Page 1: Usb Adapter
USB Adapter PS/2 to USB Keyboard/ Mouse Adapter Installation Manual USB2PS2... - Page 2 USB specification via the USB instead of using conventional bus technology. The USB2PS2 comes with 2 standard 6 pin mini DIN female connectors for the PS/2 keyboard and PS/2 mouse to plug into, and has an attached 30 cm (1 ft.) USB cable with a type A plug for connection to the PCs USB port, or to a USB hub.
- Page 3 1. Plug the PS/2 mouse and PS/2 keyboard into the appropriate connectors on the USB2PS2 adapter. The ports are marked with an icon to indicate which is which. 2. Plug the USB2PS2 USB plug into the computer’s USB port, or into a USB Hub that is connected back to the computer.
-
Page 4: Specifications
Specifications Function Specification Connectors (2) 6 DIN Female, USB A Male Function Switches 1 Remote Wake Up Pushbutton Cable Length 0.3 m (1 ft.) Supported Platforms Windows98, Windows2000, Apple Mac OS 8.6 Transfer Rate 12Mbps (bits per second) USB Specifications 1.0 and 1.1 Compatible Power Mode Bus Powered (via the USB cable)
