Ford 2012 Mustang Owner's Manual

Hide thumbs Also See for 2012 Mustang:
Table of Contents

Advertisement

Quick Links

See also: User Manual , Quick Reference Manual
Manual heating and air conditioning
Headlamps
Windshield Wiper/washer control
Mirrors
Locks
2012 05+ Mustang (197)
Owners Guide, 1st Printing
USA (fus)

Table of Contents

12
12
17
19
28
37
39
42
45
45
46
46
49
53
54
54
59
60
68
68
69
73
76
77
93
93
99
109
4
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2012 Mustang and is the answer not in the manual?

Questions and answers

Related Manuals for Ford 2012 Mustang

Summary of Contents for Ford 2012 Mustang

  • Page 1 Table of Contents Introduction Instrument Cluster Warning lights and chimes Gauges Message center Entertainment Systems Auxiliary input jack (Line in) USB port Satellite radio information Navigation system SYNC Climate Controls Manual heating and air conditioning Navigation system based climate control Rear window defroster Lights Headlamps...
  • Page 2 Table of Contents Seating and Safety Restraints Seating Personal Safety System™ Safety belt system Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes AdvanceTrac Transmission operation Reverse sensing system Rear-view camera system...
  • Page 3 Ford Motor Company. Ford may change the contents without notice and without incurring obligation. Copyright © 2010 Ford Motor Company...

  • Page 4: Introduction

    Introduction CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
  • Page 5 Introduction Warning symbols on your vehicle When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind. Protecting the environment We must all play our part in protecting the environment.
  • Page 6 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may...
  • Page 7 EDR. Ford Motor Company and Ford of Canada do not access event data recorder...
  • Page 8 If you do not want Ford or its vendors to receive this information, do not activate the service. Ford Motor Company and the vendors it uses to provide you with this information do not store your vehicle travel information.
  • Page 9 Introduction WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that you use extreme caution when using any device or feature that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle.
  • Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Child Seat Lower Airbag - Side Anchor Child Seat Tether Brake System Anchor Anti-Lock Brake System Parking Brake System Brake Fluid -...
  • Page 11 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Child Safety Door Interior Luggage Lock/Unlock Compartment Release Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...

  • Page 12: Instrument Cluster

    Instrument Cluster WARNING LIGHTS AND CHIMES Base V6 engine instrument cluster (standard measure shown, metric similar) Optional V6 and GT instrument cluster (standard measure shown, metric similar) Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs.
  • Page 13 Instrument Cluster Service engine soon: The service engine soon indicator light illuminates when the ignition is first turned to the on position to check the bulb and to indicate whether the vehicle is ready for Inspection/Maintenance (I/M) testing. Normally, the service engine soon light will stay on until the engine is cranked, then turn itself off if no malfunctions are present.
  • Page 14 Instrument Cluster WARNING: Driving a vehicle with the brake system warning light on is dangerous. A significant decrease in braking performance may occur. It will take you longer to stop the vehicle. Contact your authorized dealer as soon as possible. Driving extended distances with the parking brake engaged can cause brake failure and the risk of personal injury.
  • Page 15 Instrument Cluster Engine coolant temperature: Illuminates when the engine coolant temperature is high. Stop the vehicle as soon as possible, switch off the engine and let cool. Refer to Engine coolant in the Maintenance and Specifications chapter. WARNING: Never remove the coolant reservoir cap while the engine is running or hot.
  • Page 16 Instrument Cluster Speed control: Illuminates when the speed control is engaged. Turns off when the speed control system is disengaged. Door ajar: Illuminates when the ignition is in the on position and any of the doors or the hood/trunk are not completely closed.

  • Page 17: Gauges

    Instrument Cluster GAUGES Base V6 engine instrument cluster (standard measure shown, metric similar) 2012 05+ Mustang (197) Owners Guide, 1st Printing USA (fus)
  • Page 18 Instrument Cluster Optional V6 and GT instrument cluster (standard measure shown, metric similar) Refer to Message center in this chapter to select preset colors or user definable colors (MyColor ) for the nighttime gauge backlighting. 1. Speedometer: Indicates the current vehicle speed. 2.

  • Page 19: Message Center

    Instrument Cluster 5. Engine oil pressure gauge (optional V6 and GT cluster only): Indicates engine oil pressure. The needle should stay in the normal operating range (between L and H). If the needle falls below the normal range, stop the vehicle, turn off the engine and check the engine oil level.
  • Page 20 Instrument Cluster MILES (km) TO E This displays an estimate of approximately how far you can drive with the fuel remaining in your tank under normal driving conditions. Remember to turn the ignition off when refueling to allow this feature to correctly detect the added fuel.
  • Page 21 Instrument Cluster Your vehicle must be moving to calculate instantaneous fuel economy. When your vehicle is not moving, this function shows ↓, one or no bars illuminated. Instantaneous fuel economy cannot be reset. TIMER Timer displays the trip elapsed drive time. To operate, do the following: 1.
  • Page 22 Instrument Cluster Note: Some systems show a message only if a condition is present. OIL LIFE This displays the remaining oil life. An oil change is required whenever indicated by the message center and according to the recommended maintenance schedule. USE ONLY RECOMMENDED ENGINE OILS.
  • Page 23 Instrument Cluster AMBIENT DIM Use this to adjust the brightness of the ambient lighting. Press RESET to choose the various settings. GAUGE COLOR, AMBIENT COLOR, HALO COLOR GAUGE COLOR: The instrument cluster gauges are backlit with white backlighting when the headlamps are off. When the headlamps are on, you can select one of the preset colors for the nighttime gauge backlighting or create up to three custom colors using the MyColor feature.
  • Page 24 Instrument Cluster 2. Press SETUP to scroll through the R (red), G (green), B (blue) and Exit options. 3. Press RESET to blend in more of the color being adjusted. 4. To save and exit, hold RESET for three seconds when prompted. Pressing RESET for less than three seconds will cycle back through the colors.
  • Page 25 Instrument Cluster Waiting four seconds or pressing the RESET button cycles the message center through each of the language choices. Press and hold RESET for two seconds to set the language choice. System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems.
  • Page 26 Instrument Cluster on when the engine is operating at normal speeds, contact your authorized dealer as soon as possible. CHECK PARK AID (if equipped) — Displayed when the transmission is in R (Reverse) and the reverse sensing system (park aid) is disabled. Refer to Rear park aid in this section to enable.
  • Page 27 Instrument Cluster SECURITY EVENT OCCURRED (if equipped) — Displayed when the active anti-theft system (if equipped) was activated since the prior ignition cycle. MYKEY ACTIVE DRIVE SAFELY — Displayed at startup when MyKey™ is in use. Refer to MyKey™ in the Locks and Security chapter for more information.

  • Page 28: Entertainment Systems

    AM/FM Single CD/MP3 satellite compatible sound system WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
  • Page 29 Entertainment Systems AM/FM Radio / VOL (Power/Volume): Press to turn the radio on/off. Turn the knob to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a nominal listening level when the ignition switch is turned back on.
  • Page 30 Entertainment Systems initiate or press OK to immediately initiate the search. If you press another control within those five seconds, the search will not initiate. The 10 strongest stations will be filled and the station stored in preset 1 will begin playing. If there are fewer than 10 strong stations, the system will store the last one in the remaining presets.
  • Page 31 Entertainment Systems LOAD: This control is not operational. To load a CD, simply insert the disc, label side up, into the CD slot. Play/Pause: Press to play/pause a track when playing a EJECT: Press to eject the CD. SEEK: Press SEEK access the previous/next track.
  • Page 32 Entertainment Systems COMPRESSION: Press MENU repeatedly until COMPRESSION ON/OFF appears in the display. Use SEEK to switch between ON/OFF. When COMPRESSION is ON, the system will bring the soft and loud CD passages together for a more consistent listening level. SHUFFLE: Press MENU repeatedly until SHUFFLE ON/OFF appears in the display.
  • Page 33 Entertainment Systems SCAN: Press SCAN for a brief sampling of all available SIRIUS satellite channels. If a specific category is selected, (Jazz, Rock, News, etc.) press SCAN for a brief sampling of all available SIRIUS satellite channels within the selected category.
  • Page 34 Entertainment Systems only (i.e. ROCK). You may also select CATEGORY ALL to seek all available SIRIUS categories and channels. Press OK to close and return to the main menu. • SONG SEEK MENU- Press OK to enter song seek menu. Press SEEK to scroll through the following options:...
  • Page 35 Entertainment Systems • CHANNEL LOCKOUT MENU- Press OK to enter the Channel Lockout menu. Press the SEEK to scroll through the following options: a. LOCK/UNLOCK THIS CHANNEL: Press OK when LOCK/UNLOCK THIS CHANNEL is displayed and the display will read ENTER PIN.
  • Page 36 Entertainment Systems • SPEED COMPENSATED VOLUME: With this feature on, radio volume automatically gets louder with increasing vehicle speed to compensate for road and wind noise. The default setting is off. SEEK to adjust between SPEED OFF and levels 1–7. Recommended level is 1–3;...

  • Page 37: Auxiliary Input Jack (Line In)

    Auxiliary input jack (Line in) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
  • Page 38 Entertainment Systems 3. Attach one end of the audio extension cable to the headphone output of your player and the other end of the audio extension cable to the AIJ in your vehicle. 4. Turn the radio on, using either a tuned FM station or a CD loaded into the system.

  • Page 39: Usb Port

    USB port (if equipped) WARNING: Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device or feature that may take their focus off the road. Your primary responsibility is the safe operation of the vehicle.
  • Page 40 CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. 2012 05+ Mustang (197) Owners Guide, 1st Printing...
  • Page 41 Entertainment Systems Do not use any irregular shaped CDs or discs with a scratch protection film attached. CDs with homemade paper (adhesive) labels should not be inserted into the CD player as the label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather...

  • Page 42: Satellite Radio Information

    Entertainment Systems Sample MP3 structure If you are burning your own MP3 discs, it is important to understand how the system will read the structures you create. While various .mp3 files may be present, (files with .mp3 extensions other than mp3), only files with the .mp3 extension will be .mp3 played.
  • Page 43 Note: SIRIUS reserves the unrestricted right to change, rearrange, add or delete programming including canceling, moving or adding particular channels, and its prices, at any time, with or without notice to you. Ford Motor Company shall not be responsible for any such programming changes.
  • Page 44 Entertainment Systems Radio Display Condition Action Required ACQUIRING Radio requires more No action required. than two seconds to This message should produce audio for the disappear shortly. selected channel. SAT FAULT Internal module or If this message does system failure not clear within a short present.

  • Page 45: Navigation System

    Entertainment Systems Radio Display Condition Action Required NO SIGNAL Loss of signal from You are in a location the SIRIUS satellite that is blocking the or SIRIUS tower to SIRIUS signal (i.e., the vehicle antenna. tunnel, under an overpass, dense foliage, etc).

  • Page 46: Climate Controls

    Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) Temperature conversion: To switch between Fahrenheit and Celsius, refer to Message center in the Instrument Cluster chapter. Defrost: Distributes outside air through the windshield defroster vents and de-mister vents. Can be used to clear the windshield of fog and thin ice.
  • Page 47 Climate Controls Recirculated air: Press to activate/deactivate air recirculation in the vehicle. Recirculated air may reduce the amount of time needed to cool down the interior of the vehicle and may also help reduce undesired odors from reaching the interior of the vehicle. Recirculated air engages automatically when MAX A/C is selected or can be engaged manually in any airflow mode except (defrost).
  • Page 48 Climate Controls • To improve the A/C cool down, drive with the windows slightly open for 2-3 minutes after start up or until the vehicle has been “aired out.” • A small amount of air may be felt from the floor vent regardless of the air distribution setting that is selected.
  • Page 49 Climate Controls DUAL ZONE AUTOMATIC TEMPERATURE CONTROL (NAVIGATION BASED – IF EQUIPPED) Temperature conversion: To switch between Fahrenheit and Celsius, refer to Message center in the Instrument Cluster chapter. 1. CLIMATE: Press to control the climate control system through the touch display screen.
  • Page 50 Climate Controls Passenger heated seat (if equipped): Press to control the passenger heated seat. Refer to Heated seats in the Seating and Safety Restraints chapter for more information. Recirculated air: Press to activate/deactivate air recirculation in the vehicle. Recirculated air may reduce the amount of time needed to cool down the interior of the vehicle when used with A/C and may also help reduce undesired odors from reaching the interior of the vehicle.
  • Page 51 Climate Controls TOUCHSCREEN FUNCTIONS Temperature conversion: To switch between Fahrenheit and Celsius, refer to Message center in the Instrument Cluster chapter. Temperature: Press the up and down arrows on the left side of the screen to increase/decrease the airflow temperature for the driver side of the vehicle.
  • Page 52 Climate Controls Operating tips • To reduce fog build-up on the windshield during humid weather, select (defrost). Temperature and/or fan speed can also be increased to improve clearing. • To reduce humidity build-up inside the vehicle: do not drive with the system off or with (recirculated air) engaged.

  • Page 53: Rear Window Defroster

    Climate Controls REAR WINDOW DEFROSTER Press the control to clear the rear window of thin ice and fog. The LED will illuminate. The rear window defroster turns off automatically after 15 minutes, or when the ignition is turned off. To manually turn off the defroster before 15 minutes have passed, press the control again.

  • Page 54: Lights

    Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the low beam headlamps Automatic instrumentation illumination A light sensor in your vehicle monitors the outside lighting conditions and automatically sets the instrument panel illumination to one of the following modes: •...
  • Page 55 Lights The autolamp system also keeps the lights on for a predetermined amount of time after the ignition switch is turned to off. You can change the amount of time the lamps stay on by using the programming procedure that follows: Note: If the vehicle is equipped with autolamps, it will have the headlamps on with windshield wipers feature.
  • Page 56 Lights High beams • Push the lever toward the instrument panel to activate. • Pull the lever toward you to deactivate. Flash-to-pass Pull toward you, to the first detent, to activate and release to deactivate. Note: Vehicles equipped with HID headlamps will hear an audible click when activating this feature.
  • Page 57 Lights PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable switches in the vehicle during headlamp and parking lamp operation. • Move the control to the full upright position, past detent, to turn on the interior lamps. •...
  • Page 58 Lights • (1) 8 feet (2.4 meters) • (2) Center height of lamp to ground • (3) 25 feet (7.6 meters) • (4) Horizontal reference line 2. Measure the height from the center of your headlamp to the ground and mark an 8 foot (2.4 meter) horizontal reference line on the vertical wall or screen at this height (a piece of masking tape works well).

  • Page 59: Turn Signal Control

    Lights 4. Locate the vertical adjuster on each headlamp. • Halogen headlamp (1) • HID headlamp (2) 5. Then use a 7 mm Allen wrench or a Phillips screwdriver to adjust the headlamp up or down. HORIZONTAL AIM IS NOT REQUIRED FOR THIS VEHICLE AND IS NON-ADJUSTABLE.

  • Page 60: Bulb Replacement

    Lights INTERIOR LAMPS Dome/Map lamps The dome lamp lights when:. • any door is opened. • any of the remote entry controls are pressed and the ignition is off. • the instrument panel dimmer switch is rotated up, past the detent, until the courtesy lamps come on.
  • Page 61 Lights Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to ensure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time.
  • Page 62 Lights Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in the off position, then open the hood. 2. Disconnect the electrical connector from the bulb by depressing the retainer clip and pulling rearward. 3. Remove the bulb by rotating it counterclockwise and pulling it straight out.
  • Page 63 Lights Replacing front parking lamp/turn signal bulbs 1. Make sure the headlamp control is in the off position and open the hood. Halogen headlamp HID headlamp 2. Remove the hex head screws attaching the underbody forward aeroshield and remove to gain access to the front parking lamp/turn signal assembly.
  • Page 64 Lights Replacing front sidemarker bulb 1. Make sure the headlamp control is in the off position. 2. Remove the hex head screws attaching the underbody forward aeroshield and remove to gain access to the front sidemarker assembly. 3. Rotate the socket counterclockwise and remove from the lamp assembly.
  • Page 65 Lights 3. Unbolt the three tail lamp attachment nuts and remove the lamp assembly. 4. Rotate the LED assembly counterclockwise and remove it from the lamp assembly. 5. Disconnect the LED assembly from the electrical connector and replace the LED assembly. 6.
  • Page 66 Lights Replacing rear sidemarker lamp bulbs 1. Make sure the headlamp switch is in the off position and locate the sidemarker on the rear bumper fascia. 2. Insert a flathead screwdriver between the rear of the sidemarker lens and the bumper fascia. 3.
  • Page 67 Lights Replacing fog lamp bulbs (GT-CS) (if equipped) 1. Make sure the headlamp control is in the off position and open the hood. 2. Remove the underbody air deflector panel screws and panel. 3. Disconnect the electrical connector from the bulb by pulling it straight off.

  • Page 68: Driver Controls

    Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Press the end of the stalk: •...
  • Page 69 Driver Controls TILT STEERING WHEEL To adjust the steering wheel: 1. Hold the steering wheel with one hand. With the other hand, push the lever down to unlock the steering column. 2. Tilt the steering column to its desired position. 3.
  • Page 70 Driver Controls Flexible visor storage system (if equipped) Visors equipped with the flexible visor storage system can accommodate various storage accessories. A sunglass clip and multi-function clip are provided. To attach one of the accessories, do the following: 1. Insert the provided removal tool (on the accessory holder) or a coin into the slot on the plug and turn 1/4-turn in either direction to...
  • Page 71 Driver Controls Compass zone adjustment 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map. 2. Turn ignition to the on position. 7 8 9 1011 3. Press and hold the 7 and 9 radio preset buttons together for approximately five seconds until ZONE XX appears in the CID.
  • Page 72 Driver Controls 2. To calibrate, press and hold the 7 and 9 radio preset buttons together for approximately 10 seconds until CAL appears. Release the buttons. 3. Slowly drive the vehicle in a circle (less than 3 mph [5 km/h]) until the CAL display changes to the direction value (N, S, E, W, etc.).

  • Page 73: Power Windows

    Driver Controls accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty. Auxiliary power points can be found in the following locations: • On the instrument panel • Inside the center console storage bin Do not use the power point for operating the cigarette lighter element (if equipped).
  • Page 74 Driver Controls Press and pull the switches to open and close windows. • Press down (to the first detent) and hold the switch to open. • Pull up (to the first detent) and hold the switch to close. One-touch up or down (front windows only) This feature allows the driver or passenger’s window to open or close fully without holding the control down.
  • Page 75 Driver Controls Short drop glass (front windows only) In order to improve door efforts and sealing, your vehicle is equipped with short drop glass. This feature lowers the glass when either door is opened. The glass returns to its closed position when the door is closed. Proper operation of the short drop glass requires that the windows be calibrated.

  • Page 76: Mirrors

    Driver Controls 3. Turn the ignition key to the off position, then turn back to the on position. 4. Pull and hold the rear window switch up and hold for three seconds, the rear windows will begin to start moving up. Accessory delay With accessory delay, the window switches, convertible top (if equipped) and radio may be used for up to 10 minutes after the ignition switch is...

  • Page 77: Speed Control

    Driver Controls EXTERIOR MIRRORS Power side view mirrors WARNING: Do not adjust the mirror while the vehicle is in motion. To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and rotate the control counterclockwise to adjust the left mirror.
  • Page 78 Driver Controls Optional controls RESUME ON/OFF: Press to turn the system on or off. SET (+): Press to set a speed or to increase a set speed. SET (–): Press to decrease a set speed. RES / RESUME: Press to resume a set speed. Setting speed control The set speed control: 1.
  • Page 79 Driver Controls Increasing speed while using speed control To increase the set speed: • Press and hold SET (+) until you get to the desired speed, then release. You can also use SET (+) to operate the tap-up function. Press and release SET (+) to increase the vehicle set speed in 1 mph (1.6 km/h) increments.
  • Page 80 Driver Controls • Press to change radio stations/CD tracks. Refer to the Navigation System supplement for more information on using this feature. With SYNC system (if equipped) • Press to use the voice command features. For further information on using voice commands with the SYNC system, refer to the SYNC supplement.
  • Page 81 Driver Controls Car2U Home Automation System (if equipped) The Car2U Home Automation System is a universal transmitter located in the driver’s visor that includes two primary features – a garage door opener and a platform for remote activation of devices within the home.
  • Page 82 Driver Controls • Fixed code garage door openers were produced prior to 1996. Fixed code uses the same coded signal every time. It is manually programmed by setting DIP switches for a unique personal code. If you do not know if your garage door opener is a rolling code or fixed code device, open your garage door opener’s remote control battery...
  • Page 83 Driver Controls 1. Firmly press the two outer Car2U system buttons for 1–2 seconds, then release. 2. Go to the garage to locate the garage door opener motor and its “learn” button. You may need a ladder to reach the unit and you may need to remove the unit’s cover or light lens to locate the “learn”...
  • Page 84 Driver Controls The indicator light above the selected button will turn on to confirm that the Car2U system is responding to the button command. To program another rolling code device such as an additional garage door opener, a security device or home lighting, repeat Steps 1 through 4 substituting a different function button in Step 3 than what you used for the garage door opener.
  • Page 85 Driver Controls Switch position 1 Up, on or + Middle, neutral or 0 Down, off or – L=left; M=middle; R=right 3. To input these positions into the Car2U system, simultaneously press all three Car2U system buttons for a few seconds and then release to put the device into programming mode.
  • Page 86 Driver Controls After successful programming, you will be able to operate your Car2U system by pressing the button you programmed to activate the opener. The indicator light above the selected button will turn on to confirm that the Car2U system is responding to the button command. Erasing the Car2U Home Automation System buttons Note: The system allows for three devices to be programmed.
  • Page 87 Driver Controls POSITIVE RETENTION FLOOR MAT WARNING: Do not install additional floor mats on top of the factory installed floor mats as they may interfere with the accelerator or the brake pedals. Position the floor mat so that the eyelets are over the retention posts and press down to lock in.
  • Page 88 Driver Controls Note: The latch handles must be pulled downward fully to allow the latch to fully rotate into the open position. 3. Unclamp the top from the windshield header by pulling each latch handle down and then rotating the latch to the rear until it clears the header.
  • Page 89 Driver Controls Installation of the boot (if equipped) Be sure the boot is secure on the vehicle before driving. 1. Install the boot on the vehicle by hooking the boot retaining clips on the back panel. 2. Install the boot on the right side tucking in the front part of the boot in the quarter panel and hooking the retaining clip on the side.
  • Page 90 Driver Controls Storing the boot 1. Position the boot right-side up and fold each side of the boot inward. 2. Turn the boot upside down and fold the left side of the boot inward. 3. Fold the right side inward and secure the boot with the strap. Stow the boot in the trunk.
  • Page 91 Driver Controls To raise the convertible top: 1. Bring the vehicle to a complete stop. Key must be in the on position. It is recommended that the vehicle’s engine is running when raising the top to prevent draining the battery. 2.
  • Page 92 Driver Controls ROLLER BLIND SUN SHADE (IF EQUIPPED) If your vehicle is equipped with a glass roof, the roller blind sun shade will cover the glass roof inside your vehicle. Use the center-mounted cup handle to slide the shade open or closed. INTERIOR TRUNK CONTROL The remote trunk release button is located on the instrument panel.

  • Page 93: Locks And Security

    Locks and Security KEYS Your vehicle may be equipped with two Integrated Keyhead Transmitters (IKTs). The key blade functions as a programmed key which starts the vehicle and unlocks/locks all the doors. The transmitter portion functions as the remote entry transmitter. Your IKTs are programmed to your vehicle;...
  • Page 94 Locks and Security MYKEY™ The MyKey™ feature allows you to program a restricted driving mode to promote good driving habits. All but one of the keys programmed to the vehicle can be activated as a MyKey™. The key will remain restricted until MyKey™...
  • Page 95 Locks and Security vehicles equipped with push button start, put the intelligent access key in the backup slot; see the Driving chapter for the location of the backup slot. Turn the ignition on. Use the message center buttons to do the following: 1.
  • Page 96 MyKey™ is not compatible with non-Ford approved aftermarket remote start systems. If you choose to install a remote start system please see your authorized dealer for a Ford approved remote start system. Vehicles equipped with traditional keys: When using a Ford-approved remote start system, the default settings will recognize the remote start system as an additional admin key with its associated privileges.
  • Page 97 Locks and Security 2. Remote start the vehicle using a remote start fob. 3. Follow Steps 1-4 in the Create a MyKey™ section. Vehicles equipped with an intelligent access key (push button start) • It is not possible to program the remote start system as a MyKey™ on vehicles equipped with intelligent access key (push button start).
  • Page 98 Locks and Security Troubleshooting Condition Potential Causes • Key in the ignition is already a Can’t create a MyKey™ MyKey™. • Key in the ignition is the last remaining admin key (there always has to be at least one admin key). •...

  • Page 99: Locks

    Locks and Security Condition Potential Causes • Purchase a new key from your Lost the only admin key authorized dealer. • For programming spare keys, refer Lost any key to the Programming spare keys section in this chapter. • Vehicle has a remote start system I accidentally programmed all keys as MyKeys™...
  • Page 100 Locks and Security Press the control to unlock all doors. Press the control to lock all doors. Locking and unlocking with keys Your vehicle’s keys are designed to lock and unlock the driver’s door, as well as open the trunk. •...
  • Page 101 Locks and Security The autolock feature repeats when: • any door is opened then closed while the ignition is in the on position and the vehicle speed is 9 mph (15 km/h) or lower, and • the vehicle attains a speed greater than 12 mph (20 km/h). Deactivating/activating autolock Your vehicle comes with the autolock feature enabled.
  • Page 102 Locks and Security 8. Turn the ignition to the off position. The horn will chirp once to confirm the procedure is complete. Autounlock (if equipped) The autounlock feature will unlock all the doors when: • the ignition is in the on position, all the doors are closed, and the vehicle has been in motion at a speed greater than 12 mph (20 km/h);...
  • Page 103 Locks and Security 6. To enable/disable the autounlock feature, press the lock control, then press the unlock control. The horn will chirp once if autounlock was deactivated or twice (one short and one long chirp) if autounlock was activated. 7. Turn the ignition to the off position. The horn will chirp once to confirm the procedure is complete.
  • Page 104 Locks and Security WARNING: Do not leave children, unreliable adults, or animals unattended in the vehicle. On hot days, the temperature in the trunk or vehicle interior can rise very quickly. Exposure of people or animals to these high temperatures for even a short time can cause death or serious heat-related injuries, including brain damage.
  • Page 105 Locks and Security The IKT allows you to: • remotely unlock the vehicle doors. • remotely lock all the vehicle doors. • remotely open the trunk. • activate the personal alarm. • arm and disarm the active anti-theft system. • operate the illuminated entry feature.
  • Page 106 Locks and Security Two-stage unlocking may be disabled or re-enabled by simultaneously pressing the controls on the IKT for four seconds (disabling two stage unlock allows all vehicle doors to unlock simultaneously). The turn lamps will flash twice to indicate that two-stage unlock was enabled or disabled.
  • Page 107 Locks and Security • Ensure that the trunk is closed and latched before driving your vehicle. Failure to properly latch the trunk may cause objects to fall out or block the driver’s rear view. The remote entry system allows you to open the trunk while the ignition is in any position.
  • Page 108 Locks and Security Note: Replacement of the battery will not cause the IKT or IA key to become de-programmed from your vehicle. They should operate normally after battery replacement. Replacing lost integrated keyhead transmitters (IKTs) If you would like to have your integrated keyhead transmitters reprogrammed because you lost one, or would like to buy additional IKTs, you can either reprogram them yourself, or take all IKTs to your authorized dealer for reprogramming.

  • Page 109: Anti-Theft System

    Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
  • Page 110 Locks and Security Anti-theft indicator The anti-theft indicator is located in the instrument cluster. • When the ignition is in the off position, the indicator will flash once every two seconds to indicate the SecuriLock system is functioning as a theft deterrent.
  • Page 111 Locks and Security towed to an authorized dealer. The key codes need to be erased from your vehicle and new coded keys will need to be programmed. Replacing coded keys can be very costly. Store an extra programmed key away from the vehicle in a safe place to help prevent any inconveniences.
  • Page 112 Locks and Security 5. Turn the ignition from the 1 (off) position to the 3 (on) position. Keep the ignition in the 3 (on) position for at least three seconds, but no more than 10 seconds. 6. Turn the ignition to the 1 (off) position and remove the second previously programmed coded key from the ignition.
  • Page 113 Locks and Security The interior motion detection and vehicle incline sensing systems will operate only when the vehicle is locked using the remote keyless entry transmitter or when using the power door lock control with the accompanying door open and all doors then become closed.
  • Page 114 Locks and Security The turn signal lamps will flash once when all doors, the hood and the trunk are closed indicating the vehicle is locked and entering the 20 second countdown. If any closure is not properly closed the turn signal lamps will not flash and that closure will not be armed.

  • Page 115: Seating And Safety Restraints

    Seating and Safety Restraints FRONT SEATS WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. WARNING: Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
  • Page 116 Seating and Safety Restraints Adjustable head restraints (if equipped) Your vehicle may be equipped with front row outboard head restraints that are vertically adjustable. WARNING: To minimize the risk of neck injury in the event of a crash, the driver and passenger occupants should not sit in and/or operate the vehicle, until the head restraint is placed in its proper position.
  • Page 117 Seating and Safety Restraints 3. Lower the head restraint by pressing and holding the guide sleeve adjust/release button and pushing down on the head restraint. Properly adjust the head restraint so that the top of the head restraint is even with the top of your head and positioned as close as possible to the back of your head.
  • Page 118 Seating and Safety Restraints 2. Simultaneously press and hold both the adjust/release button and the unlock/remove button, then pull up on the head restraint. To reinstall the adjustable head restraint, do the following: 1. Insert the two stems into the guide sleeve collars.
  • Page 119 Seating and Safety Restraints Lift handle to move seat forward or backward. Pull lever up to adjust the angle of the seatback. Four-way seat adjust (driver side only) Pump the handle upwards to raise the cushion and pump downward to lower the cushion to the desired location.
  • Page 120 Seating and Safety Restraints WARNING: Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop. WARNING: Always drive and ride with your seatback upright and the lap belt snug and low across the hips. WARNING: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision.
  • Page 121 Seating and Safety Restraints Move the switch in the direction of the arrows to raise or lower the front portion of the seat cushion. Move the switch in the direction of the arrows to raise or lower the rear portion of the seat cushion. Press the switch in the direction of the arrows to move the seat forward, backward, up or down.
  • Page 122 Seating and Safety Restraints Heated seats (if equipped) WARNING: Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion, or other physical conditions, must exercise care when using the seat heater. The seat heater may cause burns even at low temperatures, especially if used for long periods of time.
  • Page 123 Seating and Safety Restraints Use the recliner handle to return the seatback to the desired position. REAR SEATS (IF EQUIPPED) Non-adjustable head restraints Your vehicle is equipped with second row outboard non-adjustable head restraints. The head restraints can be rotated forward to improve rear vision when there are no rear occupants.
  • Page 124 Seating and Safety Restraints Press the button to rotate the head restraint forward in order to improve rear vision when there are no rear seat occupants. 2nd row seat/split-folding rear seat (if equipped) One or both rear seatbacks (coupe only) can be folded down to provide additional cargo space.
  • Page 125 Seating and Safety Restraints Rear seat delete (if equipped) This is not a seating position. Persons or child seats cannot be placed in the rear of vehicles with the rear seat delete option. WARNING: In a collision, passengers who are unbelted are significantly more likely to be seriously injured or killed.
  • Page 126 Seating and Safety Restraints How does the Personal Safety System™ work? The Personal Safety System can adapt the deployment strategy of your vehicle’s safety devices according to crash severity and conditions. A collection of crash sensors provides information to the Restraints Control Module (RCM).
  • Page 127 Seating and Safety Restraints very close to the airbag. For other occupants, this occurs when the occupant is not properly restrained by safety belts or child safety seats and they move forward during pre-crash braking. The most effective way to reduce the risk of unnecessary injuries is to make sure all occupants are properly restrained.

  • Page 128: Safety Belt System

    Seating and Safety Restraints effectiveness of the safety belts. In frontal collisions, the safety belt pretensioners can be activated alone or, if the collision is of sufficient severity, together with the front airbags. Front safety belt energy management retractors The front outboard safety belt energy management retractors allow webbing to be pulled out of the retractor in a gradual and controlled manner in response to the occupant’s forward momentum.
  • Page 129 Seating and Safety Restraints WARNING: Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision. WARNING: All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag supplemental restraint system (SRS) is provided.
  • Page 130 Seating and Safety Restraints Combination lap and shoulder belts The presenter arm (available on the coupe only) is intended to improve access to the safety belt and to allow access to the rear seat. Rotate the presenter arm toward the front of the vehicle until it locks into place.
  • Page 131 Seating and Safety Restraints 2. To unfasten, press the release button and remove the tongue from the buckle. WARNING: The center of the rear seat is NOT designed as a seating position and is not equipped with safety belts. The LATCH anchors were not designed to be used with a child seat in the center position and there is no tether anchor available at the center.
  • Page 132 Seating and Safety Restraints Safety belt locking modes All safety restraints in the vehicle are combination lap and shoulder belts. The driver safety belt has the first locking mode and the front outboard passenger and rear seat safety belts have both types of locking modes described as follows: Vehicle sensitive mode This is the normal retractor mode, which allows free shoulder belt length...
  • Page 133 Seating and Safety Restraints How to disengage the automatic locking mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. WARNING: After any vehicle collision, the safety belt system at all passenger seating positions must be checked by an authorized dealer to verify that the “automatic locking retractor”...
  • Page 134 Seating and Safety Restraints Use only extensions manufactured by the same supplier as the safety belt. Manufacturer identification is located at the end of the webbing on the label. Also, use the safety belt extension only if the safety belt is too short for you when fully extended.
  • Page 135 Seating and Safety Restraints Both the driver’s and passenger’s safety belt usages are monitored and either may activate the Belt-Minder feature. The warnings are the same for the driver and the front passenger. If the Belt-Minder warnings have expired (warnings for approximately five minutes) for one occupant (driver or front passenger), the other occupant can still activate the Belt-Minder feature.
  • Page 136 Seating and Safety Restraints The following are reasons most often given for not wearing safety belts (All statistics based on U.S. data): Reasons given... Consider... “Crashes are rare events” 36700 crashes occur every day. The more we drive, the more we are exposed to “rare”...
  • Page 137 Seating and Safety Restraints Reasons given... Consider... “I have an airbag” Airbags offer greater protection when used with safety belts. Frontal airbags are not designed to inflate in rear and side crashes or rollovers. “I’d rather be thrown clear” Not a good idea. People who are ejected are 40 times more likely to DIE.
  • Page 138 Seating and Safety Restraints • The ignition switch is in the off position • The driver and front passenger safety belts are unbuckled WARNING: While the design allows you to deactivate your Belt-Minder , this system is designed to improve your chances of being safely belted and surviving an accident.

  • Page 139: Airbags

    Seating and Safety Restraints AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Airbags DO NOT inflate slowly; there is a risk of injury from a deploying airbag.
  • Page 140 Seating and Safety Restraints WARNING: Never place your arm over the airbag module as a deploying airbag can result in serious arm fractures or other injuries. To properly position yourself away from the airbag: • Move your seat to the rear as far as you can while still reaching the pedals comfortably.
  • Page 141 Seating and Safety Restraints Children and airbags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
  • Page 142 Seating and Safety Restraints The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
  • Page 143 Seating and Safety Restraints • a readiness light and tone • and the electrical wiring which connects the components • Side curtain airbag system. Refer to Side curtain airbag system later in this chapter. • Front passenger sensing system. Refer to Front passenger sensing system later in this chapter.
  • Page 144 Seating and Safety Restraints The front passenger sensing system uses a passenger airbag off or pass airbag off indicator which will illuminate and stay lit to remind you that the front passenger frontal airbag is disabled. The indicator lamp is located on the front edge of the map lamps. Note: The indicator lamp will illuminate for a short period of time when the ignition is turned to the on position to confirm it is functional.
  • Page 145 Seating and Safety Restraints • If the indicator lamp remains lit even after this, the person should be advised to ride in the rear seat. Pass Airbag Off Occupant Passenger Airbag Indicator Lamp Empty seat Unlit Disabled Small child in child Disabled safety seat or booster Small child with safety...
  • Page 146 Seating and Safety Restraints Pass Airbag Off Objects Passenger Airbag Indicator Lamp Small (i.e. three-ring Unlit Disabled binder, small purse, bottled water) Medium (i.e. heavy Disabled briefcase, fully packed luggage) Empty seat, or small Disabled to medium object with safety belt buckled If you think that the status of the passenger airbag off indicator lamp is incorrect, check for the following: •...
  • Page 147 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this owner’s guide.
  • Page 148 Seating and Safety Restraints WARNING: Do not use accessory seat covers. The use of accessory seat covers may prevent the deployment of the side airbags and increase the risk of injury in an accident. WARNING: Do not lean your head on the door. The side airbag could injure you as it deploys from the side of the seatback.
  • Page 149 Seating and Safety Restraints The side airbags are fitted on the outboard side of the seatbacks of the front seats. In certain lateral collisions, the airbag on the side affected by the collision will be inflated. The airbag was designed to inflate between the door panel and occupant to further enhance the protection provided to occupants in side impact collisions.
  • Page 150 Seating and Safety Restraints Determining if the system is operational The SRS uses a readiness light in the instrument cluster or a tone to indicate the condition of the system. Refer to the Warning lights and chimes section in the Instrument Cluster chapter. Routine maintenance of the airbag is not required.
  • Page 151 Recommendations for Safety Restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consult your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in the vehicle.
  • Page 152 Seating and Safety Restraints Recommendations for Safety Restraints for Children Child size, height, weight, or Recommended restraint type Infants or Children weighing 40 lb (18 kg) or Use a child safety toddlers less (generally age four or seat (sometimes younger) called an infant carrier, convertible seat, or toddler seat).
  • Page 153 Seating and Safety Restraints Recommendations for attaching child safety restraints for children Use any attachment method as indicated below by “X” LATCH LATCH Safety Safety Safety (lower (lower belt belt and belt Restraint Child anchors anchors LATCH only Type Weight only) (lower tether...
  • Page 154 Highway Traffic Safety Administration (NHTSA) provides education and training to ensure that all children ages 0 to 16 are properly restrained in the correct restraint system. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and your pediatrician to make sure your seat is appropriate for your child and properly installed in the vehicle.
  • Page 155 Seating and Safety Restraints If the child is the proper height, age, and weight (as specified by your child safety seat or booster manufacturer), fits the restraint and can be restrained properly, then restrain the child in the child safety seat or with the belt-positioning booster.
  • Page 156 Seating and Safety Restraints When installing a child safety seat with combination lap/shoulder belts: • Use the correct safety belt buckle for that seating position. • Insert the belt tongue into the proper buckle until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
  • Page 157 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
  • Page 158 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is pulled out. 6. Allow the belt to retract to remove slack. The belt will click as it retracts to indicate it is in the automatic locking mode.
  • Page 159 For forward-facing child seats, the top tether strap must also be attached to the proper top tether anchor, if a top tether strap has been provided with your child seat. Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Attaching child safety seats with tether straps and Recommendations for attaching child safety restraints for children in this chapter for more information.
  • Page 160 Seating and Safety Restraints Your vehicle may have LATCH lower anchors for child seat installation at the seating positions marked with the child seat symbol. The LATCH anchors (if equipped) are located at the rear section of the rear seat between the cushion and seat back, below the locator symbols on the seat back.
  • Page 161 Seating and Safety Restraints Combining safety belt and LATCH lower anchors for attaching child safety seats When used in combination, either the safety belt or the LATCH lower anchors may be attached first, provided a proper installation is achieved. Attach the tether strap afterward, if included with the child seat. Refer to Recommendations for attaching child safety restraints for children in this chapter.
  • Page 162 Seating and Safety Restraints Vehicles without rear seats Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor. Once the child safety seat has been installed, using either the safety belt, the lower anchors of the LATCH system, or both, you can attach the top tether strap.
  • Page 163 Seating and Safety Restraints 2. Locate the correct anchor for the selected seating position. 3. Open the tether anchor cover. 2012 05+ Mustang (197) Owners Guide, 1st Printing USA (fus)
  • Page 164 Seating and Safety Restraints 4. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5. Tighten the child safety seat tether strap according to the manufacturer’s instructions.
  • Page 165 Seating and Safety Restraints Note: The attachments for the convertible boot located on the back of the head restraints are not tether anchors. 2. Access tether anchors located behind the seatback under the vinyl tag marked with the child tether anchor symbol.
  • Page 166 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. 2012 05+ Mustang (197)
  • Page 167 Seating and Safety Restraints Booster seats position a child so that vehicle lap/shoulder safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably at the edge of the cushion, while minimizing slouching.
  • Page 168 Seating and Safety Restraints Types of booster seats There are generally two types of belt-positioning booster seats: backless and high back. Always use booster seats in conjunction with the vehicle lap/shoulder belt. • Backless booster seats If your backless booster seat has a removable shield, remove the shield.
  • Page 169 Seating and Safety Restraints Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
  • Page 170 Refer to the child restraint manufacturer’s instructions for additional inspection and maintenance information specific to the child restraint. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.

  • Page 171: Tires, Wheels And Loading

    Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
  • Page 172 Tires, Wheels and Loading WARNING: The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
  • Page 173 Ford Motor Company. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.

  • Page 174: Tire Inflation

    Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
  • Page 175 Tires, Wheels and Loading Note: If you have to drive a distance to get air for your tire(s), check and record the tire pressure first and add the appropriate air pressure when you get to the pump. It is normal for tires to heat up and the air pressure inside to go up as you drive.
  • Page 176 Tires, Wheels and Loading Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Inspect all your tires, including the spare, frequently, and replace them if one or more of the following conditions exist: Tire wear When the tread is worn down to 1/16th of an inch (2 mm), tires must be replaced to help prevent your vehicle from skidding and...
  • Page 177 (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door.
  • Page 178 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your tire pressure monitoring system.
  • Page 179 Tires, Wheels and Loading • Do not run over curbs or hit the tire against a curb when parking WARNING: If your vehicle is stuck in snow, mud, sand, etc., do not rapidly spin the tires; spinning the tires can tear the tire and cause an explosion.
  • Page 180 Tires, Wheels and Loading • Rear-wheel drive (RWD) vehicles (front tires at top of diagram) Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
  • Page 181 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
  • Page 182 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. Letter rating Speed rating - mph (km/h) 81 mph (130 km/h) 87 mph (140 km/h) 99 mph (159 km/h) 106 mph (171 km/h) 112 mph (180 km/h) 118 mph (190 km/h)
  • Page 183 Tires, Wheels and Loading 12. Treadwear, Traction and Temperature Grades • Treadwear: The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 ⁄...
  • Page 184 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below. Note: Tire Quality Grades do not apply to this type of tire. 1.
  • Page 185 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.

  • Page 186: Tire Pressure Monitoring System (Tpms)

    Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
  • Page 187 Tires, Wheels and Loading The tire pressure monitoring system complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 188 Tires, Wheels and Loading Understanding your tire pressure monitoring system (TPMS) The tire pressure monitoring system measures pressure in your four road tires and sends the tire pressure readings to your vehicle. The low tire pressure warning light will turn on if the tire pressure is significantly low. Once the light is illuminated, your tires are under-inflated and need to be inflated to the manufacturer’s recommended tire pressure.
  • Page 189 Tires, Wheels and Loading When you believe your system is not operating properly The main function of the tire pressure monitoring system is to warn you when your tires need air. It can also warn you in the event the system is no longer capable of functioning as intended.
  • Page 190 Tires, Wheels and Loading Low tire Possible Customer action required pressure cause warning light Flashing warning Spare tire in Your temporary spare tire is in light use. Repair the damaged road wheel and re-mount it on the vehicle to restore system functionality.
  • Page 191 WARNING: Snow tires must be the same size, load index, speed rating as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.

  • Page 192: Vehicle Loading

    Tires, Wheels and Loading SUMMER TIRES Your Ford vehicle may be equipped with summer tires to provide superior performance on wet and dry roads. Summer tires do not have the Mud and Snow (M+S or M/S) tire traction rating on the tire side wall.
  • Page 193 Tires, Wheels and Loading Payload – is the combined weight of cargo and passengers that the vehicle is carrying. The maximum payload for your vehicle can be found on the Tire Label on the B-Pillar or the edge of the driver’s door (vehicles exported outside the US and Canada may not have a Tire Label).
  • Page 194 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
  • Page 195 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
  • Page 196 Tires, Wheels and Loading • Example only: WARNING: Exceeding the Safety Compliance Certification Label vehicle weight rating limits could result in substandard vehicle handling or performance, engine, transmission and/or structural damage, serious damage to the vehicle, loss of control and personal injury.
  • Page 197 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
  • Page 198 Tires, Wheels and Loading 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle. 3. Subtract the combined weight of the driver and passengers from XXX kg or XXX lbs. 4. The resulting figure equals the available amount of cargo and luggage load capacity.

  • Page 199: Trailer Towing

    Tires, Wheels and Loading 1,400 - (2 x 220) - (9 x 100) = 1,400 - 440 - 900 = 60 lb. Now you have the load capacity to transport the cement and your friend home. In metric units, the calculation would be: 635 kg - (2 x 99 kg) - (9 x 45 kg) = 635 - 198 - 405 = 32 kg.
  • Page 200 Tires, Wheels and Loading WARNING: Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of the vehicle and could result in engine damage, transmission damage, structural damage, loss of vehicle control, vehicle rollover and personal injury. Preparing to tow Use the proper equipment for towing a trailer and make sure it is properly attached to your vehicle.
  • Page 201 Tires, Wheels and Loading Trailer lamps Trailer lamps are required on most towed vehicles. Make sure all running lights, brake lights, turn signals and hazard lights are working. Do not splice into the vehicle lamp wiring for trailer lamps. Your vehicle uses an advanced electronic module to control and monitor your vehicle lamps.

  • Page 202: Recreational Towing

    Tires, Wheels and Loading RECREATIONAL TOWING Follow these guidelines if you have a need for recreational (RV) towing. An example of recreational towing would be towing your vehicle behind a motorhome. These guidelines are designed to ensure that your transmission is not damaged. Do not tow your vehicle with any wheels on the ground, as vehicle or transmission damage may occur.

  • Page 203: Driving

    Driving STARTING Positions of the ignition 1. Off — locks the automatic transmission gearshift lever and allows key removal. Note: In order to switch off the engine while the vehicle is in motion, shift to neutral and use the brakes to bring the vehicle to a safe stop.
  • Page 204 Driving WARNING: Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. WARNING: Do not start your vehicle in a closed garage or in other enclosed areas.
  • Page 205 Driving If starting a vehicle with an automatic transmission: • Make sure the gearshift is in P (Park). • Make sure the parking brake is set. If starting a vehicle with a manual transmission: • Make sure the parking brake is set.
  • Page 206 Driving 3. Turn the key to 3 (on) without turning the key to 4 (start). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights. Starting the engine 1.
  • Page 207 Driving WARNING: If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important ventilating information If the engine is idling while the vehicle is stopped for a long period of time, open the windows at least 1 inch (2.5 cm) or adjust the heating or air conditioning to bring in fresh air.
  • Page 208 Driving • Make certain that the extension cord is in excellent condition (not patched or spliced). Store your extension cord indoors at temperatures above 32°F (0°C). Outdoor conditions can deteriorate extension cords over a period of time. • To reduce the risk of electrical shock, do not use your heater with ungrounded electrical systems or two pronged (cheater) adapters.

  • Page 209: Brakes

    Driving BRAKES Occasional brake noise is normal. If a metal-to-metal, continuous grinding or continuous squeal sound is present, the brake linings may be worn-out and should be inspected by an authorized dealer. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by an authorized dealer.

  • Page 210: Advancetrac

    Driving Parking brake To set the parking brake (1), pull the parking brake handle up as far as possible. The BRAKE warning lamp will illuminate and will remain illuminated until the parking brake BRAKE is released. To release, press and hold the button (2), pull the handle up slightly, then push the handle down.
  • Page 211 Driving WARNING: Vehicle modifications involving braking system, aftermarket roof racks, suspension, steering system, tire construction and/or wheel/tire size may change the handling characteristics of the vehicle and may adversely affect the performance of the AdvanceTrac system. In addition, installing any stereo loudspeakers may interfere with and adversely affect the AdvanceTrac system.
  • Page 212 Driving The AdvanceTrac system includes a stability control button located on the center console, a stability control light and a stability control off light in the instrument cluster. Both the stability control light and the stability control off light in the instrument cluster will illuminate temporarily during start-up as part of a normal system self-check.
  • Page 213 Driving If the TCS is activated excessively in a short period of time, the braking portion of the system may become temporarily disabled to allow the brakes to cool down. In this situation, the TCS will use only engine power reduction or transfer to help control the wheels from over-spinning.
  • Page 214 Driving The stability control button can be used to enable unique AdvanceTrac modes. Full features of the AdvanceTrac system can be restored by pressing the stability control button again or by turning off and restarting the engine. When features of the AdvanceTrac system are off, the stability control off light will illuminate steadily.
  • Page 215 Driving AdvanceTrac Sport Mode (if equipped) The AdvanceTrac system provides an available sport mode on some models. This can be selected utilizing the stability off button as shown in the table above. Sport mode is not intended for use on public roadways as this mode provides less AdvanceTrac system intervention than when the default ESC and traction control systems are on.
  • Page 216 Driving Note: If the battery is disconnected or removed, the steering setting will default to standard. Refer to Message center in the Instrument Cluster chapter. AXLE INFORMATION Traction-Lok™ axle (if equipped) This axle provides added traction on slippery surfaces, particularly when one wheel is on a poor traction surface.
  • Page 217 Driving If you cannot move the gearshift lever out of P (Park) with ignition in the on position and the brake pedal pressed: 1. Apply the parking brake. 2. Using a flat head screwdriver or similar tool, remove the cap. 3.

  • Page 218: Transmission Operation

    Driving AUTOMATIC TRANSMISSION OPERATION (IF EQUIPPED) Driving with a 6–speed automatic transmission Your vehicle has been designed to improve fuel economy by reducing fuel usage while coasting or decelerating. When you take your foot off the accelerator pedal and the vehicle begins to slow down the torque converter clutch locks up and aggressively shuts off fuel flow to the engine while decelerating.
  • Page 219 Driving N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll. Hold the brake pedal down while in this position. D (Drive) standard mode The normal driving position for the best fuel economy. Transmission operates in gears one through six.
  • Page 220 Driving 2 (Second) This position allows for second gear only. • Provides engine braking. • Use to start-up on slippery roads. • To return to D (Drive) without overdrive or 3 (Third), move the transmission shift lever into the D (Drive) or 3 (Third) position. •...
  • Page 221 Driving 2. Press the clutch pedal to the floor, then put the gearshift lever in the neutral position. 3. Start the engine. 4. Press the brake pedal and move the gearshift lever to the desired gear; 1 (First) or R (Reverse). 5.
  • Page 222 Driving For the 3.7L V6 with 3.31 axle ratio, shift according to the following chart: Upshifts when accelerating (recommended for best fuel economy) Shift from: 1 - 2 13 mph (21 km/h) 2 - 3 26 mph (42 km/h) 3 - 4 37 mph (59 km/h) 4 - 5 43 mph (69 km/h)

  • Page 223: Reverse Sensing System

    Driving 3. Shift into R (Reverse) by pushing the gearshift knob down, then moving the lever fully to the left, then forward. Note: The gearshift lever can only be moved to R (Reverse) by pushing the knob down before shifting to reverse. This is a lockout feature which protects the transmission from accidentally engaging R (Reverse) when intending to select 1 (First).
  • Page 224 Driving WARNING: To help avoid personal injury, always use caution when in R (Reverse) and when using the RSS. WARNING: This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle.

  • Page 225: Rear-View Camera System

    Driving The RSS automatically turns on when the gearshift lever is placed in R (Reverse) and the ignition is on. A control in the message center allows the driver to disable the system, refer to Message center in the Instrument Cluster chapter for more information. Keep the RSS sensors (located on the rear bumper/fascia) free from snow, ice and large accumulations of dirt (do not clean the sensors with sharp objects).
  • Page 226 Driving Image delay if displayed through the rearview mirror: When shifting out of R (Reverse) and into any other gear, the image in the rearview mirror will remain on for a few seconds before it shuts off to assist in parking or trailer hookup. Image delay if displayed through the navigation screen: After shifting out of R (Reverse) and into any gear other than P (Park), the image in the navigation screen will remain until the vehicle speed...
  • Page 227 Driving Night time and dark area use At night time or in dark areas, the camera system relies on the reverse lamp lighting to produce an image. Therefore it is necessary that both reverse lamps are operating in order to get a clear image in the dark. If either of the lamps are not operating, stop using the camera system, at least in the dark, until the lamp(s) are replaced and functioning.
  • Page 228 Driving WARNING: Objects in the blind spot mirror are closer than they appear. DRIVING THROUGH WATER If driving through deep or standing water is unavoidable, proceed very slowly especially when the depth is not known. Never drive through water that is higher than the bottom of the wheel rims (for cars) or the bottom of the hubs (for trucks).

  • Page 229: Roadside Emergencies

    ROADSIDE ASSISTANCE Vehicles sold in the U.S. : Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...

  • Page 230: Hazard Flasher Control

    U.S. Ford and Lincoln vehicle customers who require Roadside Assistance, call 1-800-241-3673. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles (56 km). To obtain reimbursement information, U.S.

  • Page 231: Fuel Pump Shut-Off

    WARNING: Failure to inspect and if necessary repair fuel leaks after a collision may increase the risk of fire and serious injury. Ford Motor Company recommends that the fuel system be inspected by an authorized dealer after any collision. FUSES AND RELAYS...
  • Page 232 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
  • Page 233 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Protected Circuits Location Rating Driver rear window (convertible only) Not used (spare) SYNC Passenger rear window (convertible only) Brake transmission shift interlock (BTSI) Turn signals, Hazard flashers Left low beam headlamp Right low beam headlamp Courtesy lamps Switch illumination...
  • Page 234 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating Security module 7.5A Power mirrors Not used (spare) Center information display, Electronic finish panel, GPS Climate control Not used (spare) Power door locks, Trunk release Not used (spare) Navigation amp Diagnostic connector Fog lamps Park lamps, License lamps High beam headlamps...
  • Page 235 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating Radio/Navigation Not used (spare) Accessory delay (windows, automatic dimming rear view mirror [including microphone and compass] and door switch III) Not used (spare) Heated seat relay coils Not used (spare) Wiper relay and module, Blower relay 7.5A Passenger airbag deactivation...
  • Page 236 Roadside Emergencies If the battery has been disconnected and reconnected, refer to the Battery section of the Maintenance and Specifications chapter. The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Protected Circuits Location Rating 80A* Passenger compartment fuse panel —...
  • Page 237 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating — Not used 10A** Intercooler pump relay (Shelby only) 20A** Heated seats 10A** Alternator sense 20A* Auxiliary body module (ABM) 30A* Starter relay 30A* Rear amplifier (Shaker 1000 radio) 30A* Powertrain relay 20A* Powerpoint (instrument panel) 10A**...
  • Page 238 Roadside Emergencies Fuse/Relay Fuse Amp Protected Circuits Location Rating 15A** PCM vehicle power 4 – ignition coil G8VA relay Fuel pump relay G8VA relay Intercooler pump relay (Shelby only) G8VA relay A/C compressor relay — Not used (spare) 5A** PCM run/start 5A** PCM vehicle power 3 –...
  • Page 239 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
  • Page 240 Roadside Emergencies A dissimilar spare tire/wheel is defined as a spare tire and/or wheel that is different in brand, size or appearance from the road tires and wheels and can be one of three types: 1. T-type mini-spare: This spare tire begins with the letter “T” for tire size and may have “Temporary Use Only”...
  • Page 241 Roadside Emergencies The usage of a full-size dissimilar spare tire/wheel can lead to impairment of the following: • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs • Winter weather driving capability • Wet weather driving capability •...
  • Page 242 Roadside Emergencies WARNING: If the vehicle slips off the jack, you or someone else could be seriously injured. WARNING: Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.
  • Page 243 Roadside Emergencies 3. Remove the center ornament (if equipped) from the wheel. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. 4. Put the jack in the jack notch next to the tire you are changing.

  • Page 244: Temporary Mobility Kit

    120 miles (200 km) at a maximum speed of 50 mph (80 km/h). Note: The temporary mobility kit sealant compound in the canister is to be used for one tire only. See your Ford authorized dealer for additional replacement sealant canisters. 2012 05+ Mustang (197)
  • Page 245 • Do not drive the vehicle above 50 mph (80 km/h). • Do not drive further than 120 miles (200 km). Drive only to the closest Ford Motor Company authorized dealer or tire repair shop to have your tire inspected.
  • Page 246 Always store the kit in its original location. • After sealant use, the TPMS sensor and valve stem on the wheel must be replaced by an authorized Ford dealer. • When inflating a tire or other objects, use the black air hose only. Do not use the transparent hose which is designed for sealant application only.
  • Page 247 Roadside Emergencies • Operating the temporary mobility kit could cause an electrical disturbance in radio and DVD player operation. What to do when a tire is punctured A tire puncture within the tire’s tread area can be repaired in two stages with the temporary mobility kit: •...
  • Page 248 Roadside Emergencies 4. Plug the power cable into the 12V power point in the vehicle. 5. Remove the warning sticker found on the canister and place it on the top of the instrument panel or the center of the dash. 6.
  • Page 249 Roadside Emergencies Note: When the sealing compound is first added into the tire, the air pressure gauge reading on the compressor unit may indicate a higher value; this is normal and should be no reason for concern. The pressure will drop after about 30 seconds of operation. The tire pressure has to be checked with the compressor in the OFF position to get the correct tire pressure reading.
  • Page 250 After using the temporary mobility kit to seal your tire, you will need to replace the sealant canister and clear tube (hose). Sealing compound and spare parts can be obtained and replaced at an authorized Ford Motor Company dealership or tire dealer. Empty sealant bottles may be disposed of at home;...
  • Page 251 Roadside Emergencies Removal of the sealant canister from the temporary mobility kit 1. Unwrap the clear tube from the compressor housing. 2. Locate the yellow cap at the end of the clear tube. 3. Using the yellow cap tool, press the tab located on the temporary mobility kit compressor housing while pulling up on the sealant...
  • Page 252 3. Wrap the clear tube around the compressor housing. Note: If you experience any difficulties with the removal or installation of the sealant canister, consult your Ford Motor Company authorized dealer for assistance. 2012 05+ Mustang (197) Owners Guide, 1st Printing...

  • Page 253: Wheel Lug Nut Torque

    20 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. WARNING: When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.

  • Page 254: Jump Starting

    Roadside Emergencies RUNNING OUT OF FUEL If you have run out of fuel and need to refill the vehicle with a portable fuel container, see Running out of fuel in the Maintenance and Specifications chapter for proper fuel filling method using a portable fuel container and the included fuel filler funnel.
  • Page 255 Roadside Emergencies 3. Park the booster vehicle close to the hood of the disabled vehicle making sure the two vehicles do not touch. Set the parking brake on both vehicles and stay clear of the engine cooling fan and other moving parts.
  • Page 256 Roadside Emergencies Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts. Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2.

  • Page 257: Wrecker Towing

    It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If your vehicle is to be towed from the front using wheel lift equipment, it is recommended that the rear wheels (drive wheels) be placed on a dolly to prevent damage to the transmission.
  • Page 258 Roadside Emergencies Emergency towing In case of a roadside emergency with a disabled vehicle (without access to wheel dollies, car hauling trailer, or flatbed transport vehicle) your vehicle (regardless of transmission powertrain configuration) can be flat towed (all wheels on the ground) under the following conditions: •...

  • Page 259: Customer Assistance

    A reasonable time must be allowed to perform a repair after taking your vehicle to the authorized dealer. Repairs will be made using Ford or Motorcraft parts, or remanufactured or other parts that are authorized by Ford.
  • Page 260 • The name of the authorized dealer and city where located • The vehicle’s current odometer reading In some states, you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states.
  • Page 261 In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the following address: Ford Motor Company 16800 Executive Plaza Drive Mail Drop 3NE-B Dearborn, MI 48126...
  • Page 262 THE BETTER BUSINESS BUREAU (BBB) AUTO LINE PROGRAM (U.S. ONLY) Your satisfaction is important to Ford Motor Company and to your dealer. If a warranty concern has not been resolved using the three-step procedure outlined on the first page of the Customer Assistance section, you may be eligible to participate in the BBB AUTO LINE program.
  • Page 263 (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
  • Page 264 The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
  • Page 265 If you buy your vehicle in North America and then relocate to any of the above locations, register your vehicle identification number (VIN) and new address with Ford Motor Company Export Operations & Global Growth Initiatives by emailing expcac@ford.com. If you are in another foreign country, contact the nearest authorized dealer.

  • Page 266: Reporting Safety Defects (U.s. Only)

    However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153);...

  • Page 267: Cleaning

    Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
  • Page 268 Cleaning WAXING • Wash the vehicle first. • Use a quality wax that does not contain abrasives. • Do not allow paint sealant to come in contact with any non-body (low-gloss black) colored trim, such as grained door handles, roof racks, bumpers, side moldings, mirror housings or the windshield cowl area.
  • Page 269 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
  • Page 270 Cleaning 3.7L V6 ENGINE 5.0L V8 ENGINE 2012 05+ Mustang (197) Owners Guide, 1st Printing USA (fus)
  • Page 271 Cleaning PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3-A). • If tar or grease spots are present, use Motorcraft Bug and Tar Remover (ZC-42).
  • Page 272 Cleaning For cloth tops wash with a high quality convertible top cleaner/protectant. • Do not use stiff bristle brushes or abrasive materials or cleaners. • Hot waxes applied by commercial car washes can affect the cleanability of vinyl material. • Using high water pressure or wand-type car washes against the convertible top and windows may cause water leaks and possible seal damage.
  • Page 273 Cleaning 4. Remove the soaked cloth, and if it is not soiled badly, use this cloth to clean the area by using a rubbing motion for 60 seconds. 5. Following this, wipe area dry with a clean, white, cotton cloth. INTERIOR For fabric, carpets, cloth seats, safety belts and seats equipped with side airbags:...
  • Page 274 FORD AND LINCOLN CAR CARE PRODUCTS Your Ford or Lincoln authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...

  • Page 275: Maintenance And Specifications

    Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide to find out which parts and services are covered.
  • Page 276 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located on the driver’s side kick panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood.

  • Page 277: Engine Compartment

    Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.7L V6 engine 1. Battery 2. Engine oil dipstick 3. Engine oil filler cap 4. Brake fluid reservoir 5. Air filter assembly 6. Engine coolant reservoir 7. Windshield washer fluid reservoir 8.
  • Page 278 Maintenance and Specifications 5.0L V8 engine 1. Battery 2. Engine oil filler cap 3. Engine oil dipstick 4. Brake fluid reservoir 5. Air filter assembly 6. Engine coolant reservoir 7. Windshield washer fluid reservoir 8. Power distribution box 2012 05+ Mustang (197) Owners Guide, 1st Printing USA (fus)
  • Page 279 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specifications. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
