7ZXE Motherboard
A.5 Notices :
1. In order for STR to function properly, several hardware and software requirements must
be satisfied:
A. Your ATX power supply must comply with the ATX 2.01 specification (provide more
than 720 mA 5V Stand-By current).
B. Your SDRAM must be PC-100 compliant.
2. Jumper "STR_LED" is provided to connect to the STR LED in your system chassis.
[Some chassis may not provide this feature.] The STR LED will be illuminated when
your system is in STR sleep mode.
Please note:
Do not remove memory modules while DIMM LED is on. It might cause
short or other unexpected damages due to the 3.3V stand by voltage.
Remove memory modules only when STR function is disabled by jumper
and AC Power cord is disconnected.
+
1
STR LED Connector External
