Contents
Features 1
General Instructions 2
1. Overview 3
1.1 Front View 3
1.2 Rear View 6
2. Operation Guide 7
2.1 Program Enable 7
2.2 Programming Scenes 8
2.2.1 Scene Editing 11
2.2.2 Scanner Copy 12
2.2.3 Scene Copy 13
2.2.4 Delete a Scene 15
2.2.5 Delete all Scenes 15
2.2.6 Bank Copy 16
2.3 Programming Chases 17
2.3.1 Program a bank of scenes into a Chase 18
2.3.2 Add a Step 18
2.3.3 Delete a Step 20
2.3.4 Delete a Chase 21
2.3.5 Delete all Chases 21
2.4 Assign/Reverse DMX channel 22
2.4.1 Assign DMX channel 22
2.4.2 Reverse DMX channel 24
2.4.3 Fade Time/Assign Fade Time 26
2.4.4 Delete a scanner of DMX channel 27
2.4.5 Clear all DMX channels 28
2.4.6 Display DMX channel 28
2.5 Set Up a new Logo 30
2.6 Running Scenes 32
2.6.1 Manual Mode 32
2.6.2 Auto Mode 32
2.6.3 Music Mode 34
2.7 Running Chases 35
2.7.1 Manual Mode 35
2.7.2 Auto Mode 35
2.7.3 Music Mode 36
Improvement and changes to
2.8 MIDI Operation 37
specifications, design and this
2.8.1 MIDI Channel Setting 37
manual, may be made at any time
2.8.2 Implementation 38
without prior notice.
2.9 Send File Dump 39
All rights reserved.
2.10 Receive File Dump 40
Technical Specifications 41
