TC-Helicon VoiceWorksPlus User Manual page 29

Chord types and voicings
table
The following gives additional detail on Chords mode.
It shows the range of chords recognized by Harmony4
based on a chord root of C in the left column. To the
right in the table is the combination of notes that are
required to be played in order for Harmony4 to
recognize each chord type.
Recognized Chord Types with Root
of C
Type Required Notes
Maj C E G
Maj6 C E G
Maj7 C E G
Maj7sus4 C F G
Min C Eb G
Min6 C Eb G
Min7 C Eb G
Min7b5 C Eb Gb
Dim C Eb Gb
Dim7 C Eb
Dom7 C E G
Dom7b5 C E Gb
Aug C E G#
Aug7 C E G#
Sus C F G
Sus2 C D G
Sus7 C F G
25
25
HARMONY BACKGROUND AND TIPS
A
B
B
A
Bb
Bb
Gb Bbb (equiv. to A)
Bb
Bb
Bb
Bb
Voicing intervals in Chord mode
presets
+2 Octaves
+1 Octave
Unison
Down 1
Down 2
Down 3
Down 4
Down 5
-1 Octave
-2 Octaves
Bass 2
Bass 1
Root 2
Root 1
Up 6
Up 5
Up 4
Up 3
Up 2
Up 1
25
