1. Overview
1.1 Front View
2. Scene Buttons
3. Faders
4. Page Select Button
5. Fog Machine Button
6. Speed Slider
7. Fade Time Slider
8. LCD Display
9. Pan Wheel
10. Tilt Wheel
11. Program Button
12. Music/Bank Copy
13. MIDI/Rec
14. Auto/Del
15. Bank Up/Down
16. Tap/Display
17. Blackout Button
18. Chase Buttons(1-6)
19. Fine Button
20. Mode Button
5
Press the scene buttons to load or stored your scenes.
There are a maximum of 240 programmable scenes.
These faders are used to control the intensity of channel 1-8
or channel 9-16 depending upon the selected page.
Used to select page between Page A(1-8) and Page B(9-16).
Activates Fog Machine .
Used to adjust the chase speed within the range of 0.1 second
to 10 minutes.
Used to adjust the fade time. Fade time is the amount of time
it takes for a fixture(or scanner) to move from one position to
another, for the dimmer to fade in or fade out.
Shows the current activity or programming state.
This jog wheel is used to control the pan of the scanner or for
programming.
This jog wheel is used to control the Tilt of the scanner or for
programming.
Activates Program mode.
Activates Music mode or to copy a bank of scenes.
Used to control MIDI operation or to record programs.
Activates Auto mode or to delete scenes or chases.
Press the Up/Down button to select from 30 banks.
Used to create a standard beat or to change the value mode
between % and 0-255.
Tap to momentarily pause whole output.
These buttons are used for activating the chase of
programmed scenes.
When Fine is on, the Pan or Tilt wheel will control the
scanner in the smallest increment.
Pressing Fine and Mode buttons allows to activate Assign
or Reverse mode.
