Summary of Contents for SCHOLTES SH06GGMAB
-
Page 1: Table Of Contents
Description of the appliance, 7 Overall view Start-up and use, 8 Practical advice on using the burners Precautions and tips, 9 General safety SH06GGMAB Disposal SH07GGMAB Maintenance and care, 10 Switching the appliance off Cleaning the appliance Gas tap maintenance... -
Page 2: Installation
Installation Before operating your new appliance please read this also be equipped with vents to allow gas to escape in instruction booklet carefully. It contains important information the event of a leak. As a result LPG cylinders, whether for safe use, installation and care of the appliance. partially or completely full, must not be installed or stored in rooms or storage areas that are below ground Please keep these operating instructions for future... -
Page 3: Gas Connection
Back appliance. There is an adjustable L-shaped pipe fitting on the appliance supply ramp and this is fitted with a seal in order to prevent leaks. The seal must always be replaced after rotating the pipe fitting (seal provided with appliance). -
Page 4: Data Plate
4. Some appliances have a safety device (thermocouple) fitted. If the device fails to work when the burners are set to the low flame setting, increase this low flame setting using the adjusting screw. 5. Once the adjustment has been made, replace the seals on the by-passes using sealing wax or a similar substance. -
Page 5: Burner And Nozzle Specifications
Butane P.C.S. = 49.47 MJ/Kg Propane P.C.S. = 50.37 MJ/Kg Natural P.C.S. = 37.78 MJ/m SH06GGMAB SH07GGMAB The hob can only be installed above built-in ovens with a cooling ventilation system. Main frequency and voltage of the electrical section and characteristics of the gas section... -
Page 6: Electrical Connection
Electrical Connection Power supply voltage and frequency: 220-240V a.c. Disposing of the plug 50/60Hz. Ensure that before disposing of the plug itself, you make the pins unusable so that it cannot be accidentally inserted into a socket. Instructions for The supply cable must be positioned so that it never reaches at any point a temperature 50°C connecting cable to an alternative plug: higher than the room temperature. -
Page 7: Description Of The Appliance
Description of the appliance Overall view GAS BURNERS Support Grid for COOKWARE Control Knobs for GAS BURNERS and ELECTRIC HOTPLATE* Support Grid for COOKWARE GAS BURNERS Control Knobs for GAS BURNERS SAFETY DEVICES * Ignition for GAS BURNERS * • GAS BURNERS differ in size and power. Use the •... -
Page 8: Start-Up And Use
Start-up and use The position of the corresponding gas burner or Each burner can be adjusted using the control knob electric hotplate* is shown on every knob. as follows: • Gas burners On and inner ring set to maximum Each burner can be adjusted to one of the following settings using the corresponding control knob: Inner ring set to minimum •... -
Page 9: Precautions And Tips
Precautions and tips This appliance has been designed and • Do not close the glass cover (if present) when the manufactured in compliance with international safety gas burners or electric hotplates are still hot. standards. The following warnings are provided for •... -
Page 10: Maintenance And Care
Maintenance and care Switching the appliance off Disconnect your appliance from the electricity supply before carrying out any work on it. Cleaning the appliance Do not use abrasive or corrosive detergents such as stain removers, anti-rust products, powder detergents or sponges with abrasive surfaces: these may scratch the surface beyond repair. -
Page 11: Troubleshooting
Troubleshooting It may happen that the appliance does not function properly or at all. Before calling the service centre for assistance, check if anything can be done. First, check to see that there are no interruptions in the gas and electrical supplies, and, in particular, that the gas valves for the mains are open. -
Page 12: After Sales Support
Telephone free on 0800 158 55 00 To help manage potential problems quickly and effectively Scholtès recommends registering all appliances. To register appliances, telephone free on 0800 158 55 00 or visit www.scholtes.co.uk. This guarantee is subject to the following conditions: •...
