7ZXE Motherboard
•
IDE1 Conductor Cable
Auto Will be automatically detected by BIOS (Default Value)
ATA66/100 Set IDE1 Conductor Cable to ATA66/100 (Please make sure your IDE
device and cable is compatible with ATA66/100)
ATA33 Set IDE1 Conductor Cable to ATA33 (Please make sure your IDE
device and cable is compatible with ATA33).
•
IDE2 Conductor Cable
Auto Will be automatically detected by BIOS (Default Value)
ATA66/100 Set IDE1 Conductor Cable to ATA66/100 (Please make sure your IDE
device and cable is compatible with ATA66/100)
ATA33 Set IDE1 Conductor Cable to ATA33 (Please make sure your IDE
device and cable is compatible with ATA33).
•
OnBoard Serial Port A
Auto BIOS will automatically setup the port A address. (Default Value)
3F8/COM1 Enable onboard Serial port A and address to 3F8.
2F8/COM2 Enable onboard Serial port A and address to 2F8.
3E8/COM3 Enable onboard Serial port A and address to 3E8.
2E8/COM4 Enable onboard Serial port A and address to 2E8.
Disabled Disable onboard Serial port A.
•
OnBoard Serial Port B
Auto BIOS will automatically setup the port B address. (Default Value)
3F8/COM1 Enable onboard Serial port B and address to 3F8.
2F8/COM2 Enable onboard Serial port B and address to 2F8.
3E8/COM3 Enable onboard Serial port B and address to 3E8.
2E8/COM4 Enable onboard Serial port B and address to 2E8.
Disabled Disable onboard Serial port B.
•
Serial Port B Mode
Normal Normal operation. (Default Value)
IrDA Onboard I/O chip supports IRDA
ASK IR Onboard I/O chip supports ASK IR.
59
