INSTALLING LOGS
PCD24M & PCD24TD
WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts
specifically approved with this heater may result in property damage or personal injury.
CAUTION: After installation and periodically thereafter, check to ensure that no yellow flame comes in
contact with any log. With the heater set to High, check to see if yellow flames contact any log. If so,
reposition logs according to the log installation instructions in this manual. Yellow flames contacting logs will
create soot. It is very important to install the logs exactly as
instructed. Do not modify logs. Use only logs supplied with
heater.
Each log is marked with a number. This number will help you
to identify the logs when installing. It is very important to install
these logs exactly as instructed. Do not modify logs.
After installing logs, add decorative cinders around the grate
base, do not place any decorative cinders on logs or burner.
. Insert log # into slots in rear log
bracket on grate base, and tighten
nuts.
Figure 6 - Installing Log #
5. Insert the recessed hole on the
bottom of log #5 onto pin on log #,
with the other end placed on log #.
5
3
Figure 9 - Installing Log #5
. Insert log # into slots in middle
grate bracket and tighten nuts.


Figure 7 - Installing Log #
6. Insert the recessed hole on
the bottom of log #6 onto pin on
log #, with the other end placed
on log #3.

5

6
4
3
Figure 30 - Installing Log #6
3.

Figure 8 - Installing Log #3&Log#4
6.
the bottom of log #7 onto pin on
log #, with the other end placed
on log #4.


4
7
Provided Logs: 7
Insert log #3 and log#4 into slots
in front log bracket on grate base
and tighten nuts.

3
Insert the recessed hole on
5
6
3
Figure 3 - Installing Log #7

4


7
