ORIGINAL INSTRUCTIONS
Petrol Lawn Mower
RLM5319SMEB
RLM140SP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RLM5319SMEB and is the answer not in the manual?

Questions and answers

Related Manuals for Ryobi RLM5319SMEB

Summary of Contents for Ryobi RLM5319SMEB

  • Page 1 ORIGINAL INSTRUCTIONS Petrol Lawn Mower RLM5319SMEB RLM140SP...
  • Page 2 Important! It is essential that you read the instructions in this manual before operating this machine. Subject to technical modifications.

  • Page 3: General Safety Rules

    English ■ Always mow in the daylight or in good artificial light. GENERAL SAFETY RULES ■ Do not operate the machine in explosive atmospheres, such as in the presence of flammable liquids, gases or WARNING dust. The tool create sparks which may ignite the dust or fumes.

  • Page 4: Safety Rules For Petrol Lawn Mowers

    English necessary. If you must back the machine away from a ■ If the mower should start to vibrate abnormally, stop wall or obstruction, first look down and behind to avoid the engine, disconnect the spark plug wire, and check tripping or pulling the machine over your feet.

  • Page 5: Intended Use

    English Keep bystanders a safe distance away Keep all body parts and clothing clear of any belts or other moving parts. from the machine. Fuel and its vapours are explosive and can cause severe burns or death. To avoid injury, stay away from moving parts at all times.
  • Page 6 ■ If any parts are damaged or missing, please call your INSTALLING THE MULCHING PLUG (FOR MULCHING Ryobi service centre for assistance. OPERATION) See figure 3. WARNING NOTE: When using the mulching plug, do not install the Do not use this product if any parts on the packing list grass catcher.

  • Page 7: Operation

    English SETTING BLADE HEIGHT FUEL AND REFUELLING See figure 6. WARNING When shipped, the wheels on the mower are set to a low- cutting position. Before using the mower for the fi rst time, Always handle petrol with care; it is highly flammable. adjust the cutting position to the height best suited for your lawn.

  • Page 8: General Maintenance

    English the engine and should not be used. EMPTYING THE GRASS CATCHER See figure 9. To add engine oil: 1. Stop the mower and wait for the blade to come to a 1. Be sure mower is level and area around oil cap/dipstick complete stop.
  • Page 9 English 5. Run the engine in place for approximately 30 seconds. order in which they were removed. 6. Shut off the engine. 8. Torque the blade bolt down using a torque wrench (not 7. Turn off the water supply. provided) to ensure the bolt is properly tightened. 8.

  • Page 10: Maintaining The Spark Plug

    English MAINTAINING THE SPARK PLUG allow the stabilizer to reach the carburetor. See figure 11. WARNING The spark plug must be properly gapped and free of deposits in order to ensure proper engine operation. To Do not store the lawn mower with petrol in the tank check: inside a building where fumes may reach an open flame 1.

  • Page 11: Specifications

    English SPECIFICATIONS Engine Subaru 190cc OHC Drive system Rear wheel self-propelled No-load speed 2,800 / min (RPM) Cutting path 530 mm 7 positions Height adjustments 19 mm−76 mm Wheel size - Front 20.3 cm (8 inch) - Rear 27.9 cm (11 inch) Grass bag capacity 70 litres Measured sound...

  • Page 12: Troubleshooting

    TROUBLESHOOTING Problem Possible cause Solution Handle positioned incorrectly. Check to be sure that lower part of handle is pushed Handle not in fully back and snapped into proper position. correct position. Handle knobs not tightened. Tighten handle knobs. No spark. Use spark tester to check for proper spark plug operation.
  • Page 13 4. For servicing, the product must be sent or presented to an RYOBI authorized service station listed for each country in the following list of service station addresses. In some countries your local RYOBI dealer undertakes to send the product to the RYOBI service organisation.

  • Page 14: Declaration Of Conformity

    Techtronic Industries GmbH Max-Eyth-Strasse 10, D-71364 Winnenden, Germany Herewith we declare that the product Petrol Lawn Mower Model number: RLM5319SMEB Serial number range: 92300402000001 - 92300402999999 is in conformity with the following European Directives and harmonised standards 2006/42/EC, 2004/108/EC, 2000/14/EC, 2005/88/EC, 2011/65/EU, EN 836:1997+A4:2011 Measured sound power level: 97.28 dB(A)
