- Page 1 User’s Manual artec 500 series Antes de utilizar el equipo, lea la sección “Precauciones de seguridad” de este manual. Conserve este manual para futuras consultas. Before operating the device, please read the “Safety precautions” section of this manual. Retain this manual for future reference.
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS WARRANTY DECLARATION OF CONFORMITY 6 a 7 INTRODUCTION CONFIGURATIONS 8 a 11 4x artec 506 + 1x artec S15 4x artec 508 + 2x artec S15 4x artec 510 + 2x artec S15 4x artec 526 + 2x artec S15 LINE DRAWINGS SPECIFICATIONS ACCESSORIES... -
Page 3: Safety Precautions
500 series Precauciones de Seguridad Safety Precautions Cajas acústicas pasivas / Passive loudspeaker enclosures Conserve y lea todas estas instrucciones. Keep these instructions. Siga todas las advertencias. Heed all warnings. Follow all instructions. El signo de exclamación dentro de un triángulo indica la... -
Page 4: Warranty
GARANTÍA Todos nuestros productos están garantizados por un periodo de 24 meses desde la fecha de compra. Las garantías sólo serán válidas si son por un defecto de fabricación y en ningún caso por un uso incorrecto del producto. reparaciones garantía pueden realizadas,... -
Page 5: Declaration Of Conformity
C/ Islas Baleares, 24 - 46988 - Pol. Fuente del Jarro - Valencia. España (Spain). Declara que la serie artec 500: Declares that artec 500 series: Cumple con los objetivos esenciales de las Directivas: Abide by essential objectives relating Directives: Directiva de Baja Tensión (Low Voltage Directive) -
Page 6: Introduction
INTRODUCTION The artec 500 series full range systems have been designed to provide wide bandwidth and high SPL in a visually discrete package. The artec 500 products can be installed on walls, ceilings or columns thanks to an extensive selection of optional mounting accessories. The ideal choice for under balcony, area fill and near field applications, their reduced dimensions and sleek styling fits perfectly into multiple surrounding including hotels, restaurants and karaoke. - Page 7 artec 526 -Twin 6” loudspeakers -M-34 compression driver -Vertical or horizontal positioning -Threaded fixing points for wall mounts -Pole mount accessories The Artec 526 employs twin 6P woofers for low frequency reproduction. The M-34 comression driver provides brilliant highs. The birch plywood cabinet construction offers an ultra-compact design which is available in black or white.
-
Page 8: Configurations
CONFIGURATIONS 4 x Artec 506 1 x Artec S15 Standard Configuration LINK LINK From mixer DSP-2040 Bridge mode Manual del Usuario / artec 500 passive / User’s Manual... - Page 9 CONFIGURATIONS (cont´d) 4 x Artec 508 2 x Artec S15 Standard Configuration LINK LINK From mixer DSP-2040 Manual del Usuario / artec 500 passive / User’s Manual...
- Page 10 CONFIGURATIONS (cont´d) 4 x Artec 510 2 x Artec S15 Standard Configuration LINK LINK From mixer DSP-2040 Manual del Usuario / artec 500 passive / User’s Manual...
- Page 11 CONFIGURATIONS (cont´d) 4 x Artec 526 2 x Artec S15 Standard Configuration LINK LINK From mixer DSP-2040 Manual del Usuario / artec 500 passive / User’s Manual...
-
Page 12: Line Drawings
LINE DRAWINGS ALL DIMENSIONS IN MILIMETERS Right View Rear View Top View Front View Bottom View Front View Right View Rear View Right View Rear View Front View Bottom View Top View Right View Rear View Front View Bottom View Front View Right View Rear View... -
Page 13: Specifications
SPECIFICATIONS artec 506 artec 508 artec 510 artec 526 artec S15 Model Peak Power Handling (-10 dB) 800 W 1200 W 1600 W 1600 W 3200 W Program Power Handling 400 W 600 W 800 W 800 W 1600 W RMS Power Handling 200 W 300 W... - Page 14 Mounting AXU Introduction AXU series are designed for enclosures artec 506, artec 508, artec 510, artec 526 and different versions. Mounting instructions You can consult the AXU mounting instructions for artec500 series on the web: www.dasaudio.com Mounting AXF (only for Artec 508 & Artec 510 enclosures) Introduction The AXF series are designed for enclosures artec508, artec510 and different versions.
- Page 15 www.dasaudio.com D.A.S. AUDIO, S.A. D.A.S. AUDIO OF AMERICA, INC. D.A.S. AUDIO ASIA PTE. LTD. C/. Islas Baleares, 24 Sunset Palmetto Park 25 Kaki Bukit Crescent #01-00/02-00 46988 Fuente del Jarro 6816 NW 77th Court. Kaki Bukit Techpark 1 Valencia, SPAIN Miami, FL.
