User Manual
SN-901 AU
Digital Long Range Cordless System
Table of Contents
Safety Instructions .................................................................................... 4
General Safety Instructions ................................................................... 4
Product Safety Instructions ................................................................... 4
Battery Safety Instructions .................................................................... 6
Regulatory Information ............................................................................. 7
Equipment Checklist ............................................................................... 10
Handset Illustration ................................................................................. 11
Handset Features .................................................................................... 11
Basic Handset Features ....................................................................... 12
Additional Handset Features ............................................................... 14
Administrator Features ....................................................................... 16
Base Illustration ...................................................................................... 18
Base Features.......................................................................................... 19
Basic Base Station Features ................................................................. 19
Charger Illustration ................................................................................. 20
Charger Features ..................................................................................... 20
Getting Started ....................................................................................... 22
Base Station Installation ...................................................................... 22
Handset and Charger Installation ........................................................ 23
Basic Operations ..................................................................................... 24
Operation Modes ................................................................................ 24
A. Base Operation Modes ................................................................ 24
B. Handset Operation Modes .......................................................... 24
Menu Tree .......................................................................................... 25
Making a Telephone Call ..................................................................... 25
Making an 2-Way/ Intercom Call ......................................................... 26
Making a Broadcast ............................................................................ 27
A. Handset to Handset Calls ............................................................ 27
Redial ................................................................................................. 28
Receiving a Telephone Call .................................................................. 28
Receiving an Intercom Call .................................................................. 28
Ending a Call ....................................................................................... 29
Adjusting Receiver (Earpiece) Voice Volume ....................................... 29
Placing a Call On Hold ......................................................................... 29
Mute ................................................................................................... 30
~2~
Advertisement
Table of Contents
Related Manuals for Aristel SN-901 AU
Summary of Contents for Aristel SN-901 AU
-
Page 1: Table Of Contents
User Manual Safety Instructions ..................4 General Safety Instructions ..............4 Product Safety Instructions ..............4 Battery Safety Instructions ..............6 SN-901 AU Regulatory Information ................7 Digital Long Range Cordless System Equipment Checklist ................10 Handset Illustration ................. 11 Handset Features .................. -
Page 2: Safety Instructions
Do Not Disturb (Silent Ring) ..............30 Safety Instructions Key Guard ................... 30 To View Missed Call(s) ................ 31 Caution: Your wireless telephone gives you freedom and flexibility to Battery Recharge and Replacement ............ 31 stay in touch while you move around. However, when using your phone equipment, safety instructions should be followed to avoid the risks of Advanced Operations ................ -
Page 3: Battery Safety Instructions
Changes or modifications to this product not expressively approved by the 16. Do not use the product to report a gas leak while in the vicinity of the leak. manufacturer will void the warranty and the FCC authorization to operate the 17. - Page 4 Regulatory Information FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an SN-901 AU uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device complies with Part 15 of the FCC Rules. Operation is subject to...
-
Page 5: Equipment Checklist
- Connect the equipment into an outlet on a circuit different from that to Equipment Checklist which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. In a Base + Handset package, please find the following components: FCC Caution: Any changes or modifications not expressly approved by the party Base Station x 1 responsible for compliance could void the user's authority to operate this... -
Page 6: Handset Illustration
Handset Illustration Handset Features Basic Handset Features Antenna 4-line LCD (Liquid Crystal Display) Belt Clip (1) (2) (3) (4) (5) (6,7) (8) (9) Holder Receiver Left/Right soft keys 4-line LCD Up/Down scrolling keys The LCD display has LED (Light Emitting Diode) for backlighting. b. -
Page 7: Additional Handset Features
Indicates charging when in charger cradle. ) /Down( ) Scrolling Keys d. The 2 and 3 lines of the LCD, maximum 14 characters each, display Scroll through records and menu selections. status, message, menu selections, or user-editable alphanumerical b. Adjust receiver voice volume when in Talk mode. characters. -
Page 8: Administrator Features
Allow user to pre-program the most frequently used PBX feature [Note] you need to key in the accurate user ID and password to perform this along with its feature code into SN-901 AU which is adjunct to the PBX feature. The default password is “0000”. -
Page 9: Base Illustration
Page (handset locator only) Call transfer to PBX extension / Registration When install the SN-901 AU behind the PBX system, you can pre-program the feature code of call transfer function b. Need to adjust the Flash time to match your PBX setting... -
Page 10: Base Features
Base Features Charger Illustration Basic Base Station Features DC In Antenna The antenna port has a reversed thread connector; to install antenna or cable, turn counterclockwise; to remove, turn clockwise. Improper installation may damage the connector. When using an outdoor antenna, locate the antenna (not the base station Spare Battery Charging itself) as high as possible for a clear transmission path. -
Page 11: Charger Features
Charger Features Getting Started Base Station Installation DC In Connects to Charger AC Adaptor. There are three possible base station setups: Base station alone Handset Charging Slot Base station plus telephone answering device Charge handset battery when handset is placed in cradle. Base station plus standard telephone b. -
Page 12: Handset And Charger Installation
Basic Operations Operation Modes Handset and Charger Installation Both the base station and handset have levels of operation at which time only Plug the transformer end of the Charger AC/DC adaptor into a standard AC certain procedures of functions can be performed. electric power outlet, plug the other end into the “DC In”... -
Page 13: Menu Tree
Menu Tree Press to dial out the number Main menu Sub-menu To abort dialing, press key. 1.KeyGuard 1.Dialed During the call, press and hold the key to activate 2.PhoneBook 2.Received the speakerphone. 3.Missed 3.Call Logs 1.Ring Volume 2.Ring Tone 4.Sound 3.Key Volume Notes: 4.Key Tone... -
Page 14: Making A Broadcast
2. If a Group ID is entered, the first handset (belonging to that group) that answers will establish a link with the Redial caller. See Handset Group Subscription. 3. If a link cannot be established, the LCD shows “No Connection” after a 30-second time out. Press REDIAL (Left) soft key. -
Page 15: Ending A Call
When an intercom call arrives, the ringer will ring or vibrate unless the ringer pressing the HOLD (Right) soft key. has been turned off. Press to answer the intercom call. To return to the conversation, press UNHOLD If the handset is on the charger cradle (ringer will be temporarily switched to Notes: “Ring”... -
Page 16: To View Missed Call(S)
To prevent accidental dialing, you can press MENU (Right) Advanced Operations Welcome! soft key, then press “1” to select KeyGuard option. The handset keypad is locked. No key entry is accepted except Handset Registration UNLOCK the power on/off key. If your handset(s) is purchased as part of a system, it has been pre-registered To unlock the keypad, press UNLOCK (Left) soft key, then,... -
Page 17: Handset Group Subscription
1. The base has a 30 second registration timeout starting from pressing the PAGE button. The handset has a 12 second registration SN-901 AU can be installed as the multiple base configurations: up to 4 timeout starting from the registration or deregistration option has base units can be registered. -
Page 18: Call Manager
Notes: If the base station is adjunct to a PBX system, it is Call Manager: Scrolling keys to select a base recommended to adjust the flash time of SN-901 AU to 1. Incoming from base 1 to base 4. match the PBX spec. -
Page 19: Phonebook Operations
For example, press “2” once for the Notes: Since the base station is adjunct to a PBX system, you need character “A”, twice for “B”, etc. to adjust the flash time of SN-901 AU to match the PBX spec and (3) Use DELETE (Right) soft key to delete the last then program the “call transfer”... -
Page 20: Call Barring
for. 5. Character Table: To erase phonebook: Characters and Orders EnGenius ‘ + , . * ( ) & 1 scrolling key or the alphabetical 7144328668 search method to locate the record to be erased or A B C 2 OPTION edited. -
Page 21: Text Messaging
retrieve the PSTN tone. Press MENU-7-2 to enter outbox text message. b. Press OPTION to erase or edit the call barring codes. b. Press OPTION (Right) soft key to erase or edit the b. Up to 5 set of call barring codes can be programmed. current message: Sending…... -
Page 22: Programmable Pbx Options
Programmable PBX Options Notes: When SN-901 AU base unit installed behind the PBX 1. This feature would be useful if the SN-901 AU base unit is system, it is feasible to pre-program some PBX features adjunct to a PBX system. -
Page 23: Menu Operations
Menu Operations (3) View Number: press “3” to view the complete number if the phone number is longer than 14 digits. b. Press “2” to view the last 10 phone numbers received, starting from the Main menu Sub-menu most recent one. Use to scroll through the list. - Page 24 options: 0, 1, 2, and 3. Press SAVE to save selection. Default = 0. (1) Use to scroll through values 1 to 16. Pick one that is Press “3” to select key volume when a key is pressed: use most suitable to you. Default = 10. to scroll through 3 options: High, Low, and Off.
-
Page 25: Technical Specifications
Press “9” following by entering a base ID to enter System setting. See the The manufacturer reserves the right to change designs and specifications without notice. detail instructions on page 36. Technical Specifications Electrical Specifications Base Station Portable Handset Frequency 902-928 MHz 902-928 MHz RF Power... -
Page 26: Index
Index Electric Shock, 4, 5 Emergency, 4 Equipment Checklist, 10 2-Way/Intercom, 13, 25, 35 FCC, 5, 6, 7, 8, 9, 49 FDA, 4 Adjusting Receiver (Earpiece) Voice Volume, 29 Flash Time, 17, 36, 37, 49 Administrator Features, 16 Group ID, 13, 14, 26, 27, 41 Base Station Features, 19 Base Station Installation, 22 Battery,5, 6, 10, 12,13, 15, 21, 22, 23, 24, 30, 31, 48... - Page 27 Safety Instructions, 4, 6 Spare Battery Charging Slot, 20, 21 Speed Dial, 25 Talk Mode, 14, 24, 43 Talk/, 11,13 Technical Specifications, 49 Text Messaging, 16, 41, Transformer, 22, 23 Three Call Logs, 15, 46, 47 To View Missed Call(s), 31 Two-Digit Address Index, 12 Vibrator, 14 Warning Message, 21...
