Ice Zodiac Plus Operator's Manual page 68

Technical
Specification
External Outputs
(Fully software
configurable)
Operator Interface
(CLARiTY)
Power supply
requirements
Air supply
requirements
Operating
Temperature
Approvals
Table 7-1: Technical Specifications (Continued)
Rev AA
Zodiac Plus
2 relay outputs (1
change-over + 1 N/O)
and 2 PNP +24V outputs
(max source current =
100mA per output),
configurable from
CLARiTY Configuration
Manager
On-line/Off-line
Warning
Busy
Printing (actually
energising print dots)
Labeller feed
Print cycle active (Start
to end of print and
ribbon re-wind)
Update print queue full
New allocation
Print failed (i.e.
interrupted in mid print)
Fault
8.4" TFT SVGA
90 - 264V, 47 - 63 Hz,
single-phase type 'TN'
or 'TT' 320VA (max),
2.75A @ 115V AC, 1.4A
@230V AC, 60A max
surge @ 230V, 30A max
surge @ 115V
6 bar, 90 psi,
uncontaminated, 1.0 ml/
cycle (max)
5° - 40° C (41° - 104° F)
CE//NRTL Approval (by
2
METLAB) to UL60950
1. Print speeds and throughput are resolution, substrate, application
and set-up dependent.
2. Further information available on request.
Zodiac Plus Operator Manual
Zodiac Plus LA
2 relay outputs (1
change-over + 1 N/O)
and 2 PNP +24V
outputs (max source
current = 100mA per
output), configurable
from CLARiTY
Configuration Manager
On-line/Off-line
Warning
Busy
Printing (actually
energising print dots)
Labeller feed
Print cycle active (Start
to end of print and
ribbon re-wind)
Update print queue full
New allocation
Print failed (i.e.
interrupted in mid print)
Fault
8.4" TFT SVGA
90 - 264V, 47 - 63 Hz,
single-phase type 'TN'
or 'TT' 320VA (max),
2.75A @ 115V AC, 1.4A
@230V AC, 60A max
surge @ 230V, 30A max
surge @ 115V
6 bar, 90 psi,
uncontaminated, 1.0 ml/
cycle (max)
5°- 40° C (41° - 104° F)
CE//NRTL Approval (by
METLAB) to UL60950
Technical Specifications 7-3
