Group Control - Ice Zodiac Plus Operator's Manual

Zodiac Plus Operator Manual

Group Control

This level of operation (level 2) allows you to control the slave printers
from the master. As with Group Job Select, you can select jobs only on
the master printer. The master printer tells the slaves which job to
print. The slaves can be assigned and excluded from the group, as
described in "Group Job Select" on page 6-1.
You can use the master printer to change setup parameters for any
printer in the group.
The user interface on the master printer also displays the following
additional information:
• The Consumables information for each printer in the group.
• The Batch Count and Total Count values for the group as a whole.
• The fault or warning messages for both the master and slave
• The diagnostics information about each printer in the group.
6-2 Group Control
Total Count values for each printer in the group are also available.
printers (the slaves will show only their own faults or warnings).
Rev AA
