Connecting the FM and AM
If FM reception is poor,
connect an outdoor FM antenna
(not supplied).
FM Antenna (supplied)
FM antenna connection
1. Connect the FM antenna supplied to the FM 75
COAXIAL terminal as temporary measure.
2. Slowly move the antenna wire around until you
find a location where reception is good, then
fasten it to a wall or other rigid surface.
• If reception is poor, connect an outdoor antenna.
Before attaching a 75 coaxial cable (with a standard
type connector), disconnect the supplied FM antenna.
(About the cooling fan)
A cooling fan is mounted on the rear panel of the center unit to
prevent abnormal temperature inside the center unit, thus assuring
normal operation. The cooling fan automatically starts rotating to
supply external cool air to the inside of the center unit when the
internal temperature exceeds the specified limit.
13
Downloaded From TheatreSystem-Manual.com Manuals
Antennas
( MW/LW )
1 2 3
If AM reception is
poor, connect an
outdoor AM
antenna(not
supplied).
AM Loop Antenna
ANTENNA
Snap the tabs on the loop into the
slots of the base to assemble the
AM loop antenna.
Cooling fan (See "About Cooling Fan" below.)
AM antenna connection
(MW/LW)
1. Connect the AM loop antenna supplied
to the AM and terminals.
2. If reception is poor, connect an outdoor
single vinyl-covered wire to the AM
terminal. (Keep the AM loop antenna
connected).
For safety, observe the following carefully.
• Make sure there is good ventilation around the center unit. Poor
ventilation could overheat and cause damage.
• DO NOT block the cooling fan and the ventilation openings or
holes. (If they are blocked by a newspaper or cloth, etc., the heat
may not be able to escape.)
External Digital
Components
Example: CD recorders, MD (Mini Disc) D/A
(supplied)
Audio Cable (Red/White)
If the external analog
component has only one
output jack, you may connect
To Play External Digital/Analog Equipment
Press AUX on the remote control to select DIGITAL IN, AUX1, or AUX2.
Press Function on the main unit to select DIGITAL IN, AUX1, or AUX2.
•
Each time the button is pressed the mode switches as follows: FM
DIGITAL IN

AUX Connections

For connection to external
equipment with digital output.
converters or other components equipped
with digital output jacks
DIGITAL OUT
(not supplied)
Optical Cable
either L or R.
External Analog
Components
R L
Connect to external equipment with
analog output.
Example: Video, TV, etc.
AUX 1 AUX 2.
TV
To view pictures from
external input (AUX 1 ,
AUX 2 ), first connect the
VIDEO IN jack (AUX 1 ,
VIDEO IN
AUX 2 ) and then connect
the VIDEO OUT jack.
Video Cable
VIDEO OUT
•
Always connect the video and
audio connection cables to the
equivalent colored jack.
