Omron M3 Instruction Manual

A. Display
B. O/I START ( ) button
C. User A/B button
D. Up/Down ( ) buttons
E. Buzzer and Date/Time
setting ( ) button
Digital Automatic Blood
Pressure Monitor Arm cuff:
I J K
Model M3 Family
Instruction Manual
IM-HEM-7202-ARU-02-06/2012
5334156-4B
L
Introduction
AC adapter:
Thank you for purchasing the OMRON M3 Family Digital Automatic Blood
Pressure Monitor.
The OMRON M3 Family is a compact, fully automatic blood pressure monitor,
operating on the oscillometric principle. It measures your blood pressure and
pulse rate simply and quickly. For comfortable controlled inflation without the
need of pressure pre-setting or re-inflation the device uses its advanced
"IntelliSense" technology.
Intended Use
Display:
M
This product is designed to measure the blood pressure and pulse rate of
people within the range of the designated arm cuff, following the instructions in
N
this instruction manual.
It is mainly designed for general household use. Please read the Important
O
Safety Information in this instruction manual before using the unit.
P
Please read this instruction manual thoroughly before using the unit.
Q
Please keep for future reference.
R
For specific information about your own blood pressure, CONSULT YOUR
DOCTOR. S
T
Important Safety Information M. Systolic blood pressure
N. Diastolic blood pressure
Consult your doctor prior to using in pregnancy or if diagnosed with arrhythmia O. Heartbeat symbol
or arteriosclerosis.
(Flashes during measurement)
Please read this section carefully before using the unit.
P. Average value symbol
Warning: Q. Memory symbol
• Indicates a potentially hazardous situation which, if not avoided, could result in
R. Deflation symbol
death or serious injury.
S. Irregular heartbeat symbol
(General Usage)
• Always consult your doctor. Self-diagnosis of measurement results and self-
treatment are dangerous.
2. Preparation
• People with severe blood flow problems, or blood disorders, should consult a
doctor before using the unit, as cuff inflation can cause internal bleeding.
2.1 Using the AC Adapter
(AC Adapter Usage)
1. Insert the AC adapter plug
(Battery Usage)
into the AC adapter jack on
• If battery fluid should get in your eyes, immediately rinse with plenty of clean
water. Consult a doctor immediately. the rear side of the main
Caution:
unit.
• Indicates a potentially hazardous situation which, if not avoided, may result in
2.
minor or moderate injury to the user or patient or damage to the equipment or Plug the AC adapter into an
other property.
electrical outlet.
(General Usage)
• Do not leave the unit unattended with infants or persons who cannot express their
To disconnect the AC adapter, unplug the AC adapter from the
consent.
electrical outlet first and then remove the AC adapter plug from the
• Do not use the unit for any purpose other than measuring blood pressure.
main unit.
• Do not disassemble the unit or arm cuff.
• Use only the approved arm cuff for this unit. Use of other arm cuffs may result in
2.2 Installing/Replacing the Batteries
incorrect measurement results.
• Make sure that the air tube is not wrapped around other parts of your body when 1.
Remove the battery cover.
taking measurements. This could result in injury when the air pressure in the air
tube is increased.
2.
Insert four "AA" batteries
• Do not leave the cuff wrapped on the arm if taking measurements during the
night. This could result in injury. as indicated in the battery
• Do not inflate the arm cuff over 299 mmHg.
compartment and then
• Do not use a mobile phone or other devices that emit electromagnetic fields, near
replace the battery cover.
the unit. This may result in incorrect operation of the unit.
• Do not operate the unit in a moving vehicle (car, airplane).
Notes:
• To inflate the cuff manually, refer to Section 3.3. If the cuff is over inflated, it can
• If the battery low symbol (
cause internal bleeding.
then replace all batteries at the same time.
(AC Adapter Usage)
• The measurement values continue to be stored in memory even after
• Use only the original AC adapter designed for this unit. Use of unsupported
the batteries are replaced.
adapters may damage and/or may be hazardous to the unit.
• Plug the AC adapter into the appropriate voltage outlet. Do not use a multiple-tap. Disposal of used batteries should be carried out in accordance with the
• Do not use the AC adapter if the unit or the power cord is damaged. Turn off the national regulations for the disposal of batteries.
power and unplug the power cord immediately.
(Battery Usage) 2.3 Setting the Buzzer/ Date and Time
• If battery fluid should get on your skin or clothing, immediately rinse with plenty of
1. Press the button.
clean water.
• Use only four "AA" alkaline or manganese batteries with this unit. Do not use
2. Set the Buzzer.
other types of batteries.
• Do not insert the batteries with their polarities incorrectly aligned.
• Replace old batteries with new ones immediately. Replace all four batteries at the
1) Push or
same time.
select On or Off.
• Remove the batteries if the unit will not be used for three months or more.
2) Push the
• Do not use new and used batteries together.
confirm.
General Precautions
• Do not apply strong shocks and vibrations to or drop the unit and arm cuff.
3. Set the monitor to the correct date and time before
• Do not take measurements after bathing, drinking alcohol, smoking, exercising or
eating. taking a measurement for the first time.
• Do not forcibly bend the arm cuff or bend the air tube excessively.
• When removing the air tube, pull on the air plug at the connection with the main
unit not the tube itself.
• Do not inflate the arm cuff when it is not wrapped around your arm.
• Do not wash the arm cuff or immerse it in water.
• Read and follow the "Important information regarding Electro Magnetic Compatibil-
ity (EMC)" in the Technical Data Section.
• Read and follow the "Correct Disposal of This Product" in the Technical Data
Section when disposing of the device and any used accessories or optional parts.
Year
1. Overview
Main unit:
A G
4. Press the O/I START button to store the setting.
Notes:
• If the batteries have been removed for 30 seconds or more, the date
B
and time setting will need to be reset.
H • If the date and time are not set, "-:--" appears during or after
F
measurement.
C
E
D
3. Using the Unit
F. Air Jack
3.1 Applying the Arm Cuff
G. Battery compartment
H. AC adapter jack
Remove tight-fitting clothing or tight rolled up sleeve from your
upper arm.
Do not place the cuff over thick clothes.
1. Insert the air plug into the air jack.
I. Arm cuff (Wide Range Cuff: arm
circumference 22 - 42 cm)
J. Marker
K. Air tube
L. Air plug
2. Put your arm through the cuff loop.
Storage case:
3.
Position the arm correctly.
U
V
W
X
Y
Z
AA
The bottom edge of the cuff should be 1 to 2 cm above the elbow.
T. Date/Time display
Marker (arrow under tube) is centred on the middle of your inner arm.
U. Blood pressure level indicator
Close the fabric fastener FIRMLY.
V. Pulse display and Memory
number
W. Buzzer symbol
X. Cuff wrapping guide
Y. User ID symbol (A/B) 1 to 2 cm
Z. Battery low symbol
AA. Movement error symbol
Notes:
• When you take a measurement on the right
arm, air tube will be at the side of your
elbow. Be careful not to rest your arm on
the air tube.
• The blood pressure can differ between the right arm and the left arm,
and therefore also the measured blood pressure values can be
different. OMRON recommends to always use the same arm for
measurement. If the values between the two arms differ substantially,
please check with your physician which arm to use for your
measurement.
3.2 How to Sit Correctly
To take a measurement, you need to be
relaxed and comfortably seated, under
comfortable room temperature. No eating,
smoking or exercising 30 minutes before
taking a measurement.
• Sit on a chair with your feet flat on the floor.
• Sit upright with your back straight.
• The cuff should be at the same level as your
heart.
) appears on the display, turn the unit off
Cuff Wrapping Guide
The Cuff Wrapping Guide is a unique feature that indicates if the cuff is not
wrapped tightly enough around the arm. Even when the is displayed, a
blood pressure reading will be taken.
Note: This reading is NOT reliable due to the incorrect wrapping of the cuff.
Please wrap the cuff again, taking care to wrap it correctly and take the
measurement again.
When the is displayed, the cuff is correctly wrapped tightly enough on
the arm and the reading is accurate and reliable.
buttons to
3.3 Taking a Reading
Notes:
button to
• To cancel a measurement, press the O/I START button to turn off the
On Off
unit and to release the air in the arm cuff.
• Remain still while taking a measurement.
1. Press the O/I START button.
1) Push or buttons to
change.
2) Push the button to confirm.
Next setting appears.
2. Select your USER ID (A or B).
Month Day
Hour Minute
3.
Press the O/I START button again.
The cuff will start to inflate automatically.
The buzzer will sound when measurement is completed.
START INFLATE DEFLATE END COMPLETE To Delete All the Values Stored in Memory
The values stored in the memory are deleted by USER ID.
When the memory symbol (
Then while holding it down, press the O/I START button
simultaneously for about 2 - 3 seconds.
If your systolic pressure is more than
220 mmHg
After the cuff starts to inflate, press and hold the O/I START
button until the monitor inflates 30 to 40 mmHg higher than
Note: You cannot partially delete values stored in the memory.
your expected systolic pressure.
All values for the user you select will be deleted.
Notes:
• The monitor will not inflate above 299 mmHg.
• Do not apply more pressure than necessary.
4. Troubleshooting and Maintenance
Notes:
4.1 The Icons and Error Messages
• During measurement, the buzzer (if set to "on") will beep in rhythm
with your heartbeat.
Error Display Cause
• Wait 2-3 minutes before taking another blood pressure measurement.
Waiting between readings allows the arteries to return to the condition
prior to taking the blood pressure measurement.
Warning: Irregular or weak pulses are
detected.
Self-diagnosis of measured results and treatment are dangerous.
Please follow the instructions of your doctor.
4.
Remove the arm cuff.
Movement during
measurement.
5.
Press the O/I START button to turn off the monitor.
The monitor automatically stores the measurement in its
Cuff is not applied correctly.
memory.
It will automatically turn off after five minutes.
Important:
• Recent research suggests that the following Blink The batteries are low.
values can be used as a guide to high blood
pressure for measurements taken at home.
The batteries are
Lit
exhausted.
Systolic Blood Pressure Above 135 mmHg
Cuff is under inflated.
Diastolic Blood Pressure Above 85 mmHg
This criteria is for home blood pressure measurement.
• Your blood pressure monitor includes an irregular Movement during
heartbeat feature. Irregular heartbeats can influence measurement.
the results of the measurement. The irregular
heartbeat algorithm automatically determines if the
measurement is usable or needs to be repeated. If the
Air plug disconnected.
measurement results are affected by irregular
heartbeats but the result is valid, the result is shown
together with the irregular heartbeat symbol ( ). If the Arm cuff not applied
irregular heartbeats cause the measurement to be
correctly.
invalid, no result is shown. If the irregular heartbeat
symbol ( ) is shown after you have taken a measurement, repeat
the measurement. If the irregular heartbeat symbol ( ) is shown Clothing is interfering with
frequently, please make your doctor aware of it.
the arm cuff.
• If you move during measurement, the movement error
symbol ( ) will appear on the display. Keep still and Air is leaking from the arm
repeat the measurement. cuff.
The arm cuff was inflated
above 299 mmHg when
inflating the cuff manually.
3.4 Using the Memory Function
The monitor automatically stores the result up to 60 sets for each user
Device error.
(A and B). It can also calculate an average reading based on the
measurements from the last three readings taken within 10 minutes. If
there are only two readings in memory for that period, the average will
Note: The irregular heartbeat symbol (
be based on two readings. If there is one reading in memory for that
messages.
period, the average will be based on one reading.
Notes:
• If the memory is full, the monitor will delete the oldest readings.
4.2 Troubleshooting
• When viewing the reading taken without setting the date and time,
"-:--" is displayed instead of the date and time.
Problem
To View the Average Value
Arm cuff not applied
1. Press the or button. correctly.
2.
Select your USER ID ( ).
The reading is
Movement or talking
extremely low (or
during measurement.
high).
Clothing is interfering
with the arm cuff.
Note: If there are no measurements results
stored in the memory, the screen to the
The air tube is not
right is displayed.
securely connected
Arm cuff pressure into the main unit.
does not rise.
Air is leaking from the
To View the Readings Stored in Memory arm cuff.
1.
Press the button, while the average value is displayed.
Arm cuff deflates too
The Memory number appears
The arm cuff is loose.
for a second before the pulse soon.
Alternating date/time
rate is displayed. The newest
display
set is numbered "1".
Cannot measure or The arm cuff has not
readings are too low been inflated
or too high. sufficiently.
2. Press the or button to view the readings stored in
memory.
: To the older readings
: To the more recent readings
Problem Cause Remedy
Replace the batteries
The batteries are
) appears, first press the button. with new ones.
empty.
Nothing happens
Refer to section 2.2.
when you press the
The batteries have Insert the batteries with
buttons.
been inserted the correct (+/-) polarity.
incorrectly. Refer to section 2.2.
• Press the O/I START button and repeat
measurement.
• If the problem continues, try replacing the
Other problems.
batteries with new ones.
If this still does not solve the problem, contact
your OMRON retail outlet or distributor.
4.3 Maintenance
To protect your unit from damage, please observe the following:
• Do not subject the main unit and the cuff to extreme
Remedy
temperatures, humidity, moisture or direct sunlight.
Remove the arm cuff. Wait
• Do not fold the cuff or tubing tightly.
2-3 minutes and then take
• Do not disassemble the unit.
another measurement.
Repeat the steps in section • Do not subject the unit to strong shocks or vibrations
3.3. If this error continues to (for example, dropping the unit on the floor).
appear, contact your doctor.
• Do not use volatile liquids to clean the main unit.
• Do not wash the arm cuff or immerse it in water.
Carefully read and repeat
the steps in section 3.3.
• Do not use petrol, thinners or similar solvents to clean
the arm cuff.
Apply the arm cuff correctly.
• Do not carry out repairs of any kind yourself. If a defect
Refer to section 3.1.
occurs, consult your OMRON retail outlet or distributor
You should replace them
as mentioned on the packaging.
with new ones ahead of
time.
Refer to section 2.2.
You should replace them
with new ones at once.
Refer to section 2.2.
Carefully read and repeat
the steps listed under
section 3.3.
Repeat measurement.
Remain still and do not talk
during measurement.
Refer to section 3.3.
Insert the air plug securely.
• The unit should be cleaned with a soft, dry cloth.
Refer to section 3.1.
• Use a soft, moistened cloth and soap to clean the arm
Apply the arm cuff correctly.
cuff.
Refer to section 3.1.
Calibration and Service
Remove any clothing
interfering with the arm cuff. • The accuracy of this blood pressure monitor has been
Refer to section 3.1.
carefully tested and is designed for a long service life.
• It is generally recommended to have the unit inspected
Replace cuff with new one.
Refer to Chapter 5. every two years to ensure correct functioning and
accuracy. Please consult your authorised OMRON
dealer or the OMRON Customer Service at the address
Do not inflate the arm cuff
above 299 mmHg. given on the packaging or attached literature.
Refer to section 3.3.
4.4 Storage
Contact your OMRON retail
outlet or distributor. Keep the unit in its storage case when not in use.
1.
) may also be displayed with error Unplug the air tube from the air connector.
2. Gently fold the air tube into the arm cuff.
Note:
Do not bend the air tube excessively.
Cause Remedy
Apply the arm cuff
correctly.
Refer to section 3.1.
3.
Place the arm cuff and main unit in the
Remain still and do not
talk during storage case.
measurement.
Refer to section 3.3.
Do not store the unit in the following situations:
Remove any clothing
• If the unit is wet.
interfering with the arm
• Locations exposed to extreme temperatures,
cuff.
humidity, direct sunlight, dust or corrosive
Refer to section 3.2.
vapours.
Make sure that the air
• Locations exposed to vibrations, shocks or where it will be at an
tube is connected
angle.
securely.
Refer to section 3.1.
5. Optional Parts
Replace the arm cuff
with a new one.
Wide range cuff Medium Arm Cuff Large Arm Cuff
Refer to Chapter 5.
Arm circumference Arm circumference Arm circumference
22 - 42 cm 22 - 32 cm 32 - 42 cm
Apply the cuff correctly
so that it is firmly
wrapped around the arm.
Refer to section 3.1.
Inflate the cuff so that it
CW-9520534-2 CM-9515371-7 CL-9515370-9
is 30 to 40 mmHg above
your previous
measurement result. AC Adapter S
Refer to section 3.3.
Adapter S-9515336-9
HEM-7202-ARU_A_M05_111019.pdf
6. Technical Data
Product Description Digital Automatic Blood Pressure Monitor
Model OMRON M3 Family (HEM-7202-ARU)
Display LCD Digital Display
Measurement Method
Oscillometric method
Measurement Range Pressure: 0 mmHg to 299 mmHg
Pulse: 40 to 180/min.
Accuracy Pressure: ±3 mmHg
Pulse: ±5% of display reading
Inflation Fuzzy-logic controlled by electric pump
Deflation
Automatic pressure release valve
Memory
60 Measurements with date and time for each user
(A and B)
Rating DC6V 4W
Power Source 4 "AA" batteries 1.5V or AC/ DC adapter
(Adapter S-9515336-9, INPUT AC100-240V 50/60Hz
0.12A)
Battery Life Capacity of new alkaline batteries is approx.
900 measurements
Applied Part = Type B
Protection Against Internally powered ME equipment (When using only
Electric Shock the batteries)
Class II ME equipment (AC adapter)
Operating +10°C to +40°C / Maximum: 30 to 90% RH
temperature/ Humidity
Storage temperature/ -20°C to +60°C / Maximum: 10 to 95% RH /
Humidity/ Air pressure 700-1060 hPa
Console Weight Approximately 340g without batteries
Cuff Weight Approximately 170g
Outer Dimensions Approximately 123 (w) mm × 85 (h) mm × 141(l) mm
Cuff Dimensions Approximately 151 mm × 563 mm
(Wide range cuff: arm circumference 22 to 42 cm)
Cuff Material Nylon and polyester
Package Content Main unit, cuff, instruction manual, quick guide,
storage case, AC adapter, battery set, guarantee
card, blood pressure pass
Note: Subject to technical modification without prior notice.
• This device fulfils the provisions of EC directive 93/42/EEC (Medical Device
Directive).
• This blood pressure monitor is designed according to the European Standard
EN1060, Non-invasive sphygmomanometers Part 1: General Requirements
and Part 3: Supplementary requirements for electromechanical blood
pressure measuring systems.
• This OMRON product is produced under the strict quality system of OMRON
HEALTHCARE Co. Ltd., Japan. The Core component for OMRON blood
pressure monitors, which is the Pressure Sensor, is produced in Japan.
Important information regarding Electro Magnetic Compatibility (EMC)
With the increased number of electronic devices such as PC's and mobile
(cellular) telephones, medical devices in use may be susceptible to
electromagnetic interference from other devices. Electromagnetic interference
may result in incorrect operation of the medical device and create a potentially
unsafe situation.
Medical devices should also not interfere with other devices.
In order to regulate the requirements for EMC (Electro Magnetic Compatibility)
with the aim to prevent unsafe product situations, the EN60601-1-2:2007
standard has been implemented. This standard defines the levels of immunity to
electromagnetic interferences as well as maximum levels of electromagnetic
emissions for medical devices.
This medical device manufactured by OMRON HEALTHCARE conforms to this
EN60601-1-2:2007 standard for both immunity and emissions.
Nevertheless, special precautions need to be observed:
• Do not use mobile (cellular) telephones and other devices, which generate
strong electrical or electromagnetic fields, near the medical device. This may
result in incorrect operation of the unit and create a potentially unsafe situation.
Recommendation is to keep a minimum distance of 7 m. Verify correct operation
of the device in case the distance is shorter.
Further documentation in accordance with EN60601-1-2:2007 is available at OMRON
HEALTHCARE EUROPE at the address mentioned in this instruction manual.
Documentation is also available at www.omron-healthcare.com.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature, indicates that it
should not be disposed of, with other household wastes at the end
of its working life. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please separate
this product from other types of wastes and recycle it responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government office, for details of where and how they can
return this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions
of the purchase contract. This product should not be mixed with other commercial
wastes for disposal.
Manufacturer OMRON HEALTHCARE Co., Ltd.
53, Kunotsubo, Terado-cho, Muko, Kyoto,
617-0002 JAPAN
EU-representative
OMRON HEALTHCARE EUROPE B.V.
Scorpius 33, 2132 LR Hoofddorp
THE NETHERLANDS
www.omron-healthcare.com
Exclusive ComplectService Ltd.
distributor in 13-14 building, 26 B. Tishinskiy per.,
Russia & importer Moscow 123557, RUSSIA
www.csmedica.ru
Production Facility OMRON (DALIAN) CO., LTD.
Dalian, CHINA
Made in China
12E1291
