APW Wyott Gas Hot Plate GHP-2H Installation And Operating Instructions Manual
Gas hot plate
Hide thumbs
Also See for Gas Hot Plate GHP-2H:
- Specifications (2 pages) ,
- Installation and operating instructions manual (12 pages)
Table of Contents
Advertisement
Quick Links
INSTALLATION AND OPERATING INSTRUCTIONS
Please complete this information and retain this manual for the life of the equipment. For
Warranty Service and/or Parts, this information is required.
Model Number
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and
!
liquids in the vicinity of this or any other appliance.
WARNING: Improper installation, operation, service or maintenance can cause property
!
damage, injury or death. Read and understand these instructions thoroughly before
positioning, installing, maintaining or servicing this equipment.
+1 (307) 634-5801 Phone
+1 (307) 637-8071 Fax
Gas Hot Plate
MODELS:
GHP-2H, GHP-4H, GHP-6H, GHPW-2H,
GHPS-2H, GHPS-4H, GHPS-6H
Safety Instructions
Installation Instructions
Operation Instructions
Maintenance Instructions
Replacement Parts List
Warranty/Service Information
IMPORTANT FOR FUTURE REFERENCE
Serial Number
APW WYOTT Foodservice Equipment Company
P.O. Box 1829
Cheyenne, WY 82003
R
Date Purchased
+1 (800) 752-0863 Toll Free
www.apwwyott.com
!
!
Advertisement
Table of Contents
Related Manuals for APW Wyott Gas Hot Plate GHP-2H
Summary of Contents for APW Wyott Gas Hot Plate GHP-2H
- Page 1 WARNING: Improper installation, operation, service or maintenance can cause property damage, injury or death. Read and understand these instructions thoroughly before positioning, installing, maintaining or servicing this equipment. APW WYOTT Foodservice Equipment Company +1 (307) 634-5801 Phone +1 (307) 637-8071 Fax...
-
Page 2: Safety Precautions
If you have questions concerning the installation, operation, maintenance or service of this product, write Technical Service Department APW Wyott Foodservice Equipment Company, P.O. Box 1829, Cheyenne, WY 82003. Before installing and operating this equipment be sure everyone involved in its operation is fully trained and is aware of all precautions. -
Page 3: Table Of Contents
½ psi (3.45 kPa). Congratulations on your purchase of APW Wyott commercial cooking or refrigeration equipment. APW Wyott takes pride in the design and quality of our products. When used as intended and with proper care and maintenance, you will experience years of reliable operation from this equipment. -
Page 4: General Installation Instructions
Installation and start-up should be performed by a qualified installer who thoroughly read, understands and follows these instruction. If you have questions concerning the installation, operation, maintenance or service of this product, write Technical Service Department APW Wyott Foodservice Equipment Company, P.O. Box 1829, Cheyenne, WY 82003. 2. GENERAL INSTALLATION INSTRUCTIONS: Ensure gas supply and gas type, as shown on unit data plate agree. -
Page 5: Lighting Instructions
Lighting instructions are located on the rear panel. Access to the pilot valves are gained through openings in the front panel. Access to the pilot burner is gained by removing the top grate. Lighting Pilot Burner: Turn all burners to the “OFF” position. Turn on the main gas supply to the unit. -
Page 6: Conversion
Clockwise increases pressure and counter-clockwise decreases pressure. Manifold pressure should be 6 inches (15.2cm) water column for Natural gas. Leak test all joints. If you should have any questions or problems, contact your nearest APW Wyott Service Representative. 6. CONVERSION... -
Page 7: Replacement Parts List & Exploded View
7. REPLACEMENT PARTS LIST & EXPLODED VIEW GHP-2H (CE) - Page 8 Item Description 8417100 Nut, Hex, KEPS 10-32 Screw, 10-32 X 1/2 Tr Hd, SS 8175900 8170700 Screw, 10-32x1/2, Type AB 2065916 Gasket, Burner 8196601 Nut, U-type 81973-00 T/S #10 X ½ TPB Tr Hd 2092621 Pipe, 3/4" Sch. 40, 20-5/8 Hood, Orifice, #52 2066852 Decal, Front Panel GHP 2 Burner...
- Page 9 NOTES:...
- Page 10 NOTES:...
- Page 12 APW WYOTT Foodservice Equipment Company P.O. Box 1829 Cheyenne, WY 82003 +1 (307) 634-5801 Phone +1 (800) 752-0863 Toll Free +1 (307) 637-8071 Fax www.apwwyott.com...
