A qualified service technician should do the installation of the internal Hard Disk Drive.
We can't get responsible for damages caused by incorrect installation.
Installation Manual
Internal Hard Disk
KORG TRITON
Contents:
1.
2.
3.
4.
First test and formatting the Hard Disk
5.
New installation of the KORG SCSI
Board
6.
SCSI-ID change
7.
Assemble the KORG Triton Keyboard
ATTENTION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Triton and is the answer not in the manual?

Questions and answers

Related Manuals for Korg Triton

Summary of Contents for Korg Triton

  • Page 1 Installation Manual Internal Hard Disk KORG TRITON Contents: General Open the KORG Triton Keyboard Installation of the Hard Disk Board First test and formatting the Hard Disk New installation of the KORG SCSI Board SCSI-ID change Assemble the KORG Triton Keyboard ©...
  • Page 2 TRITON HD Manual Content of the Triton internal HD: • Triton HD Board with SCSI to IDE converter and hard disk • 1m flat cable with 25 pin connectors • Plastic bag 1, mounting material for the Triton HD Board •...
  • Page 3 In plastic bag 2 there are two metal plates. Fasten the two metal plates with the added screws on the metal angle. (See figure 2). Screw the two metal distant screws in the free holes of the KORG Triton. Now mount the metal pieces Inside your Triton.
  • Page 4 MOSS Board. 6. SCSI ID change Before you reassemble the KORG Triton you should think about the SCSI ID of your Hard Disk. We have set the SCSI ID to ID1 but with the added jumpers you can change The table shows the jumper position and the assigned SCSI-ID:...
