT8231A
2. Part # AT8255A
3. Part # AT8230A
4. Part # AT8232A
5. Part # AT9299B
6. Part # AT6312A
Optional Extras
2. Part #AT7107A
4. Part # AT8410A
Before beginning the installation process, determine the best locations for the
mounting of the Mounting Bracket, Hand-free Cradle, Push To Talk (PTT) button, Visor
Microphone, Speaker and Junction Box.
Speaker
Junction Box
Visor Microphone.
Power cable
PTT
V860 Hands-free cradle
Privacy Handset
Palm Mic.
Advertisement
Table of Contents
Related Manuals for AdvanceTec Verizon V860 - BARRAGE
Summary of Contents for AdvanceTec Verizon V860 - BARRAGE
- Page 1 User Manual Pro Install Hands-Free Car Kit for Verizon® V860 - BARRAGE Car Kit Part # AT6810A consists of: 1. Part # AT8231A Speaker 2. Part # AT8255A Junction Box 3. Part # AT8230A Visor Microphone. 4. Part # AT8232A Power cable 5.
- Page 2 Consider the following guideline when planning the installation: • DO use all mounting hardware provided. • DO ensure that cables are not placed under stress. • DO follow proper + and - connections. • DO crimp connectors securely. • DO NOT attach components to any part of the vehicle that is not rigid or is subject to excessive vibration.
- Page 3 2. Position the Speaker on the mounting bracket and secure it by tightening the thumbscrews. The mounting bracket is used to permanently mount the Speaker in place while permitting it to be tilted to a desired angle. Diagram 1 Installation 1.
- Page 4 Installing the Power Cable 1. Route the black lead of the main power cable to convenient chassis ground and the red lead to the positive supply voltage connection points. If it is necessary to penetrate the firewall, use an existing opening. 2.
- Page 5 2. Position the antenna, maintaining a separation distance of at least 8 inches (20 cms) between the antenna and the body of any user and nearby person, to assure compliance with the U. S. FCC regulations on RF exposure. 3. Connect the coaxial antenna cable connector to the antenna cable connector from the Clam Cradle Mounting of the PTT - To the gear lever or flat surface 1.
- Page 6 2. To avoid visual or physical obstruction, route the microphone cable down inside the door molding. Allow sufficient slack in the connector end of the cable to reach the Junction Box. 3. Plug the connector side of the external microphone cord into the Junction Box as shown in diagram 3 above Note! The microphone should not be mounted near a window or in a spot where road and ambient background noise would be substantially high...
- Page 7 5. To remove the handset from the Cradle, press the release button on the top of the cradle. Car Kit Operating Procedure Car Ignition connection 1. When the car ignition is ON, the Car Kit will stay on as long as the cables are inserted into both sides on the handset.
- Page 8 Part # AT7107A – Privacy Handset with Cradle 1. To use the Privacy Handset, plug the connector on the end of the coil cord into the corresponding receptacle on the Junction Box. See Diagram 3 2. An active call can be terminated and an incoming call can be rejected by pressing the PTT button on the Privacy handset for more than 2 seconds.
