Summary of Contents for Optoma Projector

  • Page 1: Table Of Contents

    Powering Off the projector ................... 14 Warning Indicator ....................14 Adjusting the Projected Image..............15 Adjusting the Projector’s Height ................15 Adjusting the Projector’s Zoom / Focus ............... 16 Adjusting Projected Image Size ................16 User Controls ..................17 Control Panel & Remote Control ..............17 Control Panel .......................

  • Page 2: Usage Notice

    As an example, do not place the projector on a crowded coffee table, sofa, bed, etc. Do not put the projector in an enclosure such as a book case or a cabinet that restricts air flow.

  • Page 3: Precautions

    ▀■ Warning- Do not look into the projector’s lens when the lamp is on. The bright light may hurt your eyes. ▀■ Warning- To reduce the risk of fire or electric shock, do not expose this projector to rain or moisture.
  • Page 4 Usage Notice  Turn off and unplug the power plug from the AC outlet before cleaning the product.  Use a soft dry cloth with mild detergent to clean the display housing.  Disconnect the power plug from AC outlet if the product is not being used for a long period of time.

  • Page 5: Eye Safety Warnings

    Usage Notice Eye Safety Warnings ▀■ Avoid staring/facing directly into the projector beam at all times. Keep your back to the beam as much as possible. ▀■ When projector is used in a classroom, adequately supervise students when they are asked to point out something on the screen.

  • Page 6: Introduction

    Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact your nearest customer service center. Power Cord 1.8m Projector with lens cap Lamp  Due to different applications in each country, 2 ×...

  • Page 7: Product Overview

    Introduction Product Overview Main Unit 1. Control Panel 6. Tilt-Adjustment Feet 2. Zoom Ring 7. Security Bar 3. Focus Ring 8. Input / Output 4. Zoom Lens Connections 5. IR Receiver 9. Power Socket...

  • Page 8: Control Panel

    Introduction Control Panel 1. Source 2. Menu 3. Enter 4. Re-Sync 5. Power 6. Four Directional Select Keys 7. On/Standby LED 8. Lamp Fail LED 9. Temp LED 10. IR Receiver...

  • Page 9: Input / Output Connections

    8. Power Socket Not a power 9. Kensington Lock Port supplier port. 10. Security Bar “12V OUT” is  activated when the projector is turned on and continues to stay on till you turn off the projector.

  • Page 10: Remote Control

    Installation Remote Control 1. Power On 2. Power Off Lamp 3. 16:9 4. Native 5. Contrast 6. Overscan 7. Enter 8. Re-Sync 9. D-Sub Source 10. Video Source 11. HDMI 2 Source 12. YPbPr Source 13. HDMI 1 Source 14. Menu 15.

  • Page 11: Installation

    Installation Connecting the Projector Connect to Computer/Notebook MOLEX  “12V OUT” is only + 12V Output for trigger control. Not a power supplier port.  “12V OUT” is activated when the projector is turned on and continues to stay on till you turn off VIDEO the projector.

  • Page 12: Connect To Video Sources

    VIDEO  “12V OUT” is SERVICE VGA/SCART/YPbPr 12V OUT activated when HDMI 1 HDMI 2 the projector is turned on and continues to stay on till you turn off the projector. DVD Player, Set-top Box, Composite Video Output HDTV receiver  Due to the...

  • Page 13: Powering On/Off The Projector

    The ON/STANDBY LED will now turn Green.  The startup screen will display in approximately 10 seconds. The first time you use the projector, you can select your preferred language from quick menu after the startup screen displays.

  • Page 14: Powering Off The Projector

    Green. When the ON/STANDBY LED lights solid Amber, the projector has entered standby mode. If you wish to turn the projector back on, you must wait until the projector has completed the cooling cycle and has entered standby mode. Once in standby mode, simply press “...

  • Page 15: Adjusting The Projected Image

    1. Locate the adjustable foot you wish to modify on the underside of the projector. 2. Rotate the adjustable ring counter clockwise to raise the projector or clockwise to lower it. Repeat with the remaining feet as needed. Tilt-Adjustment Feet...

  • Page 16: Adjusting Projection Image Size

    You may turn the zoom ring to zoom in or out. To focus the im- age, rotate the focus ring until the image is clear. The projector will focus at distances from 4.89 to 32.68 feet (1.49 to 9.96 meters).

  • Page 17: User Controls

    There are two ways for you to control the functions: Control Panel and Remote Control. Control Panel Using the Control Panel Refer to the “Power On/Off the Projector” section on Power pages 13-14. Automatically synchronize the projector to the input RE-SYNC source.

  • Page 18: Remote Control

    User Controls Remote Control Using the Remote Control Power On Refer to the “Power On” section on page 13. Refer to the “Power On/Off the Projector” Lamp Power Off section on page 14. Increase the brightness of the image. (refer...

  • Page 19: Four Directional Select Keys

    Using the Remote Control Enter Confirm your item selection. Lamp Source Press “Source” to select an input signal. Automatically synchronizes the projector Re-sync to the input source. Display or exit the on-screen display Menu menus for projector. Press “HDMI 1” to choose source from HDMI 1 HDMI 1 connector.

  • Page 20: On-Screen Display Menus

    User Controls On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. How to operate To open the OSD menu, press “Menu” on the Remote Control or Projector Keypad.

  • Page 21: Menu Tree

    User Controls Menu Tree ) “B/W Extension”  can’t support when source is HDMI, analog or digital Automatic/Phase/Tracking/H.Position/V.Position RGB via DVI port. Video (*) “Signal” is not  supported when the source is HDMI or DVI-D. (**) “IRE” is only ...
  • Page 22 User Controls IMAGE Mode There are many factory presets optimized for various types of images. Cinema: For home theater.  Bright: Maximum brightness input.  Photo: Optimized for displaying photographic images.  Reference: This mode is intended to reproduce, as close as ...
  • Page 23 User Controls IMAGE Color Adjust a video image from black and white to fully saturated color. Press the to decrease the color saturation in the image.  Press the to increase the color saturation in the image.  Tint Adjust the color balance of red and green. Press the to increase the amount of green in the image.

  • Page 24: Image

    User Controls IMAGE | Advanced Noise Reduction The motion Adaptive Noise Reduction reduces the amount of visible noise interlaced signals. The range is from “0” to “10”. (0: Off) B/W Extension Black and White Extension can stretch the black and white levels “B/W Extension”...
  • Page 25 User Controls IMAGE | Advanced Gamma This allows you to set up gamma curve type. After the initial setup and fine tuning is completed, utilize the Gamma Adjustment steps to optimize your image output. Film: for home theater.  Video: for video or TV source. ...

  • Page 26: Display

    User Controls DISPLAY Format Use this function to choose your desired aspect ratio. 4:3: This format is for 4x3 input sources.  16:9: This format is for 16x9 input sources, like HDTV and DVD  enhanced for Widescreen TV. Native: This format displays the original image without any ...
  • Page 27 User Controls Detail informations about LBX mode : 1. Some Letter-Box DVDs are not enhanced for 16x9 TVs. In this situation, the image will not look right when displayed in 16:9 mode. In this situation, please try to using the 4:3 mode to view the DVD.
  • Page 28 User Controls DISPLAY Overscan Overscan function removes the noise in a video image. Overscan Each I/O has  the image to remove video encoding noise on the edge of video different setting of source. “Overscan”. Edge Mask “Overscan” and  Press the to reduce the size of an image.
  • Page 29 Auto: To solve the differences of the film formats, the option can  keep the format in the same ratio. How to use “SuperWide” 1. Obtain a 2.0:1 aspect ratio screen 2. Switch SuperWide ON 3. Align the projector image correctly on the screen 4. Enjoy movies without black bars...

  • Page 30: System

    User Controls SYSTEM Menu Location Choose the menu location on the display screen. Projection Front-Projection  This is the default selection. The image is projected straight on the screen. Rear-Desktop  When selected, the image will appear reversed. Rear-Desktop  Front-Ceiling ...
  • Page 31 User Controls SYSTEM Image AI Image AI improves the contrast of the picture by optimizing the brightness of the lamp according to the picture content. On: The dynamic image performance manager is active in  making sure your greatest pleasure from seeing a movie dynamically with the most dark details revealed, vivid and bright image performed all the way.

  • Page 32: Test Pattern

     “12V OUT” is only for trigger control. 12V trigger provides a standard trigger for motorized screens. Not a power supplier port.  “12V OUT” is activated when the projector is turned on and continues to stay on till you turn off the projector.

  • Page 33: Lamp Settings

    User Controls SYSTEM | Lamp Settings Lamp Hour Display the cumulative lamp operating time. Lamp Reminder Choose this function to show or to hide the warning message when the changing lamp message is displayed. The message will appear up 30 hours before suggested replacement of lamp. Bright Mode Choose “On”...

  • Page 34: Setup

    Input Source Use this option to enable / disable input sources. Press to enter the sub menu and select which sources you require. Press “Enter” to finalize the selection. The projector will not search for inputs that are not selected.
  • Page 35 User Controls SETUP Source Lock When this function is turned off, the projector will search for other signals if the current input signal is lost. When this function is turned on, it will search for a specified connection port. High Altitude Choose “On”...
  • Page 36 Signal is not automatic, the phase, frequency source is HDMI or items will appear for user to manually tune and DVI-D. saved in settings after that for next time projector turns off and on again. Phase: Change the display data frequency to match the ...

  • Page 37: Video Source

    User Controls SETUP | Signal Video Source Signal White Level: Allow user adjust White Level when inputting  “Signal” is not  S-Video or Video/CVBS signals. supported when the Black Level: Allow user adjust Black Level when inputting  source is HDMI or S-Video or Video/CVBS signals.

  • Page 38: Appendices

     Check if the projection lamp has been securely installed. Please  refer to the “Replacing the lamp” section. Make sure you have removed the lens cap and the projector is  switched on. Image is out of focus Make sure the lens cap is removed.

  • Page 39: Other Problems

    Other Problems The projector stops responding to all controls If possible, turn off the projector, then unplug the power cord and  wait at least 60 seconds before reconnecting power. Lamp burns out or makes a popping sound When the lamp reaches its end of life, it will burn out and may ...

  • Page 40: Projector Status Indication

    Appendices Projector Status Indication LED lighting message ON/STANDBY Temp-LED Lamp-LED Message (Green/Amber) (Red) (Red) Standby State Amber (Input power cord) Flashing Power on (Warming) Green Lamp lighting Green Steady light  No light  Flashing Power off (Cooling) Green Flashing Error (Over Temp.)

  • Page 41: Remote Control Problems

    IR receivers on the projector. Make sure there are not any obstructions between the remote  control and the projector. Move to within 8 m of the projector. Make sure the batteries are inserted correctly.  Replace batteries if they are exhausted.

  • Page 42: Replacing The Lamp

    When you see this message, please contact your local reseller or service center to change the lamp as soon as possible. Make sure the projector has been cooled down for at least 30 minutes before changing the lamp. Warning: If ceiling mounted, please use caution when opening the lamp access panel.

  • Page 43: Lamp Replacement Procedure

    Lamp Replacement Procedure: 1. Switch off the power to the projector by pressing the “ ” button. 2. Allow the projector to cool down for at least 30 minutes. 3. Disconnect the power cord. 4. Unscrew the two screws on the cover. 1 5.

  • Page 44: Compatibility Modes

    Appendices Compatibility Modes Computer Compatibility  V.Frequency Mode Resolution AAnalog Digital (Hz) 800 x 600   800 x 600   SVGA 800 x 600   800 x 600   800 x 600   1024 x 768 ...
  • Page 45 Appendices Video Compatibility  NTSC M (3.58MHz), 4.43 MHz B, D, G, H, I, M, N SECAM B, D, G, K, K1, L SDTV/HDTV 480i/p, 576i/p, 720p@50Hz/60Hz, 1080i/p@50Hz/60Hz...

  • Page 46: Ceiling Mount Installation

    1. To prevent damage to your projector, please use the Optoma ceiling mount. 2. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: Screw type: M3*3 ...

  • Page 47: Optoma Global Offices

    Appendices Optoma Global Offices For service or support please contact your local office. 715 Sycamore Drive 408-383-3700 Milpitas, CA 95035, USA 408-383-3702 www.optomausa.com services@optoma.com Canada 5630 Kennedy Road, Mississauga, 905-361-2582 ON, L4Z 2A9, Canada 905-361-2581 www.optoma.ca canadacsragent@optoma.com Europe 42 Caxton Way, The Watford Business Park...
  • Page 48 Appendices Latin America 715 Sycamore Drive 408-383-3700 Milpitas, CA 95035, USA 408-383-3702 www.optoma.com.br www.optoma.com.mx Korea WOOMI TECH.CO.,LTD. 4F,Minu Bldg.33-14, Kangnam-Ku, +82+2+34430004 seoul,135-815, KOREA +82+2+34430005 Japan 東京都足立区綾瀬3-25-18 info@osscreen.com 株式会社オーエスエム 0120-46-5040 www.os-worldwide.com サポートセンター: Taiwan 5F., No. 108, Minchiuan Rd. +886-2-2218-2360 Shindian City, +886-2-2218-2313 Taipei Taiwan 231, R.O.C.

  • Page 49: Fcc Notice

    Appendices Regulation & Safety notices This appendix lists the general notices of your projector. FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules.

  • Page 50: Operation Conditions

    Appendices Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation.
