EchoLife BM625 WiMAX CPE
Quick Start

Advertisement

loading

  Summary of Contents for Huawei EchoLife BM625 WiMAX CPE

  • Page 1 EchoLife BM625 WiMAX CPE Quick Start...
  • Page 3 Thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation.
  • Page 4 HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS. Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and will...
  • Page 5: Table Of Contents

    Contents Before you begin......................... 1 Getting to Know Your CPE ......................1 Preparing for Installation......................4 Logging In to the Web-Based Utility ..................6 Troubleshooting .......................... 8 Specifications ..........................10 Warnings and Precautions ....................... 11...
  • Page 7: Before You Begin

    Thank you for purchasing WiMAX CPE! Before you begin Check the following items in the product package. If you find anything missing or damaged, contact the service provider. WiMAX CPE Dedicated Power Adapter Ethernet Cable Quick Start Qualification Card Getting to Know Your CPE The supported functions and actual appearance of the CPE may vary with the product you purchase.
  • Page 8: Rear Panel

    Indicator Status Description WiMAX The indicators indicate the signal strength of the WiMAX network. When all the indicators are on, it indicates that the signal strength is at the highest level. Blink The CPE is being upgraded when they blink sequentially.
  • Page 9: Side Panel

    Interface/Indicator Description POWER The interface is used to connect to the output interface of the power adapter. The interfaces are used to connect the CPE to the computer or the switch. The indicators are used to indicate the status of the devices connected to the corresponding interfaces.
  • Page 10: Preparing For Installation

    Preparing for Installation Selecting a Proper Installation Position Obstacles such as concrete or wooden walls may affect the transmission of WiMAX network signals. Therefore, install the CPE in an open space. Keep the CPE away from any household appliance that produces a strong electric or magnetic field, such as a microwave oven, a refrigerator, or a satellite dish antenna.
  • Page 11 TEL1 TEL2 POWER LAN2 LAN3 LAN4 LAN1 LAN1 LAN3 LAN2 LAN4 1 Power adapter 2 Computer 3 Set top box 4 Switch 5 Electrograph 6 Telephone Use the cables and the power adapter provided with the product. The cable connection figure is provided for illustration purpose. You can connect the devices to the CPE according to the actual requirements.
  • Page 12: Logging In To The Web-Based Utility

    During lightning storms, stop using the external antenna, and disconnect it from the CPE. Two external antennas can be connected to the CPE at a time. If only one antenna is connected, connect it to the main antenna interface labeled with .
  • Page 13 After the user name and the password are verified, you can perform operations on the Web-based utility. For details about the settings of advanced parameters, see the online help in the Web-based utility. To read the online help, you need to install the Adobe Reader 6.0 or later versions.
  • Page 14: Troubleshooting

    Troubleshooting The power indicator is not on. Ensure that the device is powered on. Ensure that the power adapter is compatible with the device. You cannot make calls. Ensure that the telephone is working normally and the telephone line is connected properly.
  • Page 15 dish antenna. If the problem persists, contact the local service provider. The device or the power adapter overheats. The device may get heated after being used for a long time. Therefore, power off the device when you do not use the device. Place the device in a well-ventilated place and do not expose the device to direct sunlight.
  • Page 16: Specifications

    Specifications WiMAX Parameters Standard IEEE 802.16e-2005 Frequency 2.496–2.69 GHz Port Four Fast Ethernet (FE) interfaces Two Plain Old Telephone Service (POTS) interfaces Other Parameters Power adapter input 100–240V AC Power consumption 12 W Power supply to device 12V, 2A Operating temperature 0˚C to 40˚C (32˚F to 104˚F) Operating humidity 5% to 95%, non-condensing...
  • Page 17: Warnings And Precautions

    Warnings and Precautions To use the device properly and safely, read these warnings and precautions carefully and strictly observe them during operation. Note: Unless otherwise specified, the device described in this section includes the device and its accessories. Basic Requirements During storage, transportation, and operation of the device, keep it dry and prevent it from colliding with other objects.
  • Page 18 Do not block the openings on the device with any object. Reserve a minimum space of 10 cm around the device for heat dissipation. Do not place any object (such as a candle or a water container) on the device. If any foreign object or liquid enters the device, stop using the device immediately, power it off, remove all the cables connected to it, and then contact an authorized service center.
  • Page 19 and regulations related to telecommunications terminals may become null and void, or an injury may occur. Do not use the power adapter if its cable is damaged. Otherwise, electric shocks or fires may occur. Ensure that the power adapter meets the specifications indicated on the device nameplate.
  • Page 20 The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. Български: С настоящето Huawei Technologies Co., Ltd. декларира, че този уред съответства на основните изисквания и другите разпоредби на Директива...
  • Page 21 Česky: Huawei Technologies Co., Ltd., tímto prohlašuje, že toto zařízení je ve shodě se základními požadavky a dalšími souvisejícími opatřeními směrnice 1999/5/EC. Dansk: Huawei Technologies Co., Ltd. erklærer hermed at denne enhed er i overensstemmelse med de obligatoriske krav og andre relevante bestemmelser i direktiv 1999/5/EF.
  • Page 22 è conforme ai requisiti essenziali e alle altre disposizioni applicabili della Direttiva 1999/5/CE. Latviski: Ar šo Huawei Technologies Co., Ltd. paziņo, ka šī ierīce atbilst Direktīvas 1999/5/EC pamatprasībām un piemērojamajiem nosacījumiem. Lietuviškai: Šiuo Huawei Technologies Co., Ltd. praneša, kad šis įtaisas atitinka Direktyvos 1999/5/EC pagrindinius reikalavimus ir taikomas sąlygas.
  • Page 23 Notice: Observe the national local regulations in the location where the device is to be used. This device may be restricted for use in some or all countries of European Union. Issue: 02(2009-11-20) Part Number: 00392282...
  • Page 24 Huawei Technologies Co., Ltd Huawei Industrial Base, Bantian, Longgang Shenzhen 518129 People’s Republic of China www.huawei.com...
