Lab.gruppen C 68:4 Operation Manual page 31

Common values for all C Series amplifiers
Performance with Gain: 35dB and VPL: 141V
THD 20 Hz - 20kHz for 1W
THD at 1kHz and 1dB below clipping
Signal To Noise Ratio
Channel separation (Crosstalk) at 1kHz
Frequency response (1 W into 8 Ohm) +0/-3dB
Voltage Peak Limiter (VPL), max. peak output
VPL, selectable per ch. (V) 3)
VPL, when bridged (V)
3), 1)
Voltage Peak Limiter mode (per ch.)
Gain and level
Amplifier gain selectable (all channels)
Default gain
Level adjustment (per ch.)
General
Input connectors (per ch.)
Output connectors (per ch.)
Output bridge mode
NomadLink network
Intelligent fans (on/off)
Power on/off and Remote enable on/off
Cooling
front panel indicators:
Common
Per channel
Power
Operating voltage, 230 V / 115 V nominal
Minimum power-up voltage, 230 V / 115 V
Power Average Limiter
2)
Soft start / Inrush power
dimensions (W/h/d)
Weight
finish
Approvals
0.1%
0.05%
112 dBA
70 dB
6.8 Hz - 34 kHz
141, 118, 100, 85, 71, 59, 50, 42 V
282, 236, 200, 170, 142, 118, 100, 84 V
Hard / Soft
Rear panel switches: 23, 26, 29, 32, 35, 38, 41, 44 dB
1)
35dB
Front panel pot, 21 position detent -inf to 0 dB, .
hidden behind security panel/dust filter grille
3-pin Phoenix, electronically balanced
Barrier strip 2-pole screw terminals
A+B and/or C+D, inputs A and C are signal source
On board, 2 x RJ45 EtherCon connectors, IN and OUT
Depending on presence of output signal
Individual switches on front panel
Two fans, front to back airflow, temperature controlled speed
NomadLink
Signal present / High impedance; -10 dB and -4 dB output signal;
Voltage Peak Limiter (VPL); Current Peak Limiter (CPL): Very High
Frequency (VHF); High temperature; Fault; Mute
130-265 V / 65-135 V
5)
171 V / 85 V
Yes
Yes / max. 5A
W: 483 mm (19"), H: 88 mm (2 U), D: 343 mm (13.5")
12 kg (26.4 lbs.)
Black painted steel chassis with gray painted steel front
CE 230V, ETL 115V/230V, FCC
TEChNICAL sPECIFICATIONs 9
Network; Power Average Limiter (PAL™)
®
; Power on
2)
C Series Operation Manual 31
