Connectors
Audio:
5-pin Phoenix style
Exp In/Out:
8-pin mini DIN
Programmable I/O:
15 pin D-Sub
LecNet RS-232:
3.5mm Stereo jack

Audio Inputs

Line Input Type:
Electronically Balanced and RF Filtered
Input Impedance:
>40k Ohms, Balanced/Unbalanced
Maximum Input Level:
+20dBu
Gain Range:
+10dB to -68dB, plus off
Outputs
Line Output Type:
Electronically Balanced and RF filtered
Output Impedance:
200 ohms balanced, 100 ohms unbalanced
Output Gain Range:
0dB to –78dB, 1dB steps, plus mute
Maximum Output Level:
+20dBu
Matrix Crosspoints
Matrix Crosspoint
Gain Settings:
+10dB to -20dB, plus off in 1dB steps
User Defined Filters
Types Available:
1st order highpass and lowpass
2nd order highpass, bandpass, and lowpass
1st order shelving bass and treble
2nd order shelving bass and treble
Parametric
Feedback Eliminator (ADFE)
Filter Type:
1/5 octave notch, placed with 1/10
octave accuracy
Filter Cut:
-6dB, -12dB
Filter Range:
100Hz to 5.6kHz
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. If this equipment does cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

SPECIFICATIONS

Compressor
Attack Time:
Release Time:
Threshold:
Compression Ratio:
Limiter
Attack Time:
Release Time:
Threshold:
Digital Delay
Delay Time:
Programmable Inputs/Outputs
Programmable Input Range: 0VDC - 5VDC
Analog Control:
Logic Control:
Programmable Output:
Serial Communication
Default LecNet Address:
Serial Comm Parameters:
System:
Overall Latency:
System THD:
System IMD:
Power Consumption:
Weight:
Dimensions:

FCC PART 15 NOTICE

Rio Rancho, NM – USA
4 In / 4 Out Digital Audio Processor
0.5mS to 128mS in 0.5mS steps
10mS to 2.55S in 10mS steps
+20dBu to -40dBu in 1dB steps
1:1, 1.5:1, 2:1, 3:1, 4:1, 5:1
0. 1 25mS to 32mS in 0. 1 25mS steps
2mS to 512mS in 2mS steps
+20dBu to -40dBu in 1dB steps
182.625mS maximum, in 20.83uS steps
0dB to -30dB plus off control range
156mV/dB control sensitivity
Active Low
Active low
Max sink current:
100 mA
Max supply voltage:
40VDC
DSP4/4: 143; DSP4/4 Dual: 143, 144
RS-232, 9600 baud, 8 data bits, no parity,
1 stop bit
3 ms
Less than 0.05%, +20dBu in, +20dBu out
Less than 0.05%
DSP4/4: 10 Watts max at 16.5VAC;
Dual: 20 Watts max at 16.5VAC
3.5 lbs. (4 lbs for dual)
19" wide x 1.75" high x 8" deep
31
