POWER Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc., but may be reproduced or duplicated without the prior permission of Cross Technologies, Inc. for purposes of operating the equipment. When ordering parts from Cross Technologies, Inc., be sure to include the equipment model number, equipment serial number, and a description of the part.
Page 2
WARRANTY - The following warranty applies to all Cross Technologies, Inc. products. All Cross Technologies, Inc. products are warranted against defective materials and workmanship for a period of one year after shipment to customer. Cross Technologies, Inc.’s obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s option, replacing parts, subassemblies, or entire assemblies.
1.1 Equipment Description The 2000-2XX LNB Power Supply is a switching power supply which provides either regulated +12 VDC (- 212) at 1 amp, +15 VDC (-215) at 1 amp, +18 VDC (-218) at 0.5 amps OR +24 VDC (-224) at 1 amp through RF connectors for insertion on an RF line.
1.2 Technical Characteristics TABLE 1.0 2000-2XX LNB Power Supply Specifications* RF Input/Output Characteristics Impedance/Return Loss 75Ω/14 dB Frequency 950 - 2150 MHz Insertion Loss 1 ± 0.5 dB Frequency Response ±1.0 dB AC Input Characteristics Voltage 100- 240 ±10% VAC...
2.0 Installation 2.1 Mechanical The 2000-2XX is packaged in an aluminum extrusion. The -R option is mounted on a 1 3/4” X 19” panel that can be mounted to a rack using t he 4 holes at the ends. REAR SCREWS (4EA) POWER SUPPLY CABLE...
2.2 Rear Panel Input/Output Signals - Figure 2.2 shows the input and output connectors on the rear panel. DS1 - DC ON RF F1 - FUSE J3 - REF IN Lights yellow when the DC When the provided fuse is inserted, Connect the external 10 MHz supply voltage is present the supply voltage, 0.5 amps max.
2.4 Operation 2.4.1 Installing and Operating the 2000-2XX LNB Power Supply 1. Connect an RF signal to RF connector, J2 (Figure 2.2). 2. Connect RF+DC connector, J1, to the external equipment (Figure 2.2). 3. To insert +12VDC, +15VDC, +18VDC or +24VDC on the RF signal insert a 1 amp fuse (provided) in fuse holder, F1 (Figure 2.2).
ROSS ECHNOLOGIES, INC. 6170 Shiloh Road Alpharetta, Georgia 30005 (770) 886-8005 FAX (770) 886-7964 Toll Free 888-900-5588 WEB www.crosstechnologies.com E-MAIL info@crosstechnologies.com Printed in USA 2000-2XX Manual_Rev. D Page 8 05/08/13...
