Extron electronics MPX 423 A Quick Manual

MPX 423 A
Media Presentation Matrix switcher
The Extron MPX 423 A is a media presentation matrix switcher that combines
three independent matrix switchers in a single, compact enclosure: a 4x2 VGA
switcher, a 4x2 S-video switcher, and a 4x2 composite video switcher. It is ideal for
a variety of applications including classrooms, training and conference facilities,
and residential entertainment systems.
Matrix SwitcherS
Three matrix switchers in one
n
enclosure:
– 4x2 VGA and stereo
audio switcher
– 4x2 S-video and stereo
audio switcher
– 4x2 composite video and
stereo audio switcher
350 MHz (-3 dB) RGB
n
video bandwidth
150 MHz (-3 dB) video bandwidth
n
Two operating modes: Single
n
Switcher or Separate Switcher
Digital Sync Validation
n
Processing (DSVP )
™
RGB mute
n
Input audio gain and attenuation
n
Audio output volume control
n
Audio breakaway
n
RS-232 control
n
IP Link Ethernet control
™
n
Internal international power supply
n
