The AdvanceTec Hands-free car kit is designed for use with all
AdvanceTec car kit cradles as well as all Motorola® OEM car kit
cradles for safe and convenient vehicular operation.
The Car Kit (AT6538A) includes:
1. Part # AT8231A
2. Part # AT8240A
2. Part # AT8230A
3. Part # AT8232A
4. Part # AT9299A
5. Part # AT8219A
Optional Extras
1. Part #AT7107A
2. Part # HMN4058A
! Note
1. A separate car kit cradle compatible with your mobile must be
purchased for use with this hands-free car kit.
2. If the car kit purchased is Part # AT6537A, Part # AT8219A, adapter
cable for Motorola OEM cradle is not included.
If this car kit is to be used with a Motorola® OEM car kit cradle it
will be necessary to utilize the AdvanceTec Part # AT8219A
adaptor cable (if included or purchased separately, if not
included) to connect the car kit to the Motorola® OEM cradle.
The adaptor cable is NOT required to connect the car kit to an
AdvanceTec car kit cradle.
A properly installed Hands-free Car Kit will minimize service calls and
equipment downtime. Because of the wide variations in vehicle design,
these instructions should be modified to suit each particular installation.
Before beginning the installation process, determine the locations for the
mounting of the Mounting Bracket, Clam Cradle, Push To Talk (PTT)
button, Visor Microphone, Speaker and Junction Box.
Consider the following guideline when planning the installation:
* DO use all mounting hardware provided.
* DO ensure that cables are not placed under stress.
* DO follow proper + and - connections.
* DO crimp connectors securely.
* DO NOT attach components to any part of the vehicle that is not rigid or
is subject to excessive vibration.
* DO NOT install components in areas where rain or snow can easily get
into them, such as next to a vehicle window, which may be left open.
Speaker
Junction Box
Visor Microphone
Power cable
PTT Control
Adapter Cable for Motorola Cradles
Privacy Handset
Potato Mic.
Advertisement
Table of Contents
Related Manuals for AdvanceTec AT6538A
Summary of Contents for AdvanceTec AT6538A
- Page 1 The AdvanceTec Hands-free car kit is designed for use with all AdvanceTec car kit cradles as well as all Motorola® OEM car kit cradles for safe and convenient vehicular operation. The Car Kit (AT6538A) includes: 1. Part # AT8231A Speaker 2.
- Page 2 * DO NOT dress cables over sharp edges that could cause wear or tearing of cable insulation. * DO NOT install components in locations where they might interfere with the vehicle operator or operating controls. * DO NOT install the Hands-free Cradle where it will be difficult for the operator to reach.
- Page 3 Diagram 2 2. Connect the Cradle Control Cable, (use the AdvanceTec connector cable referred to on page 1 of these instructions if a Motorola® OEM cradle is being used), the Speaker, Microphone, Power cable and the PTT connectors to their respective corresponding connectors in the Junction Box, as shown in Diagram 3 below.
- Page 4 The Hands-free unit should be used with a negative ground system only Junction Box Volume Switch 1. The speaker audio is preset for the AdvanceTec cradles and most of the Motorola® OEM cradles. 2. If the speaker audio is too low (in particular when used with the Motorola®...
- Page 5 lead of the power cable and the desired positive voltage connection point. 8. Route and connect the green lead to a convenient ignition switch supply point in the vehicle. Diagram 5 Stereo Mute If the vehicle’s stereo system supports an external muting feature, route and connects the orange wire to the car stereo system.
- Page 6 Inserting and removing handset from cradle In most instances the following instructions can be used with an AdvanceTec cradle. If not applicable, contact AdvanceTec direct for assistance. If you are using a Motorola® OEM cradle, follow the instructions supplied with that cradle.
- Page 7 2. Press the top of the handset back into the Cradle until the catch mechanism snaps into place, securing the handset in the Cradle. 3. Turn the Handset on. Diagram 9 - Removing handset from Clam Cradle 1. To remove the handset from the Cradle, press the release button which will be located on the side or the top of the cradle.
- Page 8 2. Incoming calls can be answered by lifting the Privacy handset 3. Call can be terminated by placing the Privacy handset into its cradle 4. An active call can be terminated and an incoming call can be rejected by pressing the PTT button on the Privacy handset for more than 2 seconds.
