INSTALLATION AND OPERATING INSTRUCTIONS
Safety Instructions, Installation Instructions, Operation Instructions
Maintenance Instructions, Replacement Parts List, Warranty/Service Information
Please complete this information and retain this manual for the life of the equipment. For
Warranty Service and/or Parts, this information is required.
Model Number
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or liquids
!
in the vicinity of this or any other appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
!
cause property damage, injury or death.
maintenance instructions thoroughly before installing, or servicing this equipment.
WARNING: Instructions must be posted in a prominent location. All safety precautions
!
must be taken in the event the user smells gas. Safety information can be obtained from
your local gas supplier.
+1 (307) 634-5801 Phone
+1 (307) 637-8071 Fax
Gas Hot Plate
MODELS:
GHP-2H, GHP-4H, GHP-6H, GHPW-2H,
GHPS-2H, GHPS-4H, GHPS-6H
PRODUCT MANUAL
IMPORTANT FOR FUTURE REFERENCE
Serial Number
APW WYOTT Foodservice Equipment Company
P.O. Box 1829
Cheyenne, WY 82003
R
Read the installation, operating and
1
Date Purchased
!
!
ANSI/NSF4
P/N 8838900 4-09
+1 (800) 752-0863 Toll Free
www.apwwyott.com
!
Advertisement
Table of Contents
Related Manuals for APW Wyott GHP-2H
Summary of Contents for APW Wyott GHP-2H
- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS Gas Hot Plate MODELS: GHP-2H, GHP-4H, GHP-6H, GHPW-2H, GHPS-2H, GHPS-4H, GHPS-6H PRODUCT MANUAL Safety Instructions, Installation Instructions, Operation Instructions Maintenance Instructions, Replacement Parts List, Warranty/Service Information IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or Parts, this information is required.
-
Page 2: Safety Precautions
Installation and start-up should be performed by a qualified installer who thoroughly read, understands and follows these instructions. If you have questions concerning the installation, operation, maintenance or service of this product, write Technical Service Department APW Wyott Foodservice Equipment Company, P.O. Box 1829, Cheyenne, WY 82003. 1. SAFETY PRECAUTIONS Before installing and operating this equipment be sure everyone involved in its operation is fully trained and is aware of all precautions. -
Page 3: Table Of Contents
The countertop hot plate, models GHP-2H, -4H, -6H and GHPS-2H, -4H, -6H provides countertop heating and cooking capabilities. These units incorporate 2, 4 or 6 burners at 30,000 BTU/Hr each for fast, even cooking and heating. -
Page 4: General Installation Instructions
Installation and start-up should be performed by a qualified installer who thoroughly read, understands and follows these instruction. If you have questions concerning the installation, operation, maintenance or service of this product, write Technical Service Department APW Wyott Foodservice Equipment Company, P.O. Box 1829, Cheyenne, WY 82003. 2. GENERAL INSTALLATION INSTRUCTIONS: Ensure gas supply and gas type, as shown on unit data plate agree. -
Page 5: Lighting Instructions
4. LIGHTING INSTRUCTIONS Lighting instructions are located on the rear panel. Access to the pilot valves are gained through openings in the front panel. Access to the pilot burner is gained by removing the top grate. Lighting Pilot Burner: Turn all burners to the “OFF” position. Turn on the main gas supply to the unit. -
Page 6: Conversion
Clockwise increases pressure and counter-clockwise decreases pressure. Manifold pressure should be 6 inches (15.2cm) water column for Natural gas. Leak test all joints. If you should have any questions or problems, contact your nearest APW Wyott Service Representative. -
Page 7: Replacement Parts List & Exploded View
7. REPLACEMENT PARTS LIST & EXPLODED VIEW GHP-2H (CE) - Page 8 Varies 2065914 Venturi, Rear, 12.578" Lg. Varies Gasket, Burner 2065916 Varies 2201610 Varies Grate, Individual, GHP-2H Nut, U-type 8196601 21813313 Side Panel, LH & RH T/S #10 X ½ TPB Tr Hd Side Panel, LH & RH GHPW 81973-00 21815584...
- Page 9 NOTES:...
- Page 10 NOTES:...
-
Page 11: Warranty
APW Wyott's option or its Authorized Service Agency, it will be serviced on site or replaced. From day two through the conclusion of this warranty period, portable units must be taken to or sent prepaid to the APW Wyott Authorized Service Agency for in-warranty repairs. - Page 12 APW WYOTT Foodservice Equipment Company P.O. Box 1829 Cheyenne, WY 82003 +1 (307) 634-5801 Phone +1 (800) 752-0863 Toll Free +1 (307) 637-8071 Fax www.apwwyott.com...
