enphase Gateway Quick Start Manual

ENPHASE QUICKSTART GUIDE
4 Easy Steps
1 2
1 2
BROADBAND ROUTER
LAN CABLE
980000000366- 980000000364-
980000000364- 980000000362- 980000000367-
REGISTER
1
Installers: Begin the activation process
• First-time installers: Go to enlighten.enphaseenergy.com/register and complete
the form. Your login credentials will be emailed to you.
• Self-installers: Click on the "Self-installed" checkbox.
• Existing installers: Log into Enlighten, click "Add New Activation" in the Installation
Status widget.
INSTALL
2
3
Install the PV modules and microinverters
Consult the microinverter installation manual for installation and commissioning
instructions.
3
CONNECT
3
Install the Envoy Communications Gateway
• Connect to a broadband router and plug into a dedicated wall outlet.
• Wait 15 minutes to allow the Envoy to start detecting the microinverters in your array.
• Ensure at least 2 level bars and the correct number of microinverters are showing
(see overleaf for troubleshooting).
05:00
LEVEL
Consult the Envoy installation manual for more details.
ASSIGN
4
Use the Array Builder to generate the array
• Once all microinverters have been detected, log in to Enlighten to
use the Enlighten Array Builder.
• For guidance on how to use the Array Builder, please visit
www.enphase.com/support/learningcenter.cfm
support@enphaseenergy.com
1 877 797 4743
+WEB
Devices: 15
Solar PV power systems should be
installed by qualified personnel.
