- Page 1 Service-manual RL-8...
- Page 2 Schalter „Phono/Line“ für DJ-24 5 E0193726 Schalter „CH-1/CH-2“ für DJ-24 Switch „CH-1/CH-2“ for DJ-24 Schalter „CH-1/CH-2“ für DJ-24 6 E0193730 Poti „Cue Level“ für DJ-24 Poti „Cue Level“ for DJ-24 Poti „Cue Level“ für DJ-24 7 E0193740 Fader „Phono/Line“ für DJ-24 Fader „Phono/Line“...
- Page 3 R124 SW4B CUE1_R HEADER 3 HEADER 3 HEADPHONES OUT R125 180K CUE2_R R130 CH1/CH2 CUE SW VR3B 39 1/4W 50KA 4556 100uF/16V R126 4.7uF/50V OMNITRONIC ® BIGROUP CORP Title DJ-24 SCH Size Document Number MASTER.SCH Date: August 14, 1999 Sheet...
- Page 4 DJ-24 BLOCK DIAGRAM HP AMP HEADPHONES HP AMP CUE LEVEL RIAA AMP PHONO1 RIAA AMP REC. L LINE1 LEVEL REC. R MASTER L PWR ON/OFF MUTING MASTER R CROSSFADER PWR ON/OFF MUTING CH1/CH2 CUE SW RIAA AMP LED DRIVE PHONO2...
- Page 5 100pF R52C HEADER 5 CUE2 R 100K R53A R53B SW3B 4558P 4558P CH2.RCF +12V 47uF/16V 4558P 4.7uF/50V MIX_R R52B R52A 5.6K VR2B 100K 100K 50KA OMNITRONIC ® BIGROUP CORP Title DJ-24 Size Document Number CHANNEL.SCH Date: August 25, 1999 Sheet...
- Page 6 JK104 1A 250V CN105 1000uF/25V 100uF/16V AC 10V IN4001 +12V AC JACK TO JP105 IN4001 -12V HEADER 3 1000uF/25V 100uF/16V 1000uF/16V IN4001 LM7912 IN4001 OMNITRONIC ® BIGROUP CORP Title DJ-24 SCH Size Document Number OUT.SCH Date: June 23, 1999 Sheet...
- Page 7 100pF 5.6K LINE 2 JK101D JK102B R19A R19B R20A R20B C21A 5.6K C21B 5.6K 100pF 100pF -12V C23A C23B 0.1uF 0.1uF 4558P 4558P +12V OMNITRONIC ® BIGROUP CORP Title DJ-24 SCH Size Document Number INPUT.SCH Date: June 23, 1999 Sheet...
