- Page 1 LED TV Installation manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Model Serial No. [HC890_ZA]Install_Guide_00ENG.indd 1 2014-04-02 1:39:03...
-
Page 2: Introduction
✎ When using a stand or wall-mount, use parts provided by Samsung Electronics only. If you use parts provided by another manufacturer, it may cause a problem with the product or cause the product to fall, leading to serioius injury. -
Page 3: Table Of Contents
Using the TV's Controller ............................6 y The Connection Panel ............................... 7 y The Remote Control ..............................9 y Using the Samsung Smart Control .......................... 11 y Connecting to the Network ............................. 16 y Connecting the TV to an SBB or STB ........................18 y Connecting the Bathroom Speakers ........................ -
Page 4: Accessories
Accessories ✎ Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer. ✎ The items’ color and shape may vary, depending on the model. ✎ The parts for the stand are listed under Stand Components on the following page. List of Parts SEARCH KEYPAD... -
Page 5: Installing The Led Tv Stand
Installing the LED TV Stand Stand Components When installing the stand, use the provided components and parts. A 1 EA x12 (M4 X L14) y Stand y Guide Stand y Bracket Stand y Screws ✎ Place a soft cloth over the table to protect the TV, and then place the TV on the cloth screen-side down. -
Page 6: Using The Tv's Controller
TV Controller The control stick is located on the lower- left corner of the back of the TV Remote control sensor When you use the Samsung Smart Control, the standby LED does not respond, except when you press the P button. -
Page 7: The Connection Panel
HDMI 1.2 version, contact to the Samsung customer care center. Refer to page 54 for the information of the Samsung customer care center. 3 LAN: Connect to a wired LAN using CAT 7 cable. - Page 8 COMPONENT IN / AV IN – Use to connect to Component video / audio devices such as DVD players and AV (Composite) devices such as VCRs. – Connect audio cables to "R-AUDIO-L" on your TV and the other ends to corresponding audio out jacks on A/V or Component devices.
-
Page 9: The Remote Control
The Remote Control ✎ This remote control has Braille points on the Power, Channel, and Volume buttons and can be used by visually impaired customers. Display and select the available video Turns the TV on and off. sources. Press to directly access channels. Press to select additional digital channels being broadcast by the same station. - Page 10 Installing batteries (Battery size: AAA) Match the polarity of the batteries to the symbols in the battery compartment. After you have installed the batteries, use a screwdriver to screw in the screw that holds the battery cover closed. NOTE ✎ •...
-
Page 11: Using The Samsung Smart Control
Adjusts the volume. M.SCREEN Touch pad Place a finger on the touch pad and move the Samsung Smart Control. The pointer on the screen moves in the direction you moved the Samsung Smart Control. Press the touch pad to run the focused item. - Page 12 You can also move the Samsung Smart Control in the same fashion to scroll scrollable screens up and down. – If you stop using the Motion Function, even momentarily, put your fi nger on the touch pad, and then move the Samsung Smart Control to re-start the function.
- Page 13 Using the Touch Pad and the Directional Buttons – In the TV's menu, navigate to Support > Smart Control Tutorial to view a tutorial that shows how to use the touch pad. – If the touch pad's sensitivity is too high or low, navigate to the System > Smart Control Settings menu, and then select the Touch Sensitivity option to change the touch pad sensitivity.
-
Page 14: The Low Battery Alarm Window
If the Samsung Smart Control stops operating or works abnormally, try replacing the batteries. If the problem persists, pair the Samsung Smart Control and TV again. 1. Move to within a foot of the TV, and then aim the Samsung Smart Control at the TV's remote control receiver. Remote Control Sensor 2. -
Page 15: Button Description
On-Screen Remote to enter numbers, control content playback, and use the features and functions of the TV, just like a real remote. Use the directional buttons on the Samsung Smart Control to move the cursor on the On-Screen Remote. Press the touch pad on the Samsung Smart Control to select. -
Page 16: Connecting To The Network
Authentication Modes: WEP, WPAPSK, WPA2PSK y Encryption Types: WEP, TKIP, AES In compliance with the newest Wi-Fi certification specifications, Samsung TVs do not support WEP or TKIP security encryption in networks running in the 802.11n mode. If the wireless router supports WPS (Wi-Fi Protected Setup), you can connect the TV to your network using PBC (Push Button Configuration) or a PIN (Personal Identification Number). - Page 17 Network Connection - Wired There are three main ways to connect your TV to your network using cable, depending on your network setup. They are illustrated below: TV Rear Panel The Modem Port on the Wall External Modem (ADSL / VDSL / Cable TV) Modem Cable (Not Supplied) LAN Cable (Not Supplied) TV Rear Panel...
-
Page 18: Connecting The Tv To An Sbb Or Stb
Connecting the TV to an SBB or STB TV Rear Panel ETH MODEM Data Cable 1. Connect the DATA jack of the TV to the ETH MODEM jack of the STB (SBB) with the Data cable. ✎ The "ETH MODEM" jack name that you connect the Data Cable to may differ depending on the SBB or STB type. English [HC890_ZA]Install_Guide_00ENG.indd 18 2014-04-02... - Page 19 Contact your nearest dealer or your SI Vendor to buy the data cable not included in the TV. Confirm the code on the Code Label Note the labeled end. Note the labeled end. SI Vendor Cable code Pin assign Remark Samsung BN39-00865B Provided Enseo Guest-Tek NXTV BN39-01011B nStreams BN39-01110A...
- Page 20 Connecting the Audio Output to an Audio Amplifier ¦ TV Rear Panel AUDIO IN Audio Amplifier 1 Stereo cable 1. Connect the AUDIO OUT port of the TV to the Audio In port of an audio amplifier with a stereo cable. English [HC890_ZA]Install_Guide_00ENG.indd 20 2014-04-02...
-
Page 21: Connecting The Bathroom Speakers
Connecting the Bathroom Speakers You can connect the Bathroom Speakers in the following manner. Connecting through the Variable Output (available without an external amplifier) ¦ TV Rear Panel Speaker VOL+ Volume Control Box VOL- 1. Connect the VARIABLE AUDIO OUT port of the TV to the Bathroom Wall Speakers of the hotel. -
Page 22: Connecting The Rjp (Remote Jack Pack)
TV to the HDMI port of the RJP. 4. Connect the EX-LINK port of the TV to the RS/232 port of the RJP. ✎ This Samsung TV is compatible with the TeleAdapt TA-7610 RJP only. English [HC890_ZA]Install_Guide_00ENG.indd 22 2014-04-02 1:39:20... - Page 23 y RJP (Remote Jack Pack): The RJP is a hardware module that has various Audio and Video inputs (A/V Video, A/V Audio, PC and HDMI) and corresponding outputs. The corresponding outputs are connected from the RJP to the TV. The RJP communicates with the TV via RS232.
-
Page 24: Setting The Hotel Option Data
→ ENTERE on your Samsung remote. After a menu appears, follow these general directions to navigate and change values: – Use the Up and Down arrow buttons on the Samsung remote to move from menu item to menu item. – Press the ENTER or Left or Right arrow buttons to select a menu item. -
Page 25: Menu Items
• Interactive mode : TV works with an SI STB or SBB. • Standalone mode : TV works alone, without an SI STB or SBB. • Interactive mode : Samsung / OCC / MTI / Nstreams / NXTV / Enseo / Cardi- SI Vendor... - Page 26 Hotel TV Function Description Category Item initial value Picture Menu Lock Enable or disable the Picture Menu. • On : The Main Menu is displayed. Menu Display • Off : The Main Menu is not displayed. Turning the front panel (local key) operations on/off. • Unlock : Unlocks all panel keys.
- Page 27 … • BMP or AVI files only. • Max file size : BMP - 960 X 540. AVI - 30MB. • The file can only be named samsung.bmp or samsung.avi. Logo Display Time … Hospitality Logo Display Time (3/5/7 seconds).
- Page 28 Solution Type Vendor Server installed in your site. • SINC Server : in the case of that the Samsung SINC server is installed in your site. Server URL Setting if this item is entered into, URL of the solution server can be inputted.
- Page 29 AGC Gain default value unless problems occur. If the Samsung Sound Bar device is connected to this TV, this item lets you to select where the TV sound is outputted when the TV is turned on. • ON : When the TV is turned on, the TV sound is automatically outputted in the Sound Bar Out Sound Bar device only.
- Page 30 Welcome Message ¦ The Welcome Message feature displays a custom message on the TV every time it is turned on. – Welcome message settings are in the Hotel Option Menu. – Set Welcome Message to ON to display the message when the TV is powered on. Welcome Message Edit Welcome Message Hospitality Logo...
- Page 31 Logo File Format – The TV supports only BMP and AVI format. – The file name must be samsung.bmp or samsung.avi. – The maximum resolution of the BMP format is 960 x 540. – The maximum file size for AVI format is 30MB.
- Page 32 USB Cloning ¦ The USB Cloning function lets you download user-configured settings (Picture, Sound, Input, Channel, Setup, and Hotel Setup) from one TV to a USB device, and then upload these settings from the USB device to other TV sets. This lets you create a standard file of settings and distribute that standard file to all the TVs in your facility.
- Page 33 y Settings Cloned in the Hotel Menu Menu Item Cloning Support Hospitality Mode SI Vendor Power On Channel Power On Channel Num Power On Channel Type Power On Volume Power On Volume Num Min Volume Max Volume Power On Source Power On Option Channel Setup Channel Editor...
- Page 34 Menu Item Cloning Support Logo Display Time Clone TV to USB Clone USB to TV Setting Auto Intialize REACH 3.0 REACH 2.0 REACH Channel Group ID IPG Room Type TICKER REACH Update Time REACH Update Immediate Room Number REACH 2.0 TV Sound REACH 2.0 Server Version Network Setup SmartHub Model Setting...
- Page 35 Multi Code Remocon ¦ A Multi Code Remocon is a special remote which is designed to control multiple TVs. This function is useful where there is more than one TV in a location. You can control up to 10 TVs with a different ID code of each remote with no conflicts between the TVs. ID numbers are displayed on each TV's OSD.
- Page 36 Setting Auto Initialize ¦ When you clone settings from one TV to another, you clone both the guest side menu and hotel side menu settings: Picture, Sound, Input, Channel, Setup, and Hotel Setup. This lets you set nearly all of the menu values on your hospitality TVs to the same, standard settings.
- Page 37 Press Power OFF to exit. Interactive Only Hospitality Option Menu Standalone appears. Plug&Play Welcome to Samsung TV Welcome to Samsung TV Confi gure your TV Auto Program Select your language to start the on Select your information in the categories below.
- Page 38 – If you select Standalone from the “Select Hotel TV Mode” OSD, the “Select Menu Language” OSD appears. – Initially highlighted: English – Display time: OSD time out and operation are the same as Samsung's consumer TV models. – If you press the Enter key, the “Picture Mode” OSD appears y Picture Mode OSD –...
- Page 39 ¦ Samsung may offer upgrades to the TV’s SW in the future. Please contact the Samsung Hospitality Hot line at 1-866-894- 0524 to receive information about downloading upgrades and using a USB drive to update the SW by connecting the USB drive containing the upgrade to the USB port located on the TV.
- Page 40 Channel Bank Editor (Smoovie TV Only) ¦ The Channel Bank Editor in conjunction with the SMOOVIE remote lets you control the channels guests have access to. The Channel Bank Editor provides three Banks of channels and lets you select which channels will be available from each bank. SMOOVIE remotes have instalable Bank Cards which correspond to the channel banks in the Channel Bank Editor.
- Page 41 Smoovie Set Up Sequence Smoovie TV Setup (Air/ Cable ) Only Air or Cable used Step Only Air or Cable used If the TV starts with Hotel Plug&Play If Hotel Plug&Play already done Do a complete P&P (including Air or Cable auto tune) Enter the Hotel menu Select the channel type After P&P, the TV displays the Hotel menu...
- Page 42 The picture below shows a sample Channel Editor screen. Channel ----- (Cable) a 10 ----- (Cable) Air 10-1 CW DTV ----- (Cable) a 11 ----- (Cable) Air 11-1 HBO DTV ----- (Cable) a 12 Air 12-1 NBC DTV Air 7-1 a 13 ----- (Cable) a 14...
-
Page 43: Edit Channel Number
When you press the TOOLS button, the following menu is available. Channel TOOLS ----- (Cable) a 10 Edit Channel Number ----- (Cable) Air 10-1 CW DTV Rename Channel ----- (Cable) a 11 Information ----- (Cable) Air 11-1 HBO DTV ----- (Cable) a 12 Air 12-1 NBC DTV... - Page 44 The external sources of this TV are displayed in the last page of the Channel Editor menu as shown in the example below. In the example, there are two external sources connected to the TV, HDMI2 and AV. – You can assign a new analog channel to an external source by selecting the source on the last page, pressing the TOOLS button, selecting Edit Channel Number, and then using the up or down arrow button on the remote to select the channel number of the analog channel.
-
Page 45: Installing The Wall Mount
Do not fasten the screws too firmly. This may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions. -
Page 46: Securing The Tv To The Wall
Securing the TV to the Wall Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do not hang on or destabilize the TV. Doing so may cause the TV to tip over, causing serious injuries or death. Follow all safety precautions provided in the Safety Flyer included with your TV. -
Page 47: Important Information
5. Fasten the Holder with a screw the same way used when attaching it to a cabinet. Make sure to stretch the Holder cord tight. If the rack is made of steel or glass, attach the holder onto the wall. –... -
Page 48: Specifications
Specifications Environmental Considerations Operating Temperature 50°F to 104°F (10°C to 40°C) Operating Humidity 10% to 80%, non-condensing Storage Temperature -4°F to 113°F (-20°C to 45°C) Storage Humidity 5% to 95%, non-condensing Model Name HG46NC890 HG55NC890 HG65NC890 Display Resolution 1920 X 1080 Screen Size 46"... -
Page 49: Display Resolution
Display Resolution When you use your TV as a computer monitor, you can also select one of the standard resolutions listed in the Resolution column. The TV will automatically adjust to the resolution you choose. Horizontal Frequency Vertical Frequency Pixel Clock Frequency Sync Polarity Mode Resolution... -
Page 50: Dimensions
Dimensions ▪ Front view / Side view HG46NC890 / HG55NC890 / HG65NC890 (Unit: inches) HG46NC890 40.6 40.1 22.6 23.5 25.1 HG55NC890 48.2 47.6 26.8 27.8 29.4 10.5 56.9 56.2 31.6 32.9 34.8 12.4 HG65NC890 ▪ Jack panel detail / Rear view HG46NC890 / HG55NC890 / HG65NC890 (Unit: inches) HG46NC890... - Page 51 NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your TV. Not responsible for typographical or printed errors. © 2014 Samsung Electronics America, Inc English [HC890_ZA]Install_Guide_00ENG.indd 51...
-
Page 52: Important Warranty Information Regarding Television Format Viewing
SAMSUNG will additionally provide Warranty Repair Service in the United States on SAMSUNG products purchased in Canada, and in Canada on SAMSUNG products purchased in the United States, for the warranty period originally specified, and to the Original Purchaser only. - Page 53 This page is intentionally left blank. [HC890_ZA]Install_Guide_00ENG.indd 53 2014-04-02 1:39:29...
- Page 54 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Samsung Hospitality Hotline : 1-866-894-0524 (US) 1-800-726-7864 (CANADA) 1-800-726-7864 (MEXICO) Web site : http://www.samsung.com/us/business [HC890_ZA]Install_Guide_00ENG.indd 54 2014-04-02 1:39:29...
