WELCOME Thank you for choosing an RCZ, a symbol of confi dence, passion and inspiration. WARNING: This handbook has been designed to enable you to make the most of your vehicle in all situations. this symbol marks warnings which it is essential to observe for Therefore, on the fi...
Monochrome screen C (PEUGEOT Connect Sound (RD5)) PEUGEOT Connect Sound (RD5)) PEUGEOT Warning and indicator lamps Clock Retractable colour screen (PEUGEOT Connect Navigation (RT6)) Indicators Trip computer Retractable colour screen (PEUGEOT Connect Media Navigation (NG4 3D)) ACCESS 51-63 Remote control key Electric windows Boot Alarm Doors...
Page 5
Weights (petrol) Weights (Diesel) Identification markings AUDIO EQUIPMENT and TELEMATICS 207-328 Emergency or assistance PEUGEOT Connect Navigation (RT6) PEUGEOT Connect Media Navigation (NG4 3D) PEUGEOT Connect Media Navigation (NG4 3D) PEUGEOT PEUGEOT Connect Sound (RD5) ALPHABETICAL INDEX 329-333 VISUAL SEARCH...
Page 6
EXTERIOR 1. Welcome lighting This additional exterior and interior lighting, controlled remotely, makes your approach to the vehicle easier when the light is poor. 2. Directional lighting This lighting automatically provides additional visibility when cornering. 3. Spoiler 4. Front and rear parking 5.
ACCESS REMOTE CONTROL KEY WELCOME LIGHTING Normal locking (press once; fi xed lighting of the direction indicators). When poor light is detected by a sensor, the remote switching on of the dipped beam headlamps and sidelamps makes your approach to the vehicle easier. Deadlocking the vehicle (press twice in succession;...
BOOT FUEL TANK Vehicle locked 1. Unlocking and partial opening of the boot lid. 2. Open the boot lid. For access to the fuel fi ller cap, the vehicle must be unlocked. 1. Open the fuel fi ller fl ap by pressing at its rear edge. Vehicle unlocked 2.
Page 9
2. Audio and telematic systems This equipment benefi ts from the latest technology: MP3 compatible PEUGEOT Connect Sound (RD5), PEUGEOT Connect Navigation (RT6) or PEUGEOT Connect Media Navigation (NG4 3D) with 16/9 retractable colour screen, JBL audio system, auxiliary sockets.
INSTRUMENTS AND CONTROLS 1. Cruise control / speed limiter switches. 2. Steering wheel adjustment control. 3. Lighting and direction indicator control stalk. 4. Instrument panel. 5. Driver's airbag. Horn. 6. Gear lever. 7. Parking brake. 8. Bonnet release. 9. Fusebox. 10.
Page 11
INSTRUMENTS AND CONTROLS 1. Wipers / screenwash / trip computer control stalk. 2. Steering lock and ignition. 3. Audio and telematics system steering wheel control stalk. 4. Door mirror controls. Electric window controls. 5. Central adjustable air vents. 6. Windscreen demisting vent. 7.
SITTING COMFORTABLY FRONT SEATS STEERING WHEEL ADJUSTMENT FRONT ARMREST Other functions available... 1. Release the adjustment mechanism. 2. Adjust for height and reach. Lumbar adjustment. 3. Lock the adjustment mechanism. As a safety precaution, these Heated seats. operations must only be carried out when stationary.
SITTING COMFORTABLY DOOR MIRRORS REAR VIEW MIRROR FRONT SEAT BELTS Automatic day/night model A. Automatic "day/night" mode light detector. B. Adjustment of the mirror. Adjustment A. Selection of the mirror to be adjusted. B. Adjustment of the position of the mirror in the four directions.
SEEING CLEARLY LIGHTING DIRECTION INDICATORS WINDSCREEN WIPERS Fast wipe. Normal wipe. Intermittent wipe. Park. AUTO Automatic wipe or single wipe. Wash-wipe: pull the stalk towards you. Ring A Raise or lower the lighting stalk passing the point of resistance; the corresponding Lighting off.
"OK" or "correct", depending on version, for a few seconds. E. Deactivation of the front and rear parking If the levels are not correct, top up the levels sensors. which are low. Access to PEUGEOT services. 208, 209...
PASSENGER SAFETY STARTING PASSENGER'S FRONT AIRBAG SEAT BELTS AND IGNITION SWITCH PASSENGER'S FRONT AIRBAG A. Front and/or rear seat belts not fastened / 1. Stop position. Selection of the position: unfastened warning lamp. "OFF" (deactivated), with "rearward 2. Running position. B.
AT THE REAR ACCESS TO THE REAR SEATS REAR SEAT BELTS FOLDING DOWN THE REAR BACKREST 1. Release the backrest by pulling the handle from the boot. 1. Releasing the backrest. 2. Tilting the backrest. The control giving access to the rear seats does not release the seat.
DRIVING SAFELY CRUISE CONTROL "CRUISE" DISPLAY IN THE INSTRUMENT SPEED LIMITER "LIMIT" PANEL 1. Limiter mode Selection / Off. 1. Cruise control mode Selection / Off. The cruise control or speed limiter mode 2. Decrease the programmed value. 2. Programme a speed / Decrease the appears in the instrument panel when it is programmed value.
Page 22
ECO-DRIVING Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO emissions. OPTIMISE THE USE OF YOUR GEARBOX CONTROL THE USE OF YOUR ELECTRICAL EQUIPMENT With a manual gearbox, move off gently and change up without Before moving off, if the passenger compartment is too warm, ventilate it waiting.
Page 23
LIMIT THE CAUSES OF EXCESS OBSERVE THE RECOMMENDATIONS ON CONSUMPTION MAINTENANCE Spread loads throughout the vehicle; place the heaviest items in the Check the tyre pressures regularly, when cold, referring to the label in bottom of the boot, as close as possible to the rear seats. the door aperture, driver's side.
PETROL - DIESEL MANUAL Panel grouping together the vehicle operation indication dials and warning lamps, with permanent back-lighting. OR AUTOMATIC GEARBOX DIALS INSTRUMENT PANELS 1. Rev counter. With small central display screen Indicates the speed of rotation of the engine (x 1 000 rpm). 2.
Vehicle parameters *** . Navigation - Guidance *** . These functions are displayed according to the selection. * According to engine. ** Only on the large central display screen. *** Only on the large central display screen with PEUGEOT Connect Media (NG4 3D).
Page 26
INSTRUMENT PANEL NAVIGATOR WITH THE LARGE CENTRAL DISPLAY SCREEN AND PEUGEOT CONNECT MEDIA NAVIGATION (NG4 3D) The main menu and its associated functions can only be accessed when stationary , via buttons 1 to 4 . A message appears on the central screen, above a certain speed This group of buttons permits: threshold, indicating that the main menu cannot be displayed.
Page 27
Vehicle parameters * This menu allows you to activate or deactivate certain driving and comfort equipment: vehicle speed repeat, selective unlocking (refer to the "Access" section), guide-me-home lighting (refer to the "Visibility" section), interior mood lighting (refer to the "Ease of use and comfort" section), daytime running lamps ** (refer to the "Visibility"...
The illumination of a warning lamp is always accompanied by the display of an additional message, to assist you in identifying the fault. If you encounter any problems, contact a PEUGEOT dealer or a qualifi ed workshop.
Page 29
You must stop as soon as it is safe to do so. The electronic brake force with the STOP distribution (EBFD) system has Have it checked by a PEUGEOT dealer or a qualifi ed and ABS warning a fault. workshop.
Page 30
The warning lamp should go off when the engine is started. system The emission control system has fi xed. If it does not go off, contact a PEUGEOT dealer or qualifi ed a fault. workshop without delay. Refuel as soon as possible to avoid running out of fuel.
Page 31
(DSC/ASR) The DSC/ASR system has a fi xed. Have it checked by a PEUGEOT or a qualifi ed workshop. fault. Directional The directional headlamps Have it checked by a PEUGEOT dealer or a qualifi ed fl ashing.
Page 32
Operation indicator lamps If one of the following indicator lamps comes on, this confi rms that the corresponding system has come into operation. It may be accompanied by an audible signal. Depending on your version of instrument panel, illumination of the indicator lamp may also be accompanied by: a symbol in the central instrument panel screen and a message in the multifunction screen,...
Warning lamp is on Cause Action / Observations Turn the ring on the stalk rearwards to switch off the rear Rear foglamp fi xed. The rear foglamp is switched on. foglamp. Wait until the warning lamp has switched off before starting. Diesel engine The ignition switch is at the fi...
Page 34
Deactivation warning lamps If one of the following warning lamps comes on, this confi rms that the corresponding system has been switched off intentionally. It is accompanied by an audible signal and a message on the screen. Depending on your version of instrument panel, illumination of the deactivation lamp is also accompanied by: a symbol in the central instrument panel screen and a message in the multifunction screen,...
Wait a few minutes before switching off the engine. Contact a PEUGEOT dealer or a qualifi ed workshop. The check of this level is only valid if the vehicle is on a level...
Page 36
This is indicated by the fl ashing of "OIL--" or the appearance of an alert message in the instrument panel. Lack of oil Contact a PEUGEOT dealer or a qualifi ed workshop. In the event of a fault with the electric gauge, the oil level is no longer monitored.
SERVICE INDICATOR Less than 600 miles (1 000 km) remain before the next service is due Example: 500 miles remain before the next service is due. This information is displayed for a few seconds when the ignition is For 7 seconds after the ignition is switched on, the central screen switched on.
Service overdue Service indicator zero reset For 7 seconds after the ignition is switched on, the spanner fl ashes to indicate that the service must be carried out as soon as possible. Example: the service is overdue by 300 miles. For 7 seconds after the ignition is switched on, the central screen indicates: After each service, the service indicator must be reset to zero.
Page 39
If a "major" fault has been detected, only the warning lamps concerned appear in the instrument panel central screen. Have it checked by a With the ignition on, press and hold this button until zeros appear. PEUGEOT dealer or a qualifi ed workshop.
LIGHTING DIMMER CLOCK Permits manual adjustment of the brightness of the instruments and controls to suit the ambient light level. Only operates when the vehicle lighting is on, with the exception of the daytime running lamps. The analogue clock, located between the central vents of the dashboard, does not have an adjustment button.
TRIP COMPUTER DATA DISPLAYS With the small central screen System that gives you information on the journey in progress (range, fuel consumption…). Instrument panel with small central screen Press the button, located at the end of the wiper stalk , to display the various trip computer tabs in succession.
Page 42
TRIP ZERO RESET The current information tab with: ● the range, With the small central screen ● the current fuel consumption. The trip "1" tab with: ● the distance travelled, ● the average fuel consumption, ● the average speed, for the fi rst trip. ...
Page 43
60 miles (100 km). Calculated since the last trip computer reset. If dashes are displayed continuously while driving in place of the digits, contact a PEUGEOT dealer or a qualifi ed workshop. Current fuel consumption (mpg or l/100 km or km/l) Calculated over the last few seconds.
MONOCHROME SCREEN C (WITH CONTROLS PEUGEOT CONNECT SOUND (RD5)) DISPLAYS IN THE SCREEN From the control panel of your PEUGEOT Connect Sound (RD5), you Displays according to context: can: time, press the "MENU" button for access to the main menu , date, ...
" menu. "AUDIO FUNCTIONS" MENU With the PEUGEOT Connect Sound (RD5) switched on, once this menu has been selected you can activate or deactivate the functions linked with use of the radio (RDS, REG, RadioText) or the CD (introscan, ...
Example: setting of the duration of the guide-me-home lighting Press the " " or " " buttons, then the "OK" button to select the menu required. "PERSONALISATION-CONFIGURATION" Press the " " or " " buttons, then the "OK" button to select the MENU "Guide-me-home headlamps"...
Display configuration Once this menu has been selected, you have access to the following settings: With the PEUGEOT Connect Sound (RD5) switched on, once this menu brightness-video setting, has been selected you can confi gure your Bluetooth hands-free system date and time setting, (pairing), consult the various telephone directories (calls log, services...)
RETRACTABLE COLOUR SCREEN (WITH CONTROLS PEUGEOT CONNECT NAVIGATION (RT6)) From the navigation system control panel, to select one of the applications: DISPLAYS IN THE SCREEN press the dedicated "RADIO" , "MUSIC" , "NAV" , "TRAFFIC" , "PHONE" or "SETUP" button for access to the corresponding...
"SETUP" MENU Select the setting to modify. Conform by pressing " OK ", then adjust the setting and modify again. Adjust the settings one by one. Select " OK " in the screen then confi rm to save the setting. Voice synthesis This men allows you to adjust the volume for navigation instructions and to choose the type of voice (male or female).
press the "Back" button to abandon the current operation and satellite navigation system information. return to the previous display. display screen or navigation system parameter settings menus. For more information on these applications, refer to the PEUGEOT Connect Media Navigation (NG4 3D) section.
Date and time For operation of the retractable screen (opening, closing, This menu allows you to set the date and time, the format of the date adjustment of the position, etc.), refer to the "Access to the and the format of the time. retractable screen"...
(unless it had been closed manually while the system was in operation), when an outgoing telephone call is made, when a voice command is given, when a warning message linked with the STOP warning lamp is displayed (PEUGEOT Connect Navigation (RT6)).
REMOTE CONTROL KEY Selective unlocking using the remote control Press the open padlock once to unlock the driver's door System which permits central unlocking or locking of the vehicle using and the fuel fi ller fl ap only. the lock or from a distance. It is also used to locate and start the vehicle, as well as providing protection against theft.
If the alarm had been activated previously, it will not be reactivated automatically. The folding and unfolding of the door mirrors using the remote control can be deactivated by a PEUGEOT dealer or a qualifi ed workshop.
Page 55
First of all, use the key in the lock to unlock or lock your vehicle. direction. Then, reinitialise the remote control. Clip the casing. If the problem persists, contact a PEUGEOT dealer as soon as Reinitialise the remote control. possible.
Do not make any modifi cations to the electronic engine immobiliser system; this could cause malfunctions. WHEN PURCHASING A SECOND-HAND VEHICLE Have the pairing of all of the keys in your possession checked by a PEUGEOT dealer, to ensure that only your keys can be used to open and start the vehicle.
45 seconds at the same time as the interior volumetric and anti-tilt monitoring. Deactivation For all work on the alarm system, contact a PEUGEOT dealer or a qualifi ed workshop. Press the unlocking button on the remote control.
Page 58
LOCKING THE VEHICLE WITH EXTERIOR Deactivation of the interior volumetric and anti-tilt monitoring PERIMETER MONITORING ONLY Switch off the ignition. Within ten seconds, press the button until the indicator lamp is on continuously. Get out of the vehicle. ...
Page 59
When the ignition is in the button indicates a fault with the system. switched on, this fl ashing stops immediately. Have it checked by a PEUGEOT dealer or a qualifi ed workshop. FAILURE OF THE REMOTE CONTROL AUTOMATIC ACTIVATION *...
ELECTRIC WINDOWS The electric window switches remain operational for approximately 45 seconds after the ignition is switched off or until the vehicle is Fitted with a safety anti-pinch system. locked after a door is opened. If the passenger's window cannot be operated from the driver's door control panel, carry out the operation from the control panel of the passenger door.
Page 61
Reinitialisation Always remove the key from the ignition when leaving the vehicle, If a window does not rise automatically, after reconnecting the battery even for a short time. for example, its operation must be reinitialised: If an obstacle is encountered during operation of the electric ...
DOORS From inside OPENING From outside Pull the door control to open the door; this unlocks this vehicle completely. The window lowers automatically by a few millimetres to permit After unlocking the vehicle completely using the remote control or opening of the door.
Page 63
CLOSING CENTRAL LOCKING CONTROL The window rises automatically after a few seconds and adjusts to This control permits simultaneous locking or unlocking of the doors, provide perfect sealing when closed. boot lid and fuel fi ller fl ap from inside the vehicle. Be aware of the risk of pinching when the window rises automatically on closing the door.
ANTI-INTRUSION SECURITY EMERGENCY LOCKING This function permits automatic and simultaneous locking of the doors, To lock or unlock the doors mechanically in the event of a central boot lid and fuel fi ller fl ap as soon as the vehicle speed exceeds 6 mph locking system failure or fl...
BOOT CLOSING Lower the boot lid using one of the interior grab handles. OPENING If necessary, press the top of the boot lid to close it fully. Using the remote control Press this button for more than two seconds to unlock the boot lid.
FRONT SEATS Driver's or passenger's seat height adjustment Seat with integral head restraint, consisting of a seat cushion and a seat back which can be adjusted to adapt your position for ease of driving and comfort. MANUAL ADJUSTMENTS Forwards-backwards adjustment ...
Page 67
FRONT SEATS Seat cushion height adjustment Seat with integral head restraint,consisting of a seat cushion and a seat back which can be adjusted to adapt your position for ease of driving and comfort. The electrical functions of the seat are deactivated approximately one minute after the ignition is switched off.
Page 68
MANUAL LUMBAR ADJUSTMENT Heated seats control Turn the knob manually to obtain the desired level of lumbar With the engine running, the front seats can be heated separately. support. Use the adjustment dial, placed on the side of each front seat, to switch on and select the level of heating required: 0 : Off.
STORING DRIVING POSITIONS RECALLING A STORED POSITION System which takes into account the electrical settings of the driver's Using button 1 or 2 seat and the door mirrors. It enables you to store two positions using Press and hold button 1 or 2 until the audible signal is heard the buttons on the side of the driver's seat.
STEERING WHEEL ADJUSTMENT When stationary , pull the control lever to release the adjustment mechanism. Adjust the height and reach to suit your driving position. Push the control lever to lock the adjustment mechanism. As a safety precaution, these operations should only be carried out with the vehicle stationary.
MIRRORS Adjustment DOOR MIRRORS Move control A to the right or to the left to select the corresponding mirror. Each fi tted with an adjustable mirror glass permitting the lateral Move control B in all four directions to adjust. rearward vision necessary for overtaking or parking.
Page 72
The folding and unfolding of the door mirrors using the remote Exit reverse gear and wait ten seconds. control can be deactivated by a PEUGEOT dealer or a qualifi ed workshop. Return control A to the central position.
REAR VIEW MIRROR In order to ensure optimum visibility during your manoeuvres, the mirror lightens automatically when reverse gear is engaged. Adjustable mirror providing a central rearward view. Equipped with an anti-dazzle system, which darkens the mirror glass and reduces the nuisance to the driver caused by the sun, headlamps from other vehicles...
REAR SEATS Two-seat bench with one-piece fi xed seat cushion and one-piece folding backrest. The rear headrests are fi xed. ACCESS TO THE REAR SEATS Open the boot. Pull the backrest release handle, located under the shelf. Check that the front seat has been moved forward suffi ciently. ...
VENTILATION AIR INTAKE The air circulating in the passenger compartment is fi ltered and originates either from the outside via the grille located at the base of the windscreen or from the inside in air recirculation mode. AIR FLOW PATHS The incoming air follows various routes depending on the controls selected by the driver: direct arrival in the passenger compartment (air intake),...
Page 76
If the system does not produce cold air, switch it off and contact a PEUGEOT dealer or a qualifi ed workshop. When towing the maximum load on a steep gradient in high temperatures, switching off the air conditioning increases the available engine power and so improves towing performance.
DUAL-ZONE DIGITAL When the engine is cold, to prevent too great a distribution of cold AIR CONDITIONING air, the air fl ow will reach its optimum level gradually. In cold weather, it favours the distribution of warm air to the windscreen, side windows and footwells only.
4. Automatic visibility programme 5. Air conditioning On / Off The automatic comfort programme may not be suffi cient to Press this button to switch off the air conditioning. quickly demist or defrost the windscreen and side windows Switching the system off could result in discomfort (humidity, (humidity, several passengers, ice, etc.).
REAR SCREEN DEMIST - 8. Air intake / Air recirculation DEFROST Press this button for recirculation of the interior air. The indicator lamp in the button comes on. The control button is located on the heating or air conditioning system control panel.
COURTESY LAMP It switches off gradually: when the vehicle is locked, when the ignition is switched on, 30 seconds after the last door is closed. Permanently off. Permanent lighting. With the "permanent lighting" mode, the duration of lighting varies, depending on the circumstances: with the ignition off, approximately ten minutes, in energy economy mode, approximately thirty seconds, with the engine running, unlimited.
INTERIOR MOOD LIGHTING INTERIOR WELCOME LIGHTING The dimmed passenger compartment lighting improves visibility in The remote switching on of the passenger compartment lighting the vehicle when the light is poor. makes your entry into the vehicle easier in poor light. It is activated in accordance with the light intensity detected by the brightness sensor.
EXTERIOR WELCOME LIGHTING The remote switching on of the lighting makes your approach to the vehicle easier in poor light. It is activated according to the level of light detected by the sunshine sensor. SWITCHING ON Press the open padlock on the remote control. The dipped beam headlamps and the sidelamps come on;...
INTERIOR FITTINGS 1. Sun visor (see details on following page) 2. Central storage compartment (with PEUGEOT Connect Sound (RD5) ) 3. Storage compartment 4. Illuminated and coolable glove box (see details on following page) 5. Door pockets 6. Illuminated ashtray (see details on following page) 7.
SUN VISOR ILLUMINATED AND COOLABLE GLOBE BOX Component which protects against sunlight from the front or the side, also equipped with an illuminated courtesy mirror. This has areas for storing a bottle of water, the vehicle's handbook pack... With the ignition on, raise the concealing fl ap; the mirror is lit Its lid has areas for storing a pen, a pair of spectacles, tokens, cards, automatically.
Page 85
12 V ACCESSORY SOCKET ILLUMINATED ASHTRAY To connect a 12 V accessory (max power: 120 W), lift the cover Pull the drawer for access to the ashtray. and connect a suitable adaptor. To empty the ashtray, after opening, press the tab and remove the ashtray.
FRONT ARMREST LONGITUDINAL ADJUSTMENT Comfort and storage device for the driver and front passenger. The height and length of the armrest cover can be adjusted. HEIGHT ADJUSTMENT Slide the cover fully forwards or rearwards. STORAGE Raise the cover to the required position (low, intermediate or high). ...
Page 87
If the equipment is connected to the USB port, when it is in use, the portable equipment charges automatically. For more information on the use of this equipment, refer to the PEUGEOT Connect Sound (RD5) or PEUGEOT Connect Navigation (RT6) section.
Page 88
fi xings must be used, never fi t one mat on top of another. The use of mats not approved by PEUGEOT may interfere with access to the pedals and hinder the operation of the cruise control / speed limiter.
STORAGE BOX BOOT LAMPS This has areas for storing a box of spare bulbs, a fi rst aid kit, the Your vehicle is fi tted with two boot lamps; one in the right-hand boot temporary puncture repair kit, a warning triangle, the removable ball side trim and a second in the centre under the rear shelf.
EXTERIOR LIGHTING CONTROLS Control stalk for the selection and control of the various front and rear lamps providing the vehicle's lighting. MAIN LIGHTING SETTINGS The various front and rear lamps of the vehicle are designed to adapt Various automatic lighting control modes are also available depending the driver's visibility progressively in relation to the climatic conditions: on options: sidelamps, to be seen,...
Page 92
MANUAL CONTROLS The lighting is controlled directly by the driver by means of the ring A and the stalk B . Model without AUTO lighting A. Main lighting mode selection ring: turn it to position the symbol required facing the mark. Lighting off / daytime running lamps.
Page 93
C. Foglamp selection ring. In good or rainy weather, both day and night, use of the rear The foglamp operates with the dipped and main beam headlamps. foglamp is prohibited. In these situations, the power of its beam may dazzle other drivers. It should only be used in fog or snow. In these weather conditions, it is your responsibility to switch on the foglamp and dipped beam headlamps manually as the sunshine sensor may detect suffi...
LED LAMPS DAYTIME RUNNING LAMPS Daytime lighting, compulsory in certain countries, which comes on automatically when the engine is started providing better visibility of the vehicle by other road users. In countries in which it is imposed by regulations: by default, this function is activated and cannot be deactivated, the dipped beam headlamps come on, associated with the sidelamps and the number plate lamps.
MANUAL GUIDE-ME-HOME LIGHTING AUTOMATIC ILLUMINATION OF HEADLAMPS The temporary illumination of the dipped beam headlamps after the When a low level of ambient light is detected by a sunshine sensor, the vehicle's ignition has been switched off makes the driver's exit easier number plate lamps, sidelamps and dipped beam headlamps are switched when the light is poor.
Page 96
(lighting control stalk in the " AUTO " position), under low ambient light accompanied by an audible signal. the dipped beams headlamps come on automatically when the ignition Contact a PEUGEOT dealer or a qualifi ed workshop. is switched off. Programming In fog or snow, the sunshine sensor may detect suffi...
Page 97
To avoid dazzling other road users, the height of the halogen bulb Do not touch the xenon headlamp bulbs. headlamps must be adjusted according to the load in the vehicle. Contact a PEUGEOT dealer or a qualifi ed workshop. 0. 1 or 2 people in the front seats. 3 people.
If a fault occurs, this warning lamp fl ashes in the instrument panel, accompanied by a message in the screen. Contact a PEUGEOT dealer or a qualifi ed workshop. When stationary or moving at very low speed or when reverse gear is engaged, the function is inactive.
WIPER CONTROLS Control stalk for the various windscreen wiping modes for clearing rain Model with AUTO wiping and cleaning the windscreen. PROGRAMMING An automatic mode is also available, providing automatic rain sensitive windscreen wipers. MANUAL OPERATION OF THE WINDSCREEN WIPERS This control stalk allows selection of the most suitable wiping speed according to the weather conditions.
Page 100
WINDSCREEN AND HEADLAMP WASH Screenwash/headlamp wash low In the case of vehicles fi tted with headlamp washers, when the minimum level of the reservoir is reached, this warning lamp and/or the service warning lamp is displayed in the instrument panel, accompanied by an audible signal and a message in the screen.
Operating fault If an automatic wiping malfunction occurs, the wipers will operate in intermittent mode. Have it checked by a PEUGEOT dealer or a qualifi ed workshop. Activation Do not cover the rain sensor, linked with the sunshine sensor This is controlled manually by the driver by pushing the stalk and located in the centre of the windscreen behind the rear view downwards to the "AUTO"...
Page 102
SPECIAL POSITION OF THE WINDSCREEN WIPERS This position permits release of the windscreen wiper blades. It is used for cleaning or replacement of the blades. It can also be useful, in winter, to detach the blades from the windscreen. Any action on the wiper stalk in the minute after switching off the ignition places the blades vertically on the screen.
DIRECTION INDICATORS HAZARD WARNING LAMPS A visual warning by means of the direction indicators to alert other road users to a vehicle breakdown, towing or accident. Left: lower the lighting stalk passing the point of resistance. Right: raise the lighting stalk passing the point of resistance. ...
Audible warning to alert other road users to an imminent danger. This system allows you to make an emergency or assistance call to the emergency services or to the dedicated PEUGEOT service. For more information on the use of this function, refer to the "Audio ...
You must stop as soon as it is safe to do so. electronic brake force distribution (EBFD), In either case, contact a PEUGEOT dealer or a qualifi ed workshop. emergency braking assistance (EBA). When replacing wheels (tyres and rims), ensure that they conform ANTI-LOCK BRAKING SYSTEM AND to the manufacturer's recommendations.
TRAJECTORY CONTROL SYSTEMS SNOW DRIVING ASSISTANCE (INTELLIGENT TRACTION CONTROL) Your vehicle has a system to help driving on snow: Intelligent Traction Control. DYNAMIC STABILITY CONTROL (DSC) AND This automatic system continuously checks for situations of diffi cult ANTI-SLIP REGULATION (ASR) surface adhesion that could make it diffi...
Page 107
DSC and ASR, so that the wheels can turn freely and regain grip. Reactivate the systems as soon as the level of grip permits. Contact a PEUGEOT dealer or a qualifi ed workshop to have the system checked. DSC/ASR...
The airbag warning lamp comes on. After deployment, close the bonnet by pressing on the hinges. Go to the nearest PEUGEOT dealer or a qualifi ed workshop at a maximum speed of 20 mph (30 km/h).
ACTIVE SPOILER OPERATION The use of the vehicle must comply with the legislation in force System which improves the aerodynamics and stability of the vehicle in your country. This system can be used to its full potential on a when driving. It can be controlled automatically or manually. closed circuit.
Page 110
It retracts automatically as soon as the vehicle exceeds system is still faulty. this speed threshold. Have it checked by a PEUGEOT dealer or a qualifi ed workshop. In the event of a system operating fault (e.g. jamming of the spoiler), the MAINTENANCE indicator lamp in the control button fl...
Page 111
Only install carrying accessories that are recommended by When pushing the vehicle, do not press on the spoiler as there is PEUGEOT. a risk of damaging it. When washing your vehicle with a high pressure jet-wash, keep...
SEAT BELTS Seat belt not fastened / unfastened warning lamps display FRONT SEAT BELTS The front seat belts are fi tted with a pretensioning and force limiting system. This system improves safety in the front seats in the event of a front or side impact.
Page 113
REAR SEAT BELTS Seat belt unfastened warning lamps display The rear seats are each fi tted with a three-point inertia reel seat belt with force limiter. Fastening 1. Pull the strap and insert the tongue F in the black buckle F , in the centre of the bench seat.
Page 114
PEUGEOT dealer is able to provide. Wherever you are seated in the vehicle, always fasten your seat Have your seat belts checked regularly by a PEUGEOT dealer or a belt, even for short journeys. qualifi ed workshop, particularly if the straps show signs of damage.
AIRBAGS Impact detection zones The airbags have been designed to maximise the safety of the occupants in the event of violent collisions. They supplement the action of the force-limiting seat belts. In this case, the electronic detectors record and analyse the front and side impacts suffered in the impact detection zones: in the event of a serious impact, the airbags are deployed instantaneously and contribute towards protecting the occupants of...
FRONT AIRBAGS Deactivation Only the passenger's front airbag can be deactivated: System which protects the driver and front passenger in the event of a serious front impact in order to limit the risk of injury to the head and with the ignition off , insert the key in the passenger airbag deactivation switch, chest.
If this warning lamp comes on in the instrument panel, accompanied by an audible warning and a message in the screen, contact a PEUGEOT dealer or a qualifi ed workshop to have the system checked. The airbags may no longer be deployed in the event of a serious impact.
Page 118
If this warning lamp comes on on the instrument panel, accompanied by an audible signal and a message in the screen, contact a PEUGEOT dealer or a qualifi ed workshop to have the system checked. The airbags may no longer be Impact detection zones deployed in the event of a violent impact.
Page 119
After an accident or if the vehicle has been stolen or broken into, have the airbag systems checked. All work on the airbag system must be carried out by a PEUGEOT dealer or a qualifi ed workshop. Even if all of the precautions mentioned are observed, a risk of...
GENERAL POINTS RELATING TO CHILD SEATS Although one of PEUGEOT main criteria when designing your vehicle, CHILD SEAT AT THE REAR the safety of your children also depends on you. Only children between 9 and 18 kg can be carried on the rear For maximum safety, please observe the following recommendations: seats in a forward facing universal ISOFIX child seat.
Page 121
CHILD SEAT IN THE FRONT * "FORWARD-FACING" When a "forward-facing" child seat is installed on the front passenger "REARWARD-FACING" seat , adjust the vehicle's seat to the intermediate longitudinal and When a "rearward-facing" child seat is installed on the front passenger highest position with seat backrest straightened and leave the seat , adjust the seat to the intermediate longitudinal and highest passenger's airbag activated.
DEACTIVATING THE PASSENGER'S FRONT AIRBAG Never install a rearward facing child restraint system on a seat protected by an active front airbag. This could cause the death of the child or serious injury. Passenger airbag OFF The warning label present on both sides of the passenger's sun visor repeats this advice.
Page 123
НИКОГА НЕ инсталирайте детско столче на седалка с АКТИВИРАНА предна ВЪЗДУШНА ВЪЗГЛАВНИЦА. Това можеда причини СМЪРТ или СЕРИОЗНО НАРАНЯВАНЕ на детето. NIKDY neumisťujte dětské zádržné zařízení orientované směrem dozadu na sedadlo chráněné AKTIVOVANÝM čelním AIRBAGEM. Hrozí nebezpečí SMRTI DÍTĚTE nebo VÁŽNÉHO ZRANĚNÍ. Brug aldrig en bagudvendt barnestol på...
Page 124
Qatt m’ghandek thalli tifel/tifl a marbut f’siggu dahru lejn l-Airbag attiva, ghaliex tista’ tikkawza korriment serju jew anke mewt lit-tifel/tifl a Plaats NOOIT een kinderzitje met de rug in de rijrichting op een zitplaats waarvan de AIRBAG is INGESCHAKELD. Bij het afgaan van de airbag kan het KIND ERNSTIG OF DODELIJK GEWOND raken.
Page 125
CHILD SEATS RECOMMENDED BY PEUGEOT PEUGEOT offers a complete range of recommended child seats which are secured using a three point seat belt : Group 0+: from birth to 13 kg "RÖMER Baby-Safe Plus" Installed in the rearward facing position.
Page 126
LOCATIONS FOR CHILD SEATS SECURED USING THE SEAT BELT In accordance with European regulations, this table indicates the options for the installation of child seats secured using the seat belt and universally approved (a) in relation to the weight of the child and the seat in the vehicle. Weight of the child /indicative age From 9 to 18 kg From 15 to 25 kg...
Page 127
"ISOFIX" MOUNTINGS Your vehicle has been approved to the latest ISOFIX regulations . The seats represented below are fi tted with regulation ISOFIX mountings: This ISOFIX mounting system provides fast, reliable and safe fi tting of the child seat in your vehicle. The ISOFIX child seats are fi...
Page 128
ISOFIX CHILD SEAT RECOMMENDED BY PEUGEOT AND APPROVED FOR YOUR VEHICLE ISOFIX child seat with TOP TETHER RÖMER Duo Plus ISOFIX (size category B1 ) Group 1: from 9 to 18 kg Installed only in the "forward facing" position. Is attached to the rings A , as well as the ring B , referred to as the TOP TETHER, using an upper strap.
Page 129
LOCATIONS FOR FITTING ISOFIX CHILD SEATS In accordance with European Regulations, this table indicates the options for installing ISOFIX child seats on seats in the vehicle fi tted with ISOFIX mountings. In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from A to G , is indicated on the child seat next to the ISOFIX logo.
Page 130
Ensure that the lap part of the seat belt passes correctly over the child's thighs. PEUGEOT recommends the use of a booster seat which has a back, fi tted with a seat belt guide at shoulder level. As a safety precaution, do not leave:...
In the event of a malfunction, you are informed by lighting of this SWITCHING THE VEHICLE OFF warning lamp, an audible signal and a message on the screen. In this case, your vehicle does not start; contact a PEUGEOT Immobilise the vehicle. dealer as soon as possible.
PARKING BRAKE Releasing Pull the parking brake lever gently, press the release button then lower the lever fully. When the vehicle is being driven, if this warning lamp and the STOP warning lamp come on, accompanied by an audible signal and a message in the screen, this indicates that the parking brake is still on or has not been properly released.
fi rst gear or neutral on a manual gearbox, If a malfunction of the system occurs, these warning lamps come on. provided you are in position D or M on an automatic gearbox. Have it checked by a PEUGEOT dealer or a qualifi ed workshop.
6-SPEED MANUAL GEARBOX ENGAGING 5 OR 6 GEAR Move the lever fully to the right to engage 5 or 6 gear. ENGAGING REVERSE GEAR Raise the ring under the knob and move the gear lever to the left then forwards.
"PORSCHE TIPTRONIC SYSTEM" GEAR LEVER POSITIONS AUTOMATIC GEARBOX Six speed automatic gearbox which offers a choice between the comfort of fully automatic operation, enhanced by sport and snow programmes, or manual gear changing. There are two driving modes: automatic operation for electronic management of the gears by the gearbox, with the sport programme for a more dynamic driving style or the snow programme to facilitate driving when grip is poor.
DISPLAYS IN THE INSTRUMENT PANEL MOVING OFF Apply the parking brake. Select position P or N . Start the engine. If this procedure is not followed, there is an audible signal, accompanied by a message in the screen. ...
Page 137
AUTOMATIC OPERATION Sport programme "S" Press button "S" , after starting the engine. Select position D for automatic changing of the six gears. The gearbox automatically favours a dynamic style of driving. The gearbox then operates in auto-adaptive mode, without any S appears in the instrument panel.
Page 138
Do not exceed a speed of 60 mph (100 km/h), local speed restrictions permitting. Have it checked by a PEUGEOT dealer or a qualifi ed workshop. Invalid value during manual operation This warning lamp may also come on if a door is opened.
GEAR EFFICIENCY INDICATOR System which reduces fuel consumption by recommending the most appropriate gear. Example: You are in third gear. You press the accelerator pedal. With an automatic gearbox, the system is only active in manual mode. The system may suggest that you engage a higher gear. OPERATION Depending on the driving situation and your vehicle's equipment, the system may advise you to skip one (or more) gear(s).
TYRE UNDER-INFLATION DETECTION System which automatically checks the pressures of the tyres while This system does not avoid the need to check the tyre pressures driving. regularly (including the spare wheel) and before a long journey. The system continuously monitors the pressures of the four tyres, as Driving with under-infl...
Page 141
In the event of a puncture, use the temporary puncture repair kit or the spare wheel (according to equipment), Go to a PEUGEOT dealer or a qualifi ed workshop to have the system if you have a compressor, the one in the temporary puncture repair...
SPEED LIMITER STEERING MOUNTED CONTROL System which prevents the vehicle from exceeding the speed programmed by the driver. When the programmed speed limit is reached, pressing the accelerator pedal no longer has any effect. The speed limiter is switched on manually: it requires a programmed speed of at least 20 mph (30 km/h).
Page 143
DISPLAYS IN THE INSTRUMENT PANEL PROGRAMMING Turn dial 1 to the "LIMIT" position: the speed limiter mode is selected but is not switched on (OFF / Pause). The programmed information is grouped together in the instrument You do not have to switch the speed limiter on in order panel screen.
Page 144
Pressing the accelerator pedal to exceed the resulting in fl ashing of the dashes. programmed speed will not have any effect unless Have it checked by a PEUGEOT dealer or a qualifi ed workshop. you press the pedal fi rmly past the point of resistance .
CRUISE CONTROL STEERING MOUNTED CONTROL System which automatically maintains the speed of the vehicle at the value programmed by the driver, without any action on the accelerator pedal. The cruise control is switched on manually: it requires a minimum vehicle speed of 25 mph (40 km/h) and the engaging: of fourth gear on the manual gearbox, of second gear on the automatic gearbox, in sequential driving mode,...
Page 146
DISPLAYS IN THE INSTRUMENT PANEL PROGRAMMING Turn dial 1 to the "CRUISE" position: the cruise control mode is selected but is not switched on The programmed information is grouped together in the instrument (OFF / Pause). panel screen. 5. Cruise control off / resume indication. ...
Page 147
Intentional or unintentional exceeding of the resulting in fl ashing of the dashes. programmed speed results in fl ashing of this speed in Have it checked by a PEUGEOT dealer or a qualifi ed workshop. the screen. Return to the programmed speed, by means of intentional or unintentional deceleration of the vehicle, automatically cancels the fl...
PARKING SENSORS REAR PARKING SENSORS The system is switched on by engaging reverse gear. This is This system indicates the proximity of an obstacle (person, vehicle, tree, accompanied by an audible signal. gate, etc.) which comes within the fi eld of detection of sensors located The system is switched off when you come out of reverse gear.
Page 149
FRONT PARKING SENSORS Visual assistance In addition to the rear parking sensors, the front parking sensors are triggered when an obstacle is detected in front and the speed of the vehicle is still below 6 mph (10 km/h). The front parking sensors are interrupted if the vehicle stops for more than three seconds in forward gear, if no further obstacles are detected or when the speed of the vehicle exceeds 6 mph (10 km/h).
Page 150
The status of the function is stored when the ignition is switched off. by an audible signal (short beep). Contact a PEUGEOT dealer or a qualifi ed workshop. The function will be deactivated automatically if a trailer is being In bad weather or in winter, ensure that the sensors are not towed or a bicycle carrier is fi...
AND PROTECTION OF THE ENVIRONMENT Innovation at the service of performance The TOTAL Research and Development teams develop lubricants for PEUGEOT which satisfy the requirements of the latest technical innovations incorporated in PEUGEOT vehicles. This ensures that you obtain the best performance and the maximum engine life.
FUEL TANK Opening the fi ller cap may create a noise a caused by an inrush of air. This vacuum is entirely normal, resulting from the sealing of Fuel tank capacity: approximately 55 litres. the fuel system. LOW FUEL LEVEL To fi...
Page 153
Contact a PEUGEOT dealer or a qualifi ed workshop. The use of any other type of (bio)fuel (vegetable or animal oils, pure or diluted, domestic fuel...) is strictly prohibited (risk of damage to the engine and fuel system).
BONNET OPENING Open the front left door. Pull the interior release lever A , located at the bottom of the door aperture. Push the exterior safety catch B to the left and raise the bonnet. The bonnet is held open by the two side struts. The location of the interior release lever prevents opening of the bonnet while the front left door is closed.
PETROL ENGINES The various caps and covers allow access for checking the levels of the various fl uids and for replacing certain components. 1. Power steering reservoir. 6. Fusebox. 2. Screenwash and headlamp wash reservoir. 7. Air fi lter. 3. Coolant reservoir. 8.
DIESEL ENGINE The various caps and covers allow access for checking the levels of the various fl uids, for replacing certain components and for priming the fuel system. 1. Power steering reservoir. 7. Air fi lter. 2. Screenwash and headlamp wash reservoir. 8.
RUNNING OUT OF FUEL (DIESEL) 2 LITRE HDI ENGINE On vehicle fi tted with HDi engines, the fuel system must be primed if you run out of fuel; refer to the engine compartment view on the Fill the fuel tank with at least fi ve litres of Diesel. "Diesel engine"...
Check all of these levels regularly, in line with the warranty and maintenance record. Top them up if necessary, unless otherwise indicated. If a level drops signifi cantly, have the corresponding system checked by a PEUGEOT dealer or a qualifi ed workshop.
BRAKE FLUID LEVEL Topping up the engine oil level The brake fl uid level should be close to the "MAX" mark. If it is Oil grade not, check the brake pad wear. The oil must be the correct grade for your engine and conform to the manufacturer's recommendations.
The cooling fan may start after switching off the engine: take Topping up care with articles and clothing that might become caught by the The reservoir must be topped up without delay by a PEUGEOT dealer fan blades. or a qualifi ed workshop.
CHECKS Unless otherwise indicated, check these components in accordance with the warranty and maintenance record and according to your engine. Otherwise, have them checked by a PEUGEOT dealer or a qualifi ed workshop. BATTERY OIL FILTER The battery does not require any maintenance.
In order to optimise the operation of units as important as those checked, even between vehicle services. in the braking system, PEUGEOT selects and offers very specifi c Unless there is a leak in the circuit, a drop in the brake fl uid level products.
TEMPORARY PUNCTURE REPAIR ACCESS TO THE KIT Complete system consisting of a compressor and a sealant cartridge which permits temporary repair of a tyre so that you can drive to the nearest garage. It is designed to repair most punctures which could affect the tyre, located on the tyre tread or shoulder.
Page 164
DESCRIPTION OF THE KIT A. "Sealant" or "Air" position selector. Sealant cartridge. B. On "I" / off "O" switch. G. White pipe with cap for repair. C. Defl ation button. H. Black pipe for infl ation. D. Pressure gauge (in bar and p.s.i.). Speed limit sticker.
REPAIR PROCEDURE 1. Sealing Uncoil the white pipe G fully. Unscrew the cap from the white pipe. Switch off the ignition. Connect the white pipe to the valve of the tyre to be repaired. Turn the selector A to the "sealant" position. ...
Page 166
PEUGEOT dealer or a qualifi ed workshop. If after around 5 to 7 minutes the pressure is not attained, this indicates that the tyre is not repairable;...
Page 167
Drive at reduced speed (50 mph [80 km/h] max) limiting the distance travelled to approximately 120 miles (200 km). As soon as possible, go to a PEUGEOT dealer or a qualifi ed workshop. You must inform the technician that you have used this kit. After ...
Page 168
After use, do not discard the cartridge into the environment, take it to an authorised waste disposal site or a PEUGEOT dealer. Do not forget to obtain a new sealant cartridge, available from PEUGEOT dealers or from a qualifi ed workshop.
CHECKING TYRE PRESSURES / INFLATING ACCESSORIES You can also use the compressor, without injecting any product, to: check or adjust the pressure of your tyres, infl ate other accessories (balls, bicycle tyres...). Connect the compressor's electrical connector to the vehicle's 12 V socket.
CHANGING A WHEEL TOOLS REQUIRED * Parking the vehicle Security socket: for adaptation of the Immobilise the vehicle where it does not block traffi c: the ground wheelbrace to the special "security" bolts. must be level, stable and non-slippery ground. Specifi...
REMOVING THE WHEEL Extend the jack until its base plate is in contact with the ground. Ensure that the centreline of the jack base plate is directly below Remove the cover on each of the bolts using the bolt cover removal the location A or B used.
Page 172
Pre-tighten the other bolts using the wheelbrace only. After changing a wheel Have the tightening of the bolts and the pressure of the new wheel checked by a PEUGEOT dealer or a qualifi ed workshop without delay. Lower the vehicle fully.
Page 173
TOOLS AND SPARE WHEEL * Depending on the country of sale, the vehicle is equipped with the tools needed to change a wheel and may also be equipped with a spare wheel. The spare wheel is stowed in a protective cover, secured to the boot fl...
Page 174
Access to tools * Open the boot lid. Lift the boot fl oor using its strap. Fix it in the vertical position beyond the stops located on the boot sides. Remove the temporary puncture repair kit for access to the jack. All of these tools are specifi...
It is recommended that before you leave, you practise fi tting the snow For more information on snow chains, contact a PEUGEOT dealer or a chains on a level and dry surface. If your vehicle is fi tted with alloy qualifi...
CHANGING A WIPER BLADE BEFORE REMOVING A WIPER BLADE Within one minute after switching off the ignition, operate the wiper stalk to position the wiper blades in the centre of the windscreen. REMOVING Raise the corresponding wiper arm. ...
PEUGEOT Connect Sound (RD5), level of charge remaining in the battery. it will still be possible to fi nish the call with the PEUGEOT When the vehicle is being driven, the load reduction function temporarily Connect Navigation (RT6) or PEUGEOT Connect Media deactivates certain functions, such as the air conditioning, the heated (NG4 3D).
BATTERY STARTING USING ANOTHER BATTERY ACCESS TO THE BATTERY Connect the red cable to the positive terminal (+) of the fl at battery A , then to the positive terminal (+) of the slave battery B . The battery is located under the bonnet. For access to it: ...
Page 179
Following reconnection of the battery, switch on the ignition and wait 1 minute before starting to permit initialisation of the electronic systems. However, if slight problems remain following this operation, contact a PEUGEOT dealer or a qualifi ed workshop. Referring to the corresponding section, you must yourself reinitialise: ...
CHANGING A BULB FRONT LAMPS Model with halogen headlamps The headlamps are fi tted with polycarbonate glass with a protective coating: do not clean them using a dry or abrasive cloth, nor with a detergent or solvent product, use a sponge and soapy water or a pH neutral product, ...
Page 181
Risk of electrocution Xenon bulbs (D1S) must be replaced by a PEUGEOT dealer or a When refi tting, close the protective cover carefully to assure the qualifi ed workshop.
Page 182
Changing dipped beam headlamp bulbs Remove the protective cover by pulling the tab. Disconnect the bulb connector. Spread the springs to release the bulb. Pull the bulb out and change it. To refi t, carry out these operations in reverse order. Changing main beam headlamp bulbs ...
REAR LAMPS Changing integrated direction indicator side repeaters For the replacement of these bulbs, contact a PEUGEOT dealer or a qualifi ed workshop. Changing the daytime running lamps / sidelamps 1. Sidelamps (LEDs). 2. Direction indicators (LEDs). 3. Brake lamps / sidelamps (P21/5W).
Page 184
Changing brake lamps / sidelamps This bulb is changed from outside the boot, having fi rst removed the rear lamp: open the boot lid, unclip the access fl ap of the corresponding side trim, then remove it, disconnect the lamp connector, ...
Page 185
Changing reversing lamps and foglamps These two bulbs are changed from outside the rear bumper: unclip the protective cover from the rear, then tilt it, remove it completely to gain access to the two lamp fi xing bolts, ...
Page 186
Changing reversing lamp and foglamp bulbs (1.6 litre THP 270 hp version) The bulbs on these two types of lamp are changed by partly removing the lamp unit A in the rear bumper: using a screwdriver, remove the 3 fi xing screws B located under the vehicle, ...
Page 187
Changing sidelamps and direction indicators For the replacement of this type of LED lamp, contact a PEUGEOT dealer or a qualifi ed workshop. Changing the third brake lamp (LEDs) For the replacement of this type of LED lamp, contact a PEUGEOT dealer or a qualifi...
If the fault recurs soon after changing a fuse, have the electrical The extraction tweezer is fi tted to the back of the dashboard fusebox system of your vehicle checked by a PEUGEOT dealer or a cover. qualifi ed workshop.
Page 189
Before installing other electrical equipment or accessories on your vehicle, contact a PEUGEOT dealer or a qualifi ed workshop. PEUGEOT will not accept responsibility for the cost incurred in repairing your vehicle or for rectifying malfunctions resulting from...
Page 190
DASHBOARD FUSES Fuse tables The fusebox is placed in the lower section of the dashboard (left-hand Fuse N° Rating Functions side). It consists of two boxes. 30 A Locking and deadlocking earth. Airbags, active bonnet and pretensioners control unit. Clutch pedal switch, electrochromatic 10 A rear view mirror, automatic gearbox, switching and protection unit.
Page 191
Fuse N° Rating Functions Engine fusebox, active bonnet. Multifunction screen, seat belt and passenger's front airbag warning lamps 15 A display, instrument panel screen, amplifi er, Bluetooth system, parking sensors control unit, USB Box. 30 A Locking and deadlocking. Rear screen and door mirrors demist/ 40 A defrost.
Page 192
ENGINE COMPARTMENT FUSES Fuse table The fusebox is placed in the engine compartment near the battery Fuse N° Rating Functions (left-hand side). 15 A Horn. 10 A Front wash-wipe. 20 A Daytime running lamps. Air fl ow sensor, coolant pump, oil pump, thermostat, blow-by heater (petrol), 15 A by-pass and EGR electrovalves (Diesel),...
Page 193
Fuse N° Rating Functions 40 A Windscreen wipers slow / fast speed. 10 A Right-hand main beam headlamp. 10 A Left-hand main beam headlamp. 15 A Left-hand dipped headlamp. 15 A Right-hand dipped headlamp.
Page 194
Table of fuses over the battery All work on the other types of fuses (midi-fuses and maxi-fuses) Fuse N° Rating Functions must be carried out only by a PEUGEOT dealer or a qualifi ed Dual function brake switch. workshop. Battery charge unit. 25 A ABS/ESC electrovalves.
TOWING A VEHICLE TOWING EYE GENERAL RECOMMENDATIONS Observe the legislation in force in your country. Ensure that the weight of the towing vehicle is higher than that of the towed vehicle. The driver must remain at the wheel of the towed vehicle and must have a valid driving licence.
TOWING YOUR VEHICLE Towing from the rear Towing from the front It is also possible to pull your vehicle from the rear, but only in exceptional circumstances (vehicle in a parking space, off the road...). On the front bumper, unclip the cover by pressing on the left. ...
fi tting of the towbar is entrusted to a PEUGEOT dealer or a qualifi ed workshop.
Page 198
The rear parking sensors will be deactivated automatically if a Towing a trailer on a slope increases the temperature of the coolant. genuine PEUGEOT towbar is used. As the fan is electrically controlled, its cooling capacity is not dependent on the engine speed.
They are intended for customising the body. Available also as accessories, we recommend that you have them fi tted by a PEUGEOT dealer or a qualifi ed workshop. When washing your vehicle, keep the end of a high-pressure lance at least 30 centimetres from the stickers.
Page 200
The insect remover can also be used to remove minor marks (for example: fi nger marks...). Never clean the vehicle without water. Always have paint repairs done by a PEUGEOT dealer or a qualifi ed Never wash your vehicle in an automatic roller brush car wash. workshop.
These accessories and parts have been tested and approved for alloy wheels, door mirror shells in carbon fi bre... reliability and safety. They are all adapted to your vehicle and benefi t from PEUGEOT's recommendation and warranty. "Comfort": "Safety and security": front parking sensors, cool box...
Page 202
"Multimedia": By going to a PEUGEOT dealer you can also obtain products for cleaning and maintenance (exterior and interior) - including ecological portable navigation systems, Wi-Fi on Board... products from the "TECHNATURE" range, topping up products (screenwash, ...), touch-up pens and aerosols for the exact colour of your vehicle, refi...
PETROL WEIGHTS AND TOWED LOADS (IN KG) 1.6 litre THP 1.6 litre THP 1.6 litre THP 1.6 litre THP Engines 1.6 litre THP 156 hp 150 hp 163 hp 200 hp 270 hp Gearboxes Automatic Manual Auto. Automatic Manual Manual Model codes: 4J...
Page 205
DIESEL ENGINE AND GEARBOX Engine 2.0 litre HDi 163 hp Manual Gearbox (6-speed) Model codes: RHH-8 4J... Cubic capacity (cc) 1 997 Bore x stroke (mm) 85 x 88 Max power: EU standard (kW) * Max power engine speed (rpm) 3 750 Max torque: EU standard (Nm) Max torque engine speed (rpm)
Page 206
DIESEL WEIGHTS AND TOWED LOADS (IN KG) Diesel engine 2.0 litre HDi 163 hp Gearbox Manual Model codes: 4J... RHH-8 - Unladen weight 1 370 - Kerb weight 1 445 - Payload - Gross vehicle weight (GVW) 1 825 - Gross train weight (GTW) on a 12% gradient 2 325 - Braked trailer (within GTW limit)
IDENTIFICATION MARKINGS C. Manufacturer's label. The number is indicated on a self-destroying label affi xed to the door aperture, below the door striker, on the right-hand side. Various visible markings for the identifi cation of your vehicle. This label also indicates the unladen weight, the gross vehicle weight (GVW) and the gross train weight (GVW).
Operation of the system LED goes off. Cancellation is confi rmed by a voice message. To cancel a call, tell the "PEUGEOT Connect SOS" call centre that the call was a mistake. When the ignition is switched on, the green LED comes on for 3 seconds indicating that the system is operating correctly.
PEUGEOT dealer. If you have purchased your vehicle outside the The message "Deteriorated emergency call" associated with PEUGEOT dealer network, we invite you to have a dealer check fl ashing of the orange indicator lamp indicates a malfunction. the confi guration of these services and, if desired, modifi ed to suit Contact a PEUGEOT dealer.
Page 213
PEUGEOT Connect Media Navigation (NG4 3D) MULTIMEDIA AUDIO SYSTEM / BLUETOOTH TELEPHONE GPS EUROPE CONTENTS 01 First steps 02 Voice commands and The system is protected in such a way that it will only operate in your vehicle. steering mounted controls...
FIRST STEPS PEUGEOT Connect Media Navigation (NG4 3D) control panel Access to the Media Menu (audio CD, Jukebox, Abandon the current Auxiliary input). operation. Access to the Navigation Display the list of tracks. Menu and display recent Long press: return to main Access to the Address book Change the audio source.
Page 215
FIRST STEPS PEUGEOT Connect Media Navigation (NG4 3D) navigator Select successive display in the CALL: access to the Phone screen of "MAP" / "NAV" menu. (if navigation in progress) / "TEL" (if a call is in progress) / Bluetooth connection, accept Press to left / right: "RADIO"...
Voice advice off the tables below. Deactivate the spoken guidance instructions Voice advice on Speak and PEUGEOT Connect Media Navigation (NG4 3D) acts. Activate the spoken guidance instructions Save address Save an address in the address book Start guidance...
VOICE COMMANDS AND STEERING MOUNTED CONTROLS CONTEXT ACTION Initiation of voice commands MEDIA Media Select the MEDIA source Voice recognition Select media Choose a source Single slot Select the CD player source Jukebox Select the Jukebox source Select the USB player source External device Select the audio AUX input source SD-Card...
Page 218
VOICE COMMANDS AND STEERING MOUNTED CONTROLS Wiper stalk: display "RADIO" and "MEDIA". Steering mounted controls Lighting stalk: activate voice commands with a short press; indication of the current navigation instruction with a long press . Radio: automatic search for a higher frequency. Radio: select the previous/next pre-set CD / SD CARD / JUKEBOX: select the next track.
GENERAL OPERATION Contextual display Press the MODE button several times in succession to gain access to the following displays: FULL SCREEN MAP RADIO / / / / MUSIC MEDIA / VIDEO TELEPHONE NAVIGATION (If guidance is in progress) (If a conversation is in progress) TRAFFIC: TRAFFIC access to the Traffi...
Page 220
GENERAL OPERATION Contextual display TELEPHONE: Trip info Pressing OK gives access to short-cut menus according to the display on the End call Route type screen. Hold call Avoid NAVIGATION (IF GUIDANCE IS IN PROGRESS): Dial Satellites Abort guidance DTMF-Tones Stopovers Repeat advice Private mode Browse route...
Page 221
GENERAL OPERATION Contextual display RADIO: FULL SCREEN MAP: North Up In FM mode Abort guidance / Resume guidance Heading Up Set destination / Add stopover Zoom/Scroll POIs nearby Radiotext Position info AUDIO DVD (LONG PRESS): Regional prog. Options Stop Navigate to Group In AM mode Dial...
Page 222
GENERAL OPERATION Contextual display VIDEO DVD (LONG PRESS): Examples: Play Stop DVD menus DVD menu DVD top menu List of titles List of chapters DVD Options Audio Subtitles Angle...
Page 223
PEUGEOT Connect Media IS: the map setting which allows the map to be displayed fl at, in perspective or in 3D. Flat map Map in perspective Map in 3D confi guration of the system by means of voice commands.
NAVIGATION - GUIDANCE The "NAVIGATION" voice commands are listed in section 02. Selecting a destination During guidance, a long press on the end of the lighting stalk repeats the last guidance instruction. Select the "Address input" function ADDR and press OK to confi rm. RADIO MEDIA TRAFFIC...
Page 225
fi le. Press OK to confi rm the selection. and press OK to confi rm and start PQRS WXYZ The PEUGEOT Connect Media allows more than 4 000 contact guidance. records to be saved. To delete a destination; from steps 1 to 3, select "Choose from last It is also possible to select a destination via "Choose from address...
Page 226
NAVIGATION - GUIDANCE Setting and navigating to my "Home address" Select your home address and confi rm. To be set as the "Home address", an address must fi rst be Then select "Edit entry" and confi rm. TRAFFIC ADDR RADIO MEDIA BOOK SETUP...
NAVIGATION - GUIDANCE When the map is displayed on the screen, you can select "Map Settings" Route options then "2D Map / 2.5D Map / 3D Map / North Up / Heading Up". The display of buildings in 3D mode depends on the progress in town mapping. Select the "Route dynamics"...
NAVIGATION - GUIDANCE Stopovers can be added to or deleted from the route once the destination Adding a stopover has been selected. Enter a new address, for example. RADIO MEDIA TRAFFIC ADDR SETUP BOOK ADDR RADIO MEDIA TRAFFIC BOOK SETUP Press the NAV button.
Page 229
NAVIGATION - GUIDANCE The points of interest (POIs) indicate all of the service locations in the Searching for points of interest (POI) vicinity (hotels, various businesses, airports...). Select the "POI in city" function to search for POIs in the city required. ADDR RADIO MEDIA...
Page 230
List of principal points of interest (POI) Cinema Service station Airport Theme parks LPG station Railway station Garage Bus station Hospital PEUGEOT Port Pharmacy Police station Motor racing circuit Industrial estate Covered car park Supermarket School Post offi ce Car park...
Page 231
SETUP BOOK Navigation Menu Navigation Menu an SD card or USB memory stick from PQRS WXYZ the Internet. This service is available at Settings http://peugeot.navigation.com. Update personal POI Update personal POI ADDR RADIO MEDIA TRAFFIC SETUP BOOK Select the medium ("USB" or "SD-Card") The fi...
Page 232
NAVIGATION - GUIDANCE Spoken instruction settings When the navigation is displayed in the screen, press OK then select or deselect "Voice advice" to activate RADIO MEDIA TRAFFIC ADDR SETUP BOOK or deactivate the spoken guidance Select the "Settings" function and ADDR instructions.
Page 233
TRAFFIC INFORMATION The TMC (Traffi c Message Channel) messages provide information relating to traffi c and weather conditions, received in real time and transmitted to the driver audibly and visually on the navigation map. Configure the filtering and display The guidance system can then suggest an alternative route. of TMC messages Select the fi...
TRAFFIC INFORMATION Principal TMC symbols Receiving TA messages the station transmits TA messages. Black and blue triangle: general information, for example: the station does not transmit TA messages. TA messages are not activated. Weather reports Traffi c reports The TA (Traffi c Announcement) function gives priority to TA alert messages.
The external environment (hill, building, tunnel, underground car park...) RADIO may interfere with the reception, including in RDS station tracking mode. This phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a failure of the audio equipment. Selecting a station RDS - Regional mode Press the RADIO button to display the...
MUSIC MEDIA PLAYERS CD, MP3 / WMA CD, MP3 / WMA SD card / USB player Information and advice The audio equipment will only play audio fi les with the extension The MP3 format, an abbreviation of MPEG 1, 2 & 2.5 Audio Layer 3 ".mp3"...
Page 237
MUSIC MEDIA PLAYERS Selecting / Playing CD, MP3 / WMA CD, MP3 / WMA SD card / MP3 CDs, SD cards or USB peripherals are the compatible sources. USB player Insert the audio or MP3 CD in the player, the SD card in the card ADDR RADIO MEDIA...
Page 238
MUSIC MEDIA PLAYERS Jukebox When copying is in progress, switching off the ignition will interrupt the Copying a CD, a USB memory stick or an SD card process but it will resume directly when the ignition is switched on again. to the hard disk Select the tracks required then "Rip ADDR...
Page 239
MUSIC MEDIA PLAYERS Jukebox Playing the jukebox Renaming or deleting an album Check that the active source is not the Jukebox in order to be able to rename or delete a track / folder. Press the MEDIA button. RADIO MEDIA TRAFFIC MEDIA Press the MEDIA button again or...
MUSIC MEDIA PLAYERS Using an external device (AUX) Viewing a video DVD Audio / Video / RCA cable not supplied Connect the portable device (MP3 player, camcorder, camera…) to RADIO MEDIA TRAFFIC ADDR SETUP BOOK the RCA sockets (white and red for audio; yellow for video) in the Insert the DVD in the player.
USING THE TELEPHONE Choosing between the Bluetooth telephone / internal telephone RADIO MEDIA TRAFFIC ADDR SETUP BOOK To activate the Bluetooth telephone or the internal telephone, press PICK UP. PQRS WXYZ Select Phone menu, then "Select phone" then choose between ADDR RADIO MEDIA...
Page 242
MEDIA TRAFFIC ADDR SETUP BOOK telephone. The code to be entered hands-free system of the PEUGEOT Connect Media Navigation (NG4 3D) PEUGEOT Connect Media Navigation (NG4 3D) PEUGEOT is displayed on the screen of the PQRS WXYZ must be carried out with the vehicle stationary and the ignition on.
Page 243
For safety reasons and because they require prolonged attention on the part of the driver, the operations for pairing the Bluetooth Once the telephone has been connected, the PEUGEOT Connect mobile telephone to the hands-free system of the PEUGEOT Media Navigation (NG4 3D) can synchronise the address book and the call list.
Page 244
USING THE TELEPHONE Using the internal telephone with If you have declined to use the internal telephone for personal calls, you can still connect a Bluetooth telephone to receive your calls on the vehicle's a SIM card audio system. Enter the PIN code on the keypad TRAFFIC ADDR BOOK...
PQRS WXYZ It is also possible to select a number from the address book. You can select "Dial from address book". The PEUGEOT Connect End call Media can record up to 4 096 entries. It is always possible to start a call directly from the telephone;...
Page 246
SCREEN MENU MAP(S) MAIN FUNCTION Create folder Within 6 miles (10 km) Within 30 miles (50 km) Modify content OPTION A Read out settings Edit playlist option A1 On confi rmation Play options option A2 Incoming messages Folders & Files OPTION B…...
Page 247
AUX standard Classic Start route guidance Jazz Reset video settings Postal code Rock/Pop Ext. Device (Aux) management Save to address book Techno Off / Audio / Audio and Video (AV) Intersection Vocal City district RADIO Mute rear speakers Geo position "Radio"...
Page 248
Recalculate Semi-dynamic Fast route Dynamic "Phone" menu Short route Avoidance criteria Dial number Optimized route Avoid motorways Dial from address book POI search Avoid toll roads POI nearby Avoid tunnels Call lists POI near destination Avoid ferries Messages POI in city Recalculate Select phone POI in country...
Page 249
Settings Search for networks Polski Automatic answering system PIN settings Portuguese Select ring tone Change PIN Voice control Phone / Ring tone volume Activate PIN Voice control active Enter mailbox number Deactivate PIN Tutorial Internal phone settings Remember PIN Basics Automatically accept call SIM-card memory status Examples...
Page 250
Display Units Brightness Temperature Colour Celsius Steel Fahrenheit blue light (only in day mode) Metric / Imperial Orange Ray Blue Flame Miles Map colour System Factory reset Day mode for map Night mode for map Software version Auto. Day/Night for map Automatic scrolling...
Page 251
FREQUENTLY ASKED QUESTIONS The table below groups together the answers to the most frequently asked questions concerning the PEUGEOT Connect Media Navigation (NG4 3D). QUESTION ANSWER SOLUTION There is a difference in For optimum sound quality, the audio settings (Volume, Bass, Treble,...
Page 252
The aerial is absent or has been damaged (for example when going Have the aerial checked by a PEUGEOT dealer. through a car wash or into an underground car park). Sound cut-outs of 1 to During this brief sound cut-out, the RDS searches for any frequency Deactivate the "RDS"...
Page 253
QUESTION ANSWER SOLUTION "TA" is selected. On starting, it is several minutes before the system begins to receive the Wait until the traffi c information is being received However, certain traffi c traffi c information. correctly (displaying of the traffi c information jams along the route are symbols on the map).
Page 254
A list of compatible Bluetooth mobile telephones is available from the dealer network. The volume of the The volume depends both on the system and on the telephone. Increase the volume of the PEUGEOT Connect telephone connected Media Navigation (NG4 3D), to maximum in Bluetooth mode is if required, and increase the volume of the inaudible.
Page 255
Consult a PEUGEOT dealer if the problem persists. Check that the data on the MEDIUM is supplied by an offi cial partner of PEUGEOT. The voice frequencies The numeric buttons on the keypad are only active for calls if the display...
PEUGEOT Connect N onnect N onnect avigation (RT6) SATELLITE NAVIGATION SYSTEM MULTIMEDIA BLUETOOTH TELEPHONE AUDIO SYSTEM CONTENTS 01 First steps - Control panel 02 Steering mounted controls The system is protected in such a way that it will only 03 General operation operate in your vehicle.
FIRST STEPS Select: Selection and confi rmation OK dial: the previous/next line in a list or menu. Selection of an item on the screen or in a list or a menu, Open the the previous / next media folder. then confi rmation with a short press. "...
Page 259
FIRST STEPS Access to the " RADIO " menu and Access to the " MUSIC " menu, and display of the CD/MP3/ display the list of stations received. Apple tracks and folders. tracks and folders. ® ® ® Open the " Telephone " menu Long press: display the audio settings Long press: display the audio settings screen for the and display the list of recent...
STEERING MOUNTED CONTROLS RADIO: change to the next radio station in the list. Long press: automatic search for a higher frequency. CD: select the next track. CD: continuous press: fast forward play. SRC/TEL button: change the audio source, start a call from the address book, call/end call on the telephone, press for more than 2 seconds: access to the address book.
GENERAL OPERATION Press the MODE button several times in succession for access to the following displays: " MAP IN WINDOW " " RADIO " (If navigation guidance in progress) " TELEPHONE " " FULL SCREEN MAP " (If conversation in progress) Changing the audio source: SETUP : PARAMETERS RADIO : RADIO broadcasts.
Page 262
GENERAL OPERATION Display according to context Select destination DTMF ring tones A press on the knob gives access to short-cut menus according to the Hang up Enter an address display in the screen. Directory RADIO: MUSIC MEDIA PLAYERS, CD or USB GPS coordinates Activate / Deactivate TA (according to media):...
Navigation - guidance " " " " " " " " " " " " " " " " " " " " " " " functions of your navigation system, update the mapping regularly. Contact a PEUGEOT dealer or order Press NAV . your mapping update at http://peugeot.navigation.com List of recent destinations.
Page 264
NAVIGATION - GUIDANCE Selecting a destination Towards a new destination Selection the town from the list offered, then confi rm . Press NAV to display the A pre-set list (by entering the fi rst few " Navigation - guidance " menu. letters) of the towns in the country selected can be accessed directly by selecting and confi...
Page 265
NAVIGATION - GUIDANCE Towards a recent destination Towards a contact in the contacts directory Press NAV to display the Navigation towards a contact is only possible if it has an address " Navigation - guidance " menu. entered in the audio navigation system. Select the desired destination and confi...
Page 266
NAVIGATION - GUIDANCE Towards GPS coordinates Towards a point on the map With the map displayed, press OK to Press NAV to display the display the contextual menu. Select " Navigation - guidance " menu. " Move the map " and confi rm. Select "...
Page 267
NAVIGATION - GUIDANCE The points of interest (POI) indicate all of the service locations in the vicinity Towards points of interest (POI) (hotels, various businesses, airports...). Select " Search by Name " to search for POIs by name and not by Press NAV to display the proximity.
Page 268
Zooming in on this icon shows details of the POIs. List of principal points of interest (POI) Airport Service station Cinema Railway station Garage Theme parks PEUGEOT Bus station Hospital, Chemist, Port Covered car park Police station Car park Industrial estate School...
Page 269
" menu. The detailed procedure for updating risk area POIs can be found at http://peugeot.navigation.com. Select " Guidance options " and confi rm, then select " Set parameters for risk areas " and confi rm.
Page 270
NAVIGATION - GUIDANCE Adding a stage Organising stages To organise stages, carry out Press NAV to display the operations 1 to 2 again, then select " Navigation - guidance " menu. " Order/delete journey legs " and confi rm. Select " Journey leg and route " then Select the stage that you want to move in the order.
Page 271
NAVIGATION - GUIDANCE Route options Calculation criteria Select " Defi ne calculation criteria " and confi rm. This function allows modifi cation of: the guidance criteria: (" Fastest Press NAV to display the route ", " Shortest route ", " Navigation - guidance " menu. "...
Page 272
NAVIGATION - GUIDANCE Map management Selecting the points of interest displayed on the map Select from the various categories the Press NAV to display the ones that you want to display on the " Navigation - guidance " menu. screen. Select "...
Page 273
NAVIGATION - GUIDANCE Map orientation Select: " Vehicle direction " to have the map follow the direction of travel, Press NAV to display the " North direction " to keep the map " Navigation - guidance " menu. always North up, "...
Page 274
NAVIGATION - GUIDANCE Navigation voice synthesis Adjusting the volume / Deactivation The volume of messages can be adjusted during the transmission of the message using the volume adjustment control. Select the volume graph and confi rm. The volume setting of guidance messages is also accessible via the "...
Page 275
NAVIGATION - GUIDANCE Male voice / Female voice Press SETUP to display the confi guration menu. Select " Voice synthesis " and confi rm. Select " Select male voice " or " Select female voice " then confi rm " Yes "...
TRAFFIC INFORMATION Access to the "Traffic information" menu " " " " " " " " " " " " " " " " " " Traffi c information Traffi c information Traffi c information Traffi c information Traffi c information Traffi...
Page 277
TRAFFIC INFORMATION Configure the filtering and display of TMC messages TMC (Traffi c Message Channel) messages contain information on traffi c and weather conditions, received in real time and transmitted to the driver in the form of audible announcements and symbols on the navigation map. The navigation system can then suggest an alternative route to avoid a traffi...
Page 278
TRAFFIC INFORMATION Principal TMC symbols Receiving TA messages The TA (Traffi c Announcement) function gives priority to TA alert Black and blue triangle: general information, for example: messages. To operate, this function needs good reception of a radio station transmitting this type of message. When a traffi c report is transmitted, the current audio source (Radio, CD, USB, ...) is Weather reports Traffi...
USING THE TELEPHONE Access to the "Telephone" menu In the top bar of the permanent " " " " " " " " " " " " " " " " " " Telephone Telephone Telephone Telephone Telephone Telephone Telephone Telephone Telephone Telephone...
Page 280
. You can check the compatibility of your telephone Procedure from the system at www.peugeot.co.uk (services). Quick procedure from the telephone Activate the telephone's Bluetooth function and ensure that it is "visible to all" (telephone confi...
Page 281
USING THE TELEPHONE The services available depend on the network, the SIM card and the compatibility of the Bluetooth telephone used. Check the telephone manual and with your network provider for details of the services available to you. Select the name of the desired Enter a minimum 4 fi...
Page 282
USING THE TELEPHONE Directory configuration / Synchronisation with the telephone Select " Import all the entries " to import all the contacts in the telephone and Press PHONE then select " Contacts save them in the system. management " and confi rm. Once imported, a contact remains visible whatever telephone is connected.
USING THE TELEPHONE Editing, importing or deleting a contact Press PHONE then select " Directory of It is not possible to modify or delete contacts in the telephone or the contacts " and confi rm. SIM card via the Bluetooth connection. Once the contact has been imported, the Bluetooth symbol disappears, replaced by the telephone symbol which shows that the Select the desired contact and confi...
Page 284
USING THE TELEPHONE Use of the telephone is not recommended while driving. We recommended Making a call that you park safely or make use of the steering mounted controls. Calling a contact Calling a new number Press TEL or twice on PHONE . Press PHONE twice.
USING THE TELEPHONE Ending a call Calling a recently entered number Press PHONE then select " OK " to end Press TEL , select " Call list " and the call. confi rm, Or make a long press on TEL at the steering mounted controls.
Page 286
USING THE TELEPHONE Receiving a call An incoming call is announced by a ring and a superimposed display on the screen. " Yes " Yes " " to accept the call is selected by default. Press " OK " to accept the call. Select "...
USING THE TELEPHONE Options during a call * Select " DTMF ring tones " to use the numerical keypad, so as to navigate During a call, press the MODE button through the menu of an interactive vocal several times to select display of the server.
USING THE TELEPHONE Managing paired telephones Changing the ringtone Press PHONE twice. Press PHONE twice. Select " Phone functions " and confi rm. Select " Bluetooth functions ". Select " Ring options " and confi rm. Select " List of the paired peripherals " and confi...
RADIO Access to the "Radio" menu " " " " " " " " " " " " " " " " " " " FM / AM band / DAB FM / AM band / DAB FM / AM band / DAB FM / AM band / DAB FM / AM band / DAB FM / AM band / DAB...
Page 290
RADIO Changing waveband Selecting a station The external environment (hill, building, tunnel, underground car park...) may interfere with the reception, including in RDS station tracking mode. This phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio system. The quality of reception is represented by the number of active waves in this symbol.
RADIO Presetting a station Activate / Deactivate RDS RDS, if activated, allows you to continue listening to the same station by automatic retuning to alternative frequencies. However, in certain conditions, coverage of an RDS station may not be assured throughout the entire country as radio stations do not cover 100 % of the territory.
Page 292
RADIO DAB (Digital Audio Broadcasting) DAB (Digi DAB (Digital Audio Broadcasting) tal Audio Broadcasting) Digital radio - DAB/FM auto tracking Digital radio Digital radio Digital radio Digital radio Digital radio provides a higher quality reception and also the "DAB" does not have 100% coverage of the country. graphical display of information for the radio station, by selecting When the digital signal is weak, "DAB / FM auto tracking"...
MUSIC MEDIA PLAYERS Access to the "Music media player" menu " " " " " " " " " " " " " " " " " " " MEDIA MEDIA MEDIA MEDIA MEDIA MEDIA MEDIA MEDIA MEDIA MEDIA MEDIA MEDIA MEDIA MEDIA...
Page 294
MUSIC MEDIA PLAYERS CD, MP3 CD / USB player Information and advice The audio equipment will only play audio fi les with ".wma, .aac, .fl ac, The system supports USB mass storage or iPod .ogg and .mp3" fi le extensions and with a bit rate of between 32 Kbps devices via the USB port (suitable cable not supplied).
Page 295
MUSIC MEDIA PLAYERS Sources Selection of source The SOURCE button on the steering mounted controls allows a direct change to the next media source. Insert the CD in the player, insert the USB memory stick in the USB player or connect the "...
Page 296
MUSIC MEDIA PLAYERS Selecting a track MUSIC: List of USB or CD tracks or Previous track. folders Next track. Up or down in the list. Previous folder. Confi rm, next menu level. Next folder. Fast forward. Long press Fast backward. Long press Up one menu level.
MUSIC MEDIA PLAYERS Connecting APPLE Connecting APPLE Connecting APPLE players players Audio streaming ® ® ® ® Connect the Apple player to the USB port using a suitable cable player to the USB port using a suitable cable ® ® ®...
Page 298
MUSIC MEDIA PLAYERS Using the auxiliary input (AUX) JACK/USB audio cable not supplied Select " Activate / Deactivate AUX input " and confi rm. Connect the portable device (MP3, WMA player…) to the JACK auxiliary audio socket First adjust the volume of your portable or USB port using a suitable cable.
AUDIO SETTINGS They are accessible by the MUSIC The audio settings ( Equalizer , Equalizer , Equalizer Bass , Treble and Loudness ) are button in the control panel or by a long different and independent for each sound source. press on RADIO according to the source The settings for distribution and balance are common to all sources.
CONFIGURATION Display configuration Select " Choose colour " and confi rm to Choose colour " and confi rm to Choose colour select the screen colour harmony and the map presentation mode: day mode, Press SETUP to display the " Confi guration " menu. night mode, automatic day/night mode, according to whether the...
SCREEN MENU MAP(S) Map management MAIN FUNCTION Previous destinations Order/delete journey legs Map orientation Option A Vehicle direction Divert route Option A1 Chosen destination North direction Option A11 Guidance options Perspective view Option B... Defi ne calculation criteria Map details "Navigation - guidance"...
SCREEN MENU MAP(S) Phone functions Call "TRAFFIC INFORMATION" MENU Open Ring options Geographic filter Import Delete calls log Retain all the messages: Delete Bluetooth functions Retain the messages: Cancel List of the paired peripherals Around the vehicle Contacts management Connect On the route New contact Disconnect...
Page 303
SCREEN MENU MAP(S) "RADIO" MENU "MUSIC" MENU Bass Treble Change Waveband Change Media Loudness AM / FM Activated / Deactivated Guidance options Bluetooth streaming Distribution USB/iPod Driver RDS options All passengers Audio settings Read mode Le-Ri balance Equalizer Normal Fr-Re balance None Random Auto.
Page 304
SCREEN MENU MAP(S) "SETUP" MENU Select language Define vehicle parameters * Français Parking assistance Display configuration English Wiper operation Choose colour Italiano Rear wiper in reverse Harmony: Portuguese Lighting confi guration Cartography: Español Guide-me-home lighting time Day mode Deutsch Directional headlamps Night mode Nederlands Mood lighting...
FREQUENTLY ASKED QUESTIONS The following table groups together the answers to the most frequently asked questions concerning your audio system. QUESTION ANSWER SOLUTION The route calculation is The guidance criteria may confl ict with the current location (exclusion of Check the guidance criteria on the Navigation not successful.
Page 306
"visible to all". The Bluetooth telephone is not compatible with the system. You can check the compatibility of your telephone on www.peugeot.co.uk (services) The volume of the The volume depends both on the system and on the telephone. Increase the volume of the audio system, to...
Page 307
FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION Some contacts are The options for synchronizing contacts are synchronizing the contacts Select "Display SIM card contacts" or "Display duplicated in the list. on the SIM card, the contacts on the telephone, or both. When both telephone contacts".
Page 308
The aerial is absent or has been damaged (for example when going Have the aerial checked by a PEUGEOT dealer. through a car wash or into an underground car park). I cannot fi nd some radio The station is not received or its name has changed in the list.
Page 309
FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION In changing the setting The selection of an equalizer setting imposes the balance settings. Modify the balance or equalizer settings to obtain of treble and bass the the desired musical ambience. Modifying one without the other is not possible. equalizer setting is deselected.
Page 310
FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION With the engine off, the When the engine is switched off, the system's operating time depends on Start the vehicle's engine to increase the battery system switches off after the battery charge. charge. a few minutes of use. The switch-off is normal: the system switches to economy mode and switches off to prevent discharging of the vehicle's battery.
PEUGEOT Connect Sound (RD5) AUDIO SYSTEM / BLUETOOTH ® CONTENTS Your PEUGEOT Connect Sound (RD5) is coded in such 01 First steps a way that it will only operate in your vehicle. 02 Steering mounted controls 03 Main menu 04 Audio...
FIRST STEPS Display the list of Audio settings: front/ Select source: local stations. rear fader, left/right Selection of AM / FM / DAB * radio, audio CD / MP3 CD, USB, balance, bass/treble, Long press: CD wavebands. Jack connection, Streaming, tracks or MP3 Abandon the current loudness, audio...
STEERING MOUNTED CONTROLS Radio: automatic search for a higher frequency. CD / MP3 / USB: selection of the next track. CD / USB: continuous press: fast forwards play. Move in the list. Change audio source. Confi rm a selection. Call/end call on the telephone. Press for more than 2 seconds: telephone main menu.
MAIN MENU Screen C TELEPHONE : AUDIO FUNCTIONS : hands-free kit, pairing, radio, CD, USB, options. management of a call. VEHICLE DIAGNOSTICS : PERSONALISATION- CONFIGURATION : alert log. vehicle parameters, display, languages. For a detailed global view of the menus available, refer to "Screen menu map"...
AUDIO The external environment (hills, buildings, tunnels, basement car parks, ...) may block reception, including in RDS mode. This is a normal effect of the way in which radio waves are transmitted and does not indicate any failure of the audio system. Radio Selecting a station Press the SOURCE button several...
Page 316
AUDIO DAB (Digital Audio Broadcasting) Receiving TA messages Digital radio The TA (Traffi c Announcement) function gives priority to TA alert Digital radio provides a superior audio quality and also additional messages. To operate, this function needs good reception of a categories of traffi...
AUDIO Digital radio - DAB / FM tracking Playing a CD "DAB" does not have 100% coverage of the country. Insert circular compact discs only. When the digital signal is weak, "DAB / FM auto tracking" allows you Some anti-pirating systems, on original discs or CDs copied using a to continue listening to the same station, by automatically switching personal recorder, may cause faults which are no refl...
Page 318
AUDIO MP3 CD MP3 CD Playing an MP3 compilation Information and advice Insert an MP3 compilation in the player. The MP3 format, an abbreviation of MPEG 1.2 & 2.5 Audio Layer 3, The audio equipment searches for all of the music tracks, which is an audio compression standard which permits the recording of may take anything between a few seconds and several tens of several tens of music fi...
- digital player or a USB using a lead. If the audio equipment is switched memory stick - to your PEUGEOT Connect on, the USB source is detected as soon as it Sound (RD5) and heard via the vehicle's is connected.
Page 320
PEUGEOT CONNECT USB Using the PEUGEOT CONNECT USB Press one of these buttons to gain Press and hold LIST to display the access to the previous / next track on different classifi cations. the classifi cation list currently being Select by Folder / Artist / Genre / Playlist, played.
Page 321
PEUGEOT CONNECT USB Using the auxiliary input (AUX) Adjusting the volume of the auxiliary source JACK socket or USB port (according to vehicle) The auxiliary input, JACK or USB, allows the connection of a portable device (MP3 player...). First adjust the volume of your portable device.
* If your telephone is fully compatible. and the ignition on. Select the telephone to be connected from the list. Only one Go to www.peugeot.co.uk for more information (compatibility, telephone can be connected at a time. more help, ...). Activate the telephone's Bluetooth function A virtual keypad is displayed in the and ensure that it is "visible to all"...
Page 323
BLUETOOTH Making a call Receiving a call An incoming call is announced by a ring and a superimposed From the Bluetooth telephone function Audio menu, select Manage display in the vehicle's screen. the telephone call then Call, Call list or Directory. Select the YES tab on the display Press this button for more than two seconds for access to your directory, then navigate with the...
BLUETOOTH Bluetooth audio streaming * Wireless transmission of music fi les on the telephone, played via Ending a call the audio equipment. The telephone must be able to manage the appropriate Bluetooth profi les (Profi les A2DP / AVRCP). Initiate the pairing between the telephone and the vehicle.
SCREEN MENU MAP(S) Screen C Press the OK dial for access to short-cut menus according to the display in the screen: CD / MP3 CD RADIO activate / deactivate RDS activate / deactivate Intro activate / deactivate track repeat (of the current folder / artist / genre / playlist) activate / deactivate track repeat (the activate / deactivate REG mode...
SCREEN MENU MAP(S) Screen C Pressing the MENU button displays: Audio functions Vehicle diagnostics FM waveband settings Alert log Alternative frequencies (RDS) activate / deactivate Regional mode (REG) activate / deactivate Radio-text information (RDTXT) activate / deactivate Play modes Album repeat (RPT) activate / deactivate Track random play (RDM) activate / deactivate...
Page 327
SCREEN MENU MAP(S) Personalisation-Configuration Bluetooth telephone Defi ne the vehicle settings * Bluetooth confi guration Display confi guration Connect/Disconnect an equipment Video brightness adjustment Telephone function normal video Audio Streaming function inverse video Consult the paired equipment brightness (- +) adjustment Delete a paired equipment Date and time adjustment Perform a Bluetooth search...
FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION There is a difference in For optimum sound quality, the audio settings (Volume, Bass, Treble, Check that the audio settings (Volume, Bass, sound quality between Ambience, Loudness) can be adapted to the different sound sources, Treble, Ambience, Loudness) are adapted to the different audio which may result in audible differences when changing source (radio,...
Page 329
RDS mode. a failure of the audio equipment. displayed...). The aerial is absent or has been damaged (for example when going Have the aerial checked by a PEUGEOT dealer. through a car wash or into an underground car park).
Page 330
FREQUENTLY ASKED QUESTIONS QUESTION ANSWER SOLUTION Sound cut-outs of 1 to During this brief sound cut-out, the RDS searches for any frequency Deactivate the RDS function if the phenomenon is 2 seconds in radio mode. permitting better reception of the station. too frequent and always on the same route.
Page 331
ALPHABETICAL INDEX ABS and EBFD systems....103 Automatic rain sensitive windscreen Changing a fuse ....... 186-192 Changing a wheel ..... 168-172 Accessories ........199 wipers ........97, 99 Changing a wiper blade ... 100, 174 Accessory socket, 12V ...... 83 Auxiliary Changing the remote control battery ..
Page 339
TECHNICAL DATA - MAINTENANCE Petrol engines Petrol weights Diesel engine Diesel weights Dimensions Identifi cation markings Running out of fuel, Diesel Energy economy mode Battery 176-177 Checking levels 156-158 - oil - brake fl uid - power steering fl uid - coolant - screenwash/headlamp wash fl...
Page 343
PEUGEOT dealer is able Your vehicle will be fi tted with some of the to provide. equipment described in this document Automobiles PEUGEOT declares, by depending on the version and the specifi...
Page 344
Anglais AN. 14RCZ.0040 www.peugeot.com...
Need help?
Do you have a question about the RCZ and is the answer not in the manual?
Questions and answers
