Specifications
This chapter contains the following topics:

Technical Specifications

Table 7-1 lists the technical specifications of the printer.
Table 7-1: Technical Specifications
Rev AA
• Technical specifications
• System specifications
• Print specifications
• Networking and external communications
• Printer dimensions
Technical Zodiac Plus
Specification
Printer
Unique SolidState Intermittent Motion and
Ribbon Drive Continuous Motion
Printhead 53 mm (2.1"), 300 dpi,
12 dots/mm
Print Area - 53 mm (W) x 75 mm (L)
Intermittent Motion (2.1"x2.9")
Mode
Print Area - 53 mm (W) x 135 mm (L)
Continuous Motion (2.1"x5.3")
Mode
Ribbon Width 20 mm-55 mm (0.8"-
2.2")
Maximum 1000 metres (3280')
Ribbon Length
Intermittent Motion 50 mm/sec-800 mm/sec
Mode (1.9"/sec-31.5"/sec) #1
7
Zodiac Plus LA
Intermittent Motion and
Continuous Motion
107 mm (4.2"), 300
dpi,12 dots/mm
107 mm (W) x 75 mm
(L) (4.2"x2.9")
107 mm (W) x 200 mm
(L) (4.2"x7.9")
55 mm-110 mm (2.2"-
4.2")
600 metres (1968')
50 mm/sec-520 mm/sec
1
(1.9"/sec-20.5"/sec)
Technical Specifications 7-1
