Ref. No. Part No.
DUNTKB157DE01
DISPLAY MAIN UNIT(Continued)
R2226 VRS-CY1JF000J J 0
R2227 VRS-CY1JF000J J 0
R2228 VRS-CY1JF101J J 100
R2229 VRS-CY1JF101J J 100
R2230 VRS-CY1JF822F J 8.2k 1/16W Metal Oxide
R2231 VRS-CY1JF101J J 100
R2233 VRS-CY1JF101J J 100
R2235 VRS-CY1JF101J J 100
R2236 VRS-CY1JF101J J 100
R2237 VRS-CY1JF101J J 100
R2238 VRS-CY1JF101J J 100
R2239 VRS-CY1JF101J J 100
R2240 VRS-CY1JF222F J 2.2k 1/16W Metal Oxide
R2241 VRS-CY1JF473J J 47k
R2244 VRS-CY1JF223J J 22k
R2245 VRS-CY1JF223J J 22k
R2246 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide
R2247 VRS-CY1JF101J J 100
R2248 VRS-CY1JF223J J 22k
R2249 VRS-CY1JF223J J 22k
R2250 VRS-CY1JF101J J 100
R2251 VRS-CY1JF472J J 4.7k 1/16W Metal Oxide
R2252 VRS-CY1JF000J J 0
R2255 VRS-CY1JF101J J 100
R2256 VRS-CY1JF000J J 0
R2257 VRS-CY1JF102J J 1.0k 1/16W Metal Oxide
R2258 VRS-CA1JF680J J 68
R2259 VRS-CB1JF680J J 68
R2260 VRS-CF1JP680J J 68
R2261 VRS-CY1JF511J J 510
R2262 VRS-CY1JF221J J 220
R2263 VRS-CY1JF221J J 220
R2264 VRS-CY1JF220J J 22
R2265 VRS-CY1JF000J J 0
R2266 VRS-CY1JF221J J 220
R2267 VRS-CY1JF221J J 220
R2268 VRS-CY1JF221J J 220
R2269 VRS-CY1JF221J J 220
R2270 VRS-CF1JP680J J 68
R2271 VRS-CF1JP680J J 68
R2272 VRS-CB1JF680J J 68
R2273 VRS-CA1JF680J J 68
R2274 VRS-CY1JF102J J 1.0k 1/16W Metal Oxide
R2276 VRS-CY1JF220J J 22
R2277 VRS-CA1JF680J J 68
R2282 VRS-CB1JF680J J 68
R2284 VRS-CF1JP680J J 68
R2285 VRS-CA1JF680J J 68
R2287 VRS-CY1JF152J J 1.5k 1/16W Metal Oxide
R2288 VRS-CY1JF332J J 3.3k 1/16W Metal Oxide
R2290 VRS-CY1JF101J J 100
R2291 VRS-CY1JF473J J 47k
R2293 VRS-CY1JF101J J 100
R2294 VRS-CY1JF000J J 0
MISCELLANEOUS PARTS
FB2001 RBLN-0006TAZZ J Ferrite Bead
FB2201 RBLN-0006TAZZ J Ferrite Bead
FB2202 RBLN-0006TAZZ J Ferrite Bead
FB2203 RBLN-0006TAZZ J Ferrite Bead
FB2204 RBLN-0210TAZZ J Ferrite Bead
FB2206 RBLN-0210TAZZ J Ferrite Bead
FB2207 RBLN-0210TAZZ J Ferrite Bead
FB2208 RBLN-0210TAZZ J Ferrite Bead
FB2209 RBLN-0061TAZZ J Ferrite Bead
FB2210 RBLN-0061TAZZ J Ferrite Bead
FB2211 RBLN-0061TAZZ J Ferrite Bead
FB2212 RBLN-0061TAZZ J Ferrite Bead
FB2213 RBLN-0006TAZZ J Ferrite Bead
P2002 QPLGN1074TAZZ J Plug 10-Pin(SB)
P2003 QPLGN0874TAZZ J Plug 8-Pin(RM)
Description Code
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide
1/16W Metal Oxide
1/16W Metal Oxide
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide
1/16W Metal Oxide
1/16W Metal Oxide
1/16W Metal Oxide
AA
1/16W Metal Oxide AA
1/16W Metal Oxide
1/16W Metal Oxide
1/16W Metal Oxide
1/16W Metal Oxide
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AB
AB
AB
AB
AB
AB
AB
AB
AD
AD
AD
AD
AB
197
Ref. No. Part No.
P2004 QPLGN0364TAZZ J Plug 3-Pin(KK)
P2005 QPLGN0059CEZZ J Plug 9-Pin(MA)
P2006 QLUGHA001WJZZ J Lug
P2101 QPLGN0774TAZZ J Plug 7-Pin(PA)
P2102 QPLGN0178FJZZ J Plug 6-Pin(PB)
P2103 QPLGN0175FJZZ J Plug 3-Pin(MB)
P2104 QPLGN0182FJZZ J Plug 10-Pin(SA)
P2106 QPLGN0364TAZZ J Plug 3-Pin(MD)
P2107 QLUGHA001WJZZ J Lug
P2201 QLUGHA001WJZZ J Lug
SC2001 QSOCN2298TAZZ J Socket 22-Pin(MC)
SC2201 QSOCZA017WJZZ J Socket 24-Pin(DVI)
SC2202 QSOCZ2015CEZZ J Socket 20-Pin(MDR)
SC2203 QCNCWA015WJZZ J Connector 80-Pin(MSC)
PSLDMA020WJZZ J Shield
PSLDM4716CEFW J Shield
QCNW-A346WJZZ J Connecting Cord(KK)
QCNW-A347WJZZ J Connecting Cord(MD)
QCNW-A348WJZZ J Connecting Cord(PA)
QCNW-A349WJZZ J Connecting Cord(PB)
QCNW-A350WJZZ J Connecting Cord(RM)
QCNW-A351WJZZ J Connecting Cord(SA)
QCNW-A352WJZZ J Connecting Cord(SB)
NSFTZ0135CEFW J Shaft
LC-30HV2E
Description Code
AC
AD
AD
AD
AC
AE
AM
AG
AU
AD
AD
AG
AE
AH
AF
AH
AD
