Ford 2012 Mustang Quick Referenc Manual

mULtI-FUnCtIon LeVer
Rotate the end of the control to
increase/decrease the speed of the wipers.
Push the end of the stalk:
• quickly for a single swipe without fluid
• and hold briefly for three swipes with
washer fluid
• and hold for a longer wash cycle
Note: A courtesy wipe will automatically occur
after the washing cycle to ensure that any drips
LoW tIre preSSUre
have been cleared from your windshield. For
WarnIng LIght
optimal wiper performance, clean blades and
Refer to the Tire Pressure section on
glass regularly. Refer to your Owner's Guide for
the Essential Information panel of this
more information.
guide for more information.
headLamp ControL
Turns the headlamps off.
Turns on parking, instrument panel,
license plate and tail lamps.
Turns on headlamps.
Autolamps (if equipped): Automatically
turns the exterior lamps on/off based on
available daylight.
SteerIng WheeL ControLS
Pull toward you to turn on the
(IF eqUIpped)
fog lamps (if equipped).
To set the speed:
Note: Your vehicle is equipped with automatic
1 Press ON.
instrumentation illumination. When the
2 Accelerate to the desired speed.
headlamps or park lamps are turned on, a
3 Press SET + and take your foot off the accelerator.
light sensor in your vehicle monitors the
outside lighting conditions and automatically
• To set a higher speed, press and hold SET + or press
sets the instrumentation illumination to the
SET + repeatedly until the desired speed is reached.
appropriate mode. Refer to your Owner's
• To set a lower speed, press and hold SET – or press
Guide for further information.
SET – repeatedly until the desired speed is reached.
• To return to a previously set speed, press RESUME.
• To turn off, press OFF or turn off the ignition.
naVIgatIon SyStem (IF eqUIpped)
meSSage Center
VOL +/-: Press to increase/decrease volume levels.
The Mobile Media Navigation System allows
Displays important vehicle information through
: Press to access the previous/next radio station,
you to record CDs, listen to your saved music,
a constant monitoring of vehicle systems.
CD track or preset satellite radio channel.
play DVDs and access climate control
The system will notify you of potential problems
: Press repeatedly to access all possible media sources.
options in addition to navigating the vehicle.
with a display of warnings followed by a long
: Press to access SYNC ® voice recognition, if equipped.
Refer to your Navigation supplement for
indicator chime. Use the INFO, SETUP and RESET
: Press to access SYNC ® phone features, if equipped.
more information.
buttons to access various menus and settings
within the message center such as MyColor
ambient lighting and halo lighting. Refer to your
Use extreme caution when using any device or feature that may take your attention off the road.
Owner's Guide for more information.
Ford recommends against the use of any hand-held device while driving and that you comply with all
applicable laws. Your primary responsibility is the safe operation of the vehicle.
Sport Mode (if equipped):
adVanCetraC ® StabILIty
InterIor trUnk
Allows for more spirited driving (closer to the
enhanCement SyStem
reLeaSe
vehicle's handling limits) before the AdvanceTrac
Helps you maintain stability and steerability of your
system intervenes. To activate, press the brake
vehicle during a variety of road conditions. If your
pedal and then press the control twice rapidly.
vehicle becomes stuck, try turning off the Traction
Sport mode is intended for use in controlled racing
Control portion of the AdvanceTrac ® system (by
environments as it provides less AdvanceTrac
pressing the control once) to allow wheel spin and
hazard
intervention and should only be used by experienced
help increase momentum to help dig the vehicle
® FLaSher
drivers in a controlled and safe manner. Always be
out. This control also enables other AdvanceTrac ®
familiar with the vehicle and the conditions before
modes, please refer to your Owner's Guide for
selecting this mode. Refer to your Owner's Guide
more information.
for more information.
abS WarnIng LIght
Illuminates briefly when the ignition is turned
on. If the light remains on or continues to flash,
a malfunction has been detected. Contact your
authorized dealer as soon as possible and have the
system serviced. Normal braking (less ABS) is still
functional unless the brake warning light is
also illuminated.
SerVICe engIne Soon LIght
Illuminates briefly when the ignition is turned on.
If it remains on or is blinking after the engine is
started, the on-board diagnostics system
(OBD-II) has detected a malfunction. Drive in a
moderate fashion and contact your authorized
dealer as soon as possible.
aIrbag readIneSS LIght
Illuminates briefly when the ignition is turned
on. If this light fails to illuminate, remains on or
continues to flash after the engine is started,
contact your authorized dealer for service as
soon as possible. A chime will also sound if there
is a malfunction in the indicator light.
throttLe ControL/
tranSmISSIon LIght
Illuminates when a powertrain fault is detected.
If the light remains on or continues to come on,
contact your authorized dealer for service as
soon as possible.
manUaL heatIng and
aIr CondItIonIng SyStem
®
Refer to the Climate Control chapter in your
Owner's Guide for more information.
®
manUaL tranSmISSIon
The gearshift lever can only be moved to R (Reverse) by pushing
the knob down before shifting to reverse. This is a lockout
feature which protects the transmission from accidentally
engaging R (Reverse) when intending to select 1 (First).
c
l i m A t e c o n t r o l s
1 2 3 4 5 6 7 8 9 10 11 1 7
naVIgatIon baSed dUaL zone aUtomatIC temperatUre ControL (IF eqUIpped) In-daSh Cd/mp3 SateLLIte CompatIbLe SoUnd SyStem (IF eqUIpped)
heated drIVer/paSSenger rear deFroSt • 7 VoL • 1
SeatS • 1 Press to activate and clear the rear window and side
Push to turn the system on/off. Turn
Press to activate heated seats, press again heated mirrors of thin ice and fog. Press again to
to increase/decrease the volume.
to deactivate. deactivate. The defroster will turn off automatically
after 15 minutes. Cd • 2
drIVer SIde temperatUre • 2
Press to increase/decrease the air temperature for a/C • 8 Press to enter CD/MP3 mode.
the driver side of the vehicle. If the passenger side Press to activate/deactivate. Use with recirculated If a disc is already present in the
controls (dual zone) are not active, this control air to improve cooling performance efficiency. system, CD play will begin where
adjusts the temperature for the entire vehicle
reCIrCULated aIr • 9 it last ended.
cabin (single zone).
Recirculated air may reduce the amount of time
am/Fm • 3
• 3 Press to turn on/off. needed to cool down the interior of the vehicle
and may also help reduce undesirable odors from Press repeatedly to cycle through
aUto • 4
reaching the interior of the vehicle. AM, FM1 or FM2 frequency bands.
Press to engage full automatic operation. Select
paSSenger SIde
the desired temperature using the temperature
SIrIUS • 4
temperatUre • 10
control. The system will automatically determine
Press repeatedly to cycle through
fan speed, airflow location, A/C on or off, and Press to activate passenger side climate control
SAT1, SAT2 and SAT3 (satellite
outside or recirculated air, to heat or cool the (dual zone) and to increase/decrease temperature
radio modes, if equipped). Press
vehicle to reach the desired temperature. on the passenger side.
MENU when active and then OK to
deFroSt • 5 CLImate • 11
enter the satellite radio menu and
Distributes outside air through the windshield Press to access climate control features on the
defroster and demister vents. Can be used to clear navigation touchscreen. Refer to your Owner's
Note: Your vehicle is equipped with an auxiliary input jack and possibly a USB port inside your center console. The
thin ice or fog from the windshield. Guide and/or Navigation supplement for
auxiliary input jack allows you to plug in your portable MP3 player and play music through the vehicle speakers. The USB
more information.
Fan Speed • 6
port (if equipped) allows you to plug in and access media devices. For more information, refer to your Owner's Guide.
Press + to increase or - to decrease the fan speed.
®
Note: Fuel economy can be affected by climate control usage. Using MAX A/C helps improve fuel economy as it SIRIUS satellite radio broadcasts music, sports, news and entertainment programming. For more information and a
"re-cools" recirculated air and is more economical and efficient. Press the CLIMATE hard button and then press complete list of SIRIUS
Canada, or call SIRIUS
MAX A/C on the touchscreen.
A
u d i o c o n t r o l s
to Set
the tIme:
Press CLOCK. Use
the memory preset
#s to enter the
desired time and
press OK.
6 3 1 4 2 5 8
access more options. Refer to your desired radio station, track number,
Owner's Guide for more information. MP3 folder number (if in MP3
mode), or satellite radio channel.
SoUnd • 5
Press repeatedly to access: tUne • 8
Bass, Treble, Balance, Fade, Turn to go to the next/previous
Speed compensated volume and satellite radio channel, or to go
All seats (Occupancy mode, if up/down the radio band frequency
equipped). Press SEEK to in individual increments.
make adjustments.
SynC ® (IF eqUIpped)
SCan • 6 SYNC ® is a hands-free
Press for a brief sampling of all radio
communications and entertainment
stations, CD tracks or satellite radio system with special phone
channels (if equipped). Press and media features. For more
again to stop. information, please refer to
the SYNC ® Supplement, the
dIreCt • 7
SYNC ® section in the Navigation
Press DIRECT and then, using the
Supplement (if equipped) or visit
memory presets (0-9), enter in the www.SyncMyRide.com.
® satellite radio channels, visit www.sirius.com in the United States, www.sirius-canada.ca in
® at 1–888–539–7474. Satellite radio is only available with a valid SIRIUS ® radio subscription.
