SJM430-C PRO/E² Reference Manual
SJM430-C PRO/E² Specifications:
Airframe Weight (including FG canopy and main blades): 935g
RTF Weight: 1650-1750g
Airframe Length (With Canopy): 940mm
Airframe Width: 160mm
Airframe Height: 280mm
Main Blade Disk Diameter: 990mm (430mm Main Blades)
Flybar Paddle Disk Diameter (RC-TEK Default): 510mm
Flybar Rod Size (RC-TEK Default): 390mm x Ø3mm
Tail Rotor Disk Diameter: 202mm (73mm Tail Blades)
Main Shaft Size: Ø6mm x 157mm
Tail Rotor Shaft Size: Ø4mm x 54mm
Tail Boom Diameter (External): Ø18mm
Main Drive Gear: M0.6 125T
Main/Tail Gear Ratio: 1 : 4.82
Optional PRO Motor: 1100KV (1000w)
Optional E² Motor: Scorpion 1210KV (1365w)
Optional PRO ESC: SJM60A 2~6S (80A Burst) w/ 3A (5A Burst) BEC
Specifications subject to change without notice or obligation
CONTENTS
1. Important Notes
2. Assembly Drawings
RC-TEK
Copyright © 2008 RC-TEK/SGB Enterprises LLC. All Rights Reserved.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SJM430-C PRO/E2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RC-Tek SJM430-C PRO/E2

  • Page 1 Optional E² Motor: Scorpion 1210KV (1365w) • Optional PRO ESC: SJM60A 2~6S (80A Burst) w/ 3A (5A Burst) BEC Specifications subject to change without notice or obligation CONTENTS 1. Important Notes 2. Assembly Drawings Copyright © 2008 RC-TEK/SGB Enterprises LLC. All Rights Reserved.
  • Page 2 Gyro – RC-TEK 700/800 series, Futaba GY401, Logictech2100T • Servos – (4) Servos – Hitec HS-81/85, Futaba S9650/S9257 or equivalent • Battery – (1) 6S 2200mA+ Li-Po Battery (or dual 3S Li-Po’s stacked = 6S) Copyright © 2008 RC-TEK/SGB Enterprises LLC. All Rights Reserved.
  • Page 3 6. Make sure never to exceed a flying height of over 3 feet! Anything over the recommended height can and may cause major damage to the helicopter if crashed. Copyright © 2008 RC-TEK/SGB Enterprises LLC. All Rights Reserved.
  • Page 4 4. Check for excess play or gaps between the surfaces, missing or broken parts, or binding restricting free movement. It is very important to check for main rotor balance before each flight. Operating the helicopter “out of balance” will cause excessive wear and premature failure of parts, possibly resulting in a dangerous situation. Copyright © 2008 RC-TEK/SGB Enterprises LLC. All Rights Reserved.
  • Page 5 50 flights. If the main drive gear is loose, you should replace the one-way bearing. 3. Drive belt: SJMRC/RC-TEK uses only top quality, stretch-resistant belts. It is however, impossible to prevent the belt from stretching or wearing out.
  • Page 6 World Wide Sales and Support: sales@rc-tek.com sales@sjmrc.us Worldwide Headquarters: 848 N. Rainbow Blvd., Suite 1089 Las Vegas, NV 89107 USA Tel: +1-760-842-6565 Fax: +1-760-400-4242 ENJOY YOUR NEW SJM430! RM-REVA070208 SGBE Copyright © 2008 RC-TEK/SGB Enterprises LLC. All Rights Reserved.
  • Page 7: Safety Warning

    8. The operator of this helicopter is ultimately responsible for his/her own actions and any/all potential damaged caused either directly or indirectly as a result of such operation. RC-TEK Ltd., its agents and/or subsidiaries shall be held harmless for any financial, physical, or emotional loss caused by the operation of this helicopter.
  • Page 8 Specification NO. Part NO. Discription Q'TY Specification NO. Part NO. Discription Q'TY AL6056 Sliding shaft set SJ80001 Sliding shaft set screw M1.6×10mm SJ50007 Tail angel adjusting ball link...
  • Page 9 NO. Part NO. Discription Q'TY Specification NO. Part NO. Discription Q'TY Specification SJ20004 Cap screw M2×8mm AL5048 Linkage ball SJ10020 Trust bearing SJ30013 Ball link screw M2*8 AL6058 Tail blade clincher CF6037 Tail blade SJ10021 Bearing 4*9*3 SJ20017 Cap screw M3×16mm AL6059 Tail blade center...
  • Page 11 NO. Part NO. Discription Q'TY Specification Part NO. Discription Q'TY Specification AL6057 Tail unit housing CF6075 Tail unit housing side board SJ20004 Cap screw M2×8mm SJ20003 Cap screw M2×5mm CF6075 Tail unit housing side board SJ20004 Cap screw M2×8mm CF6075 Tail unit housing side board SJ20003 Cap screw...
  • Page 12 NO. Part NO. Discription Q'TY Specification NO. Part NO. Discription Q'TY Specification SJ20009 Set screw M3×3mm SJ40001 Round head screw M1.6×6mm SJ20009 Set screw M3×3mm SJ20005 Cap screw M2×10mm AL6055 Tail angel adjusting set AL5048 Ball link 39—1 SJ70001 SJ20005 Cap screw M2×10mm 39—2...
  • Page 13 Part NO. Discription Q'TY Specification Part NO. Discription Q'TY Specification SJ20003 Cap screw M2×5mm SJ20003 Cap screw M2×5mm SJ10010 Bearing Ø2ר6×2.5mm SJ50004 Ball link 42—1 AL6074 Underlay Ø2 SJ40001 Round head screw M1.6×6mm...
  • Page 14 NO. Part NO. Discription Q'TY Specification NO. Part NO. Discription Q'TY Specification AL6061 Tail servo connecting rod SJ30013 Ball link screw M2×8mm AL6083 Tail boom support set AL5048 Linkage ball AL6061 Tail servo connecting rod SJ70001 AL6069 Extend board AL6060 Tail servo support AL6060 Tail servo support...
  • Page 16 NO. part No Discription Q'TY Specification NO. part No Discription Q'TY Specification 64 AL6051 Flybar stand 69 AL5048 Linkage ball 65 AL6052 Flybar copper ball 70 AL6052 Flybar copper ball underlay sticker 66 HS6011 Flybar rod Ø3×390mm 71 SJ50004 Ball link 67 SJ20009 Set screw M3×3mm...
  • Page 17 part No Discription Q'TY Specification part No Discription Q'TY Specification AL6073 Flybar rod fixing ring AL6066 Flybar linkage ball SJ20009 Set screw M3×3mm SJ20009 Set screw M3×3mm AL5004 Fybar mixing arm set subassembly CF6032 Flybar paddle AL6063 Flybar control rod SJ20009 Set screw M3×3mm...
  • Page 18 part No Discription Q'TY Specification part No Discription Q'TY Specification SJ20005 cap screw M2×10mm SJ40001 Round head screw M1.6×6mm AL5004 Fybar mixing arm set subassembly 97 AL5007P Main blade clincher SJ10010 Bearing Ø2ר6×2.5mm SJ10012 Bearing Ø6ר10×3mm AL6074 Underlay Ø2 99 AL5007P Main blade clincher AL6053 Mixing arm...
  • Page 19 NO. Part No Discription Q'TY Specification Part No Discription Q'TY Specification SJ20009 Set screw M3×3mm AL6074 Underlay Ø2 SJ20005 Cap screw M2×10mm 113-1 SJ40001 Roundhead screw M1.6×6 SJ10010 Bearing Ø2ר6×2.5mm...
  • Page 20 NO. Part No Discription Q'TY Specification SJ50004 Ball link 115 HS6005P Linkage rod Ø2×20mm SJ50004 Ball link 117 AL6014X Swash plate SJ30005 Countersunk screw M2×8mm AL5048 Linkage ball 120 SJ70001...
  • Page 22 part No Discription Q'TY Specification part No Discription Q'TY Specification CF6019 CF board over main frame(A) AL6084 Maish shaft stand FG6020 FGboard over main frame(B) SJ20011 cap screw M2×12mm CF6021 CF board over main frame(C) AL6076 Down servo mount underlay sticker SJ20004 Cap screw M2×8mm...
  • Page 23 part No Discription Q'TY Specification SJ10014 Bearing Ø6ר12×4mm AL6075 Up servo mount AL5034 Main shaft confining ring SJ20009 Set screw M3×3mm SJ20004 Cap scew M2×5mm AL6074 Underlay Ø2 CF6018 Swash plate fixing device SJ10022 One-way bearing Ø6ר10×15mm AL6062 One-way bearing stand CL5003 Main drive gear SJ20003...
  • Page 24 NO. part No Discription Q'TY Specification SJ20005 Cap screw M2×10mm SJ20011 Cap screw M2×12mm SJ70001 SJ30013 Ball link screw M2×8mm AL5048 Linkage ball SJ70001 SJ50004 Ball link HS6005P Linkage rod Ø2×20mm SJ20011 Cap screw M2×12mm SJ50004 Ball link 169 AL6014X Swash plate fixing copper stick Ø2ר4.3×3mm...
  • Page 26 NO. part No Discription Q'TY Specification SJ20004 Cap screw M2×8mm SJ20005 Cap screw M2×10mm...
  • Page 27 part No Discription Q'TY Specification part No Discription Q'TY Specification SJ20004 Cap screw M2×8mm SJ20005 Cap screw M2×10mm CF6030 Beam(Front) AL3032P Foot linkage set CF6031 Beam(Back) SJ20003 Cap screw M2×5mm AL6040 Beam linkage set SJ70001 SJ20005 Cap screw M2×10mm SJ20004 Cap screw M2×8mm CF6025...
  • Page 28 part No Discription Q'TY Specification SJ20005 Cap screw M2×10mm SJ30005 Countersunk screw M2×8mm AL5048 Linkage ball CF6029 Receiver board SJ70001...
  • Page 29 part No Discription Q'TY Specification SJ20004 Cap screw M2×8mm CF6024 CF battery board SJ20004 Cap screw M2×8mm SJ50001 Landing skid Ø5×190mm SJ50002 Landing skid rudder AL6082 Sledge connecting set AL5037P Landing skid link AL5037P Landing skid link SJ50002 Landing skid rudder AL5028 Skid pipe lever SJ20015...
  • Page 30 part No Discription Q'TY Specification SJ20004 Cap screw M2×8mm...
  • Page 32 part No Discription Q'TY Specification part No Discription Q'TY Specification FG6003 FG main blade SJ70003 Anti-loose Nut SJ20021 Cap screw M3×20mm...
  • Page 33 Head Setup Note: When setting up or adjusting the main blade pitch, the SJM helicopter airframe and main blades should be facing TOWARDS/AWAY from you. Due to the 3 degrees of forward tilt on the SJM helicopter, do not attempt to setup or adjust the pitch of the main blades from the side of the unit.
