Rear Scuff Plate Removal (Driver’s Side) - Mazda CX-5 Installation Instructions Manual

Tab D
Tab B
Tab D
Tab A
Rear scuff plate
Hook B
(1)
(2)
Vehicle front
Hook B
Tab A
3. Take the shaded area shown in the figure, detach tabs A while
4. Take the shaded area shown in the figure, detach tabs D while
Tab A
Tab A
Rear scuff plate removal (Driver's side)
1. Take the shaded area shown in the figure, detach tab A while
2. Take the shaded area shown in the figure, detach tab E while
(4) (3)
Hook F
Hook F
pulling the trunk end trim in the direction of the arrow (1) shown
in the figure, then detach clips B, pins C while pulling in the
direction of the arrow (2).
pulling the trunk end trim in the direction of the arrow (3) shown
in the figure, then detach clips E, pins F while pulling in the
direction of the arrow (4).
pulling the rear scuff plate in the direction of the arrow (1)
shown in the figure, then detach hook B, clips C, pins D while
pulling in the direction of the arrow (2).
pulling the rear scuff plate in the direction of the arrow (3)
shown in the figure, then detach the hook F while pulling in the
direction of the arrow (4).
10
